RAVEN RP35SI AUTOMATIC DOOR BOTTOM SEAL

AUTOMATIC DOOR BOTTOM SEAL – RP35Si An adjustable, automatic door bottom seal that is spring loaded to lift clear of the floor when the door is opened. It is acoustically designed, featuring silicon gaskets for medium temperature smoke and fire door applications. Operated automatically by pressure against the door jamb or stop on its adjustable strike. Location: Face mounted or semi-morticed into the bottom of solid core single and double butt hinged doors. The RP35Si can also be face mounted to the bottom of metal doors. Min/Max Gap: 3mm to 13mm. Finish: Satin clear (silver) or bronze anodised aluminium (15µm). Fixing: Concealed screw fix. Zinc plated, cross recess head S.T. screws, colour matched escutcheon plates and cover strip supplied. Fixing holes are pre-slotted. Sizes: 1220mm- For door width, 1070 – 1220mm 1070mm- For door width, 920 – 1070mm 920mm- For door width, 820 – 920mm 820mm- For door width, 600 – 820mm 600mm- For door width, 380 – 600mm 380mm- For door width, 295 – 380mm (380mm seal can be used on doors which are smaller than 295mm, but the automatic sealing system will not work) Approvals R37913 CF 5710 ANSI/BHMA A156.22 Acoustic AUS/NZ: NCC Spec. F5.5. UK/EU: Approved Document E. Rated to BS EN ISO 717.1. Fire AUS/NZ: NCC Spec. C3.4. AS1530.4 & AS/NZS 1905.1. NZ BC Compliance Doc. C/AS1 6.19.2 & App. C6.1.1. UK/EU: Approved Document B. BS 476 Pt. 20 & 22 (similar to BS EN 1634-1). FRL & FRR-/240/60 and FD240. Gasket flammability index 1 when tested to AS1530.2. Smoke NCC Spec. C3.4. AS1530.7 & BS EN 1634-3. Meets smoke leakage rates specified in AS6905 & EN 13501-2 “Sa”, “Sm”. Energy NCC Pt. 3.12.3.3 & J3.4. Durability Tested to over 1,000,000 operating cycles without failure. Insects/Vermin AS4674, 2.1.5(iv), 2.1.7. Patented, Registered Design.

Brand: A35SIBT15 RAVEN RP35SI AUTOMATIC DOOR BOTTOM SEAL

Specifications:

• NO BRAND: A35SIBT15
