ZIRCON® PRO METALLISCANNER™ MAX DEPTH 76MM M60C

Metal Scan Mode locates non-ferrous metal, such as copper pipe, up to 38 mm deep, and ferrous metal, such as rebar, up to 75 mm deep WireWarning® Detection indicates the presence of live, unshielded AC electrical wiring up to 50 mm deep in Metal Scan Mode AC Scan Mode locates live, unshielded AC electrical wiring up to 50 mm deep ColorTrip™ Display lights blue in Metal Scan Mode and red in AC Scan Mode Target Indication Bars will begin to turn on as live AC electricity or metal is approached Low Battery Indicator for optimum performance SpotLite® Pointer shines an arrow-shaped light on the wall when the maximum live AC or metal is detected

Specifications:

• Dimension: 160 mm H x 80 mm W x 32 mm D
• Weight: 203 g without Battery
• Battery Type: 9V alkaline, required
• AC Scan Mode & WireWarning® Position Accuracy*: TypicAlly 90-250 V at 50-60 Hz
• AC Scan Mode & WireWarning® Depth*: In typical wall with Romex® wiring,
• Position Accuracy*: Metal Scan Mode: TypicAlly within
• Depth*: Metal Scan Mode: Up To 38 mm
• Operating Temperature: -7° to 41°C
• Storage Temperature: -29° to 66°C
• Humidity: 5-90% RH (Non-condensing)
• Water Resistance: Splash and water Resistant, Not waterproof
• Name: File Type
• ZIRCON® PRO METALLISCANNER™ MAX DEPTH 76MM M60C TDS: .pdf
• ZIRCON® PRO METALLISCANNER™ MAX DEPTH 76MM M60C Manual: .pdf
