ZIRCON® PRO MULTI-SCANNER® MAX DEPTH 76MM I700

StudScan mode locates the center, edges, and direction of wood or metal studs up to 3⁄4 in. (19 mm) deep DeepScan® mode doubles the scanning depth to 11⁄2 in. (38 mm) Metal Scan mode locates non-ferrous metal, such as copper pipe, up to 11⁄2 in. (38 mm) deep, and ferrous metal, such as rebar, up to 3 in. (76 mm) deep AC Scan mode finds and traces live, unshielded electrical wire up to 2 in. (51 mm) deep WireWarning® Detection indicates the presence of live, unshielded electrical wire up to 2 in. (51 mm) deep in stud and metal scan modes ACT™ (Auto Correcting Technology) corrects common errors automatically, such as when scanning begins over a stud Unique floating-head design keeps the scanning head flat on rough surfaces Integrated, erasable marker allows for one-handed operation

Specifications:

• Dimension: 190 mm H x 90 mm W x 33 mm D
• Weight: 210 g without Battery
• Battery Type: 9V alkaline (Not included)
• Position Accuracy*: Up To a Depth of 19 mm:
• Depth*: StudScan mode: Up To 19 mm
• AC & WireWarning® Position Accuracy*: TypicAlly 90-250 V at 50-60 Hz within
• AC & WireWarning® Depth*: In typical drywall with Romex® wiring,
• Operating Temperature: -7° to 41°C
• Storage Temperature: -29° to 66°C
• Humidity: 5-90% RH (Non-condensing)
• Water Resistance: Splash and water Resistant, Not waterproof
• Name: File Type
• ZIRCON® PRO MULTI-SCANNER® MAX DEPTH 76MM I700 TDS: .pdf
• ZIRCON® PRO MULTI-SCANNER® MAX DEPTH 76MM I700 Manual: .pdf
