PANDUIT CABLE TIE ANCHOR MOUNT #8 TA1S8-M 100PCS/PKT

Panduit TA1S8-M cable tie anchor mount is a low profile and versatile screw-installed mount that is ideal for applications where space is limited. This mount has four-way cable tie entry for easy orientation of wires and cables with the option to mount in-line or perpendicular to the wire bundle. Install with a #8 (M4) screw. Use with Miniature, Intermediate and Standard Panduit Cable Ties. For indoor use, are made of Nylon 6.6, are natural in color, and comes in packages of 100.

Specifications:

• Color: Natural
• Environment: Indoor
• Material: Nylon 6.6
• Mount Method: Screw
• Product Type: Cable Tie Mount
• Application: Low Profile Tie Anchor Mounts, Versatile Mount for Applications where Space is Limited
• For Use With: Miniature, Intermediate, Standard Cross-Section Ties
• Maximum Operating Temperature (°C): 85
• Maximum Operating Temperature (°F): 185
• Minimum Operating Temperature (°C): -60
• Minimum Operating Temperature (°F): -76
• Mounting Hole Thread Size: #8
• Standards Met: CE Compliant, UL Recognized E136577, RoHS Compliant
• Package 1 Height (cm): 3.43
• Package 1 Length (cm): 23.75
• Package 1 Width (cm): 22.61
• Package Weight (KG): 0.36
• Status: MATURE
• UPC: 07498358021
• Volume Of Package 1: 0.07
