MAKITA LS1040 MITER SAW 255MM SPARE PARTS

Spare Parts of Makita LS1040 Miter Saw Ref. No. Part Name & Number Price 004 MAKITA SHAFT LOCK FOR LS1040 Part No.: 343641-2 $0.98 Add To Cart 005 MAKITA FAN 80 FOR LS1045 P/N:241909-9 Part No.: 241909-9 $1.42 Add To Cart 007 MAKITA INSULATION WASHER FOR LS1040 P/N:681640-9 Part No.: 681640-9 $0.76 Add To Cart 008 MAKITA BALL BEARING 6000LLB P/N:211061-7 Part No.: 211061-7 $3.05 Add To Cart 011 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 016 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 017 MAKITA PAN HEAD SCREW M6X60 FOR LS1030 P/N:911383-2 Part No.: 911383-2 $0.65 Add To Cart 018 MAKITA SWITCH BUTTON FOR 2414NB P/N:411478-6 Part No.: 411478-6 $0.44 Add To Cart 019 MAKITA BRUSH HOLDER CAP 6.5-13.5 FOR 3612BR P/N:643650-4 Part No.: 643650-4 $0.44 Add To Cart 022 MAKITA SWITCH TG70B FOR LS1045 P/N:651923-1 Part No.: 651923-1 $9.92 Add To Cart 023 MAKITA COMPRESSION SPRING 3 FOR HM1302 P/N:231457-6 Part No.: 231457-6 $0.11 Add To Cart 024 MAKITA LOCK OFF LEVER FOR LS1040 P/N:416000-4 Part No.: 416000-4 $0.65 Add To Cart 025 MAKITA SWITCH LEVER FOR LS1040 P/N:415999-0 Part No.: 415999-0 $0.98 Add To Cart 026 MAKITA CAM FOR LS1040 Part No.: 414546-4 $0.65 Add To Cart 027 MAKITA TAPPING SCREW FLANGE PT 5X65 FOR 4100NH P/N:266029-8 Part No.: 266029-8 $0.87 Add To Cart 028 MAKITA COMPRESSION SPRING 9 FOR LS1040 Part No.: 231297-2 $0.33 Add To Cart 029 MAKITA HEX. BOLT M8X75 FOR LS1040 P/N:251667-9 Part No.: 251667-9 $0.76 Add To Cart 030 MAKITA RUBBER SLEEVE 6 FOR LS1040 P/N:262511-5 Part No.: 262511-5 $0.44 Add To Cart 031 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 033 MAKITA HELICAL GEAR 42 FOR LS1040 P/N : 226465-0 Part No.: 226465-0 $8.07 Add To Cart 034 MAKITA BEARING BOX FOR LS1040 P/N : 316821-3 Part No.: 316821-3 $4.25 Add To Cart 035 MAKITA BALL BEARING 6203LLB FOR HM1214C P/N:211256-2 Part No.: 211256-2 $4.36 Add To Cart 036 MAKITA BEARING RETAINER 64 FOR LS1040 P/N:285685-5 Part No.: 285685-5 $0.76 Add To Cart 037 MAKITA SPINDLE FOR LS1040 Part No.: 322865-3 $5.12 Add To Cart 038 MAKITA FLANGE 53 FOR LS1040 P/N:224333-1 Part No.: 224333-1 $3.49 Add To Cart 039 MAKITA FLANGE 53 FOR LS1040 P/N:224333-1 Part No.: 224333-1 $3.49 Add To Cart 040 MAKITA HEX. FLANGE HEAD BOLT M8X20 FOR LS1040 P/N:265355-2 Part No.: 265355-2 $0.55 Add To Cart 041 MAKITA CENTER PLATE FOR LS1040 P/N:343639-9 Part No.: 343639-9 $2.07 Add To Cart 042 MAKITA CENTER COVER FOR LS1040 P/N:344380-7 Part No.: 344380-7 $1.42 Add To Cart 043 MAKITA HEX. FLANGE HEAD BOLT M8X12 FOR LS1040 P/N:265324-3 Part No.: 265324-3 $0.55 Add To Cart 044 MAKITA TORSION SPRING 36 FOR LS1040 P/N:231593-8 Part No.: 231593-8 $0.44 Add To Cart 045 MAKITA SAFETY COVER FOR LS1040 P/N:416003-8 Part No.: 416003-8 $11.66 Add To Cart 046 MAKITA FLAT WASHER 5 FOR LS1040 P/N:267136-0 Part No.: 267136-0 $0.33 Add To Cart 047 MAKITA PAN HEAD SCREW M5X12 FOR LS1040 P/N:911213-7 Part No.: 911213-7 $0.33 Add To Cart 048 MAKITA HEX.SOCKET HEAD BOLT M6 FOR LS1040 P/N:265985-9 Part No.: 265985-9 $0.65 Add To Cart 049 MAKITA PAN HEAD SCREW M5X16 FOR LS1040 P/N:911223-4 Part No.: 911223-4 $0.33 Add To Cart 054 MAKITA COUNTERSUNK HEAD SCREW M6X25 FOR LS1040 P/N:912342-9 Part No.: 912342-9 $0.44 Add To Cart 055 MAKITA FLAT WASHER 6 FOR 2012NB P/N:253715-0 Part No.: 253715-0 $0.33 Add To Cart 057 MAKITA SUB FENCE PLATE FOR LS1040 P/N:344476-4 Part No.: 344476-4 $0.44 Add To Cart 058 MAKITA HEX. LOCK NUT M6-10 FOR LS1013 P/N:252014-7 Part No.: 252014-7 $0.33 Add To Cart 059 MAKITA HEX. SOCKET HEAD BOLT M6X10 FOR LS1040 P/N:251961-9 Part No.: 251961-9 $0.33 Add To Cart 060 MAKITA RING 7 FOR LS1040 Part No.: 257162-7 $0.55 Add To Cart 061 MAKITA FLAT WASHER 7 FOR LS1040 Part No.: 253823-7 $0.33 Add To Cart 062 MAKITA HEX.SOCKET BUTTON HEAD BOLT M6 F/LS1040 P/N:265984-1 Part No.: 265984-1 $0.44 Add To Cart 063 MAKITA LINK PLATE FOR LS1040 Part No.: 344377-6 $6.98 Add To Cart 064 MAKITA HEX.SOCKET BUTTON HEAD BOLT M6 F/LS1040 P/N:265984-1 Part No.: 265984-1 $0.44 Add To Cart 065 MAKITA FLAT WASHER 7 FOR LS1040 Part No.: 253823-7 $0.33 Add To Cart 066 MAKITA RING 7 FOR LS1040 Part No.: 257162-7 $0.55 Add To Cart 067 MAKITA LEVER 100 FOR LS1212 P/N:416006-2 Part No.: 416006-2 $1.31 Add To Cart 068 MAKITA PAN HEAD SCREW M4X10 FOR 3700B P/N:911113-1 Part No.: 911113-1 $0.22 Add To Cart 069 MAKITA HEX BOLT M10 FOR LS1040 Part No.: 265437-0 $2.40 Add To Cart 070 MAKITA FLAT WASHER 10 FOR LS1212 P/N:253024-7 Part No.: 253024-7 $0.44 Add To Cart 071 MAKITA ROD 16 FOR LS1040 Part No.: 256836-7 $2.40 Add To Cart 073 MAKITA STOPPER PIN FOR LS1013 P/N:322317-4 Part No.: 322317-4 $0.87 Add To Cart 074 MAKITA O RING 5 FOR LS1040 P/N:213021-5 Part No.: 213021-5 $0.11 Add To Cart 075 MAKITA COMPRESSION SPRING 28 FOR LS1040 Part No.: 233152-4 $2.18 Add To Cart 079 MAKITA PAN HEAD SCREW M4X10 FOR 3700B P/N:911113-1 Part No.: 911113-1 $0.22 Add To Cart 080 MAKITA POINTER FOR LS1040 P/N:344385-7 Part No.: 344385-7 $0.33 Add To Cart 081 MAKITA SLIDE PLATE FOR LS1040 Part No.: 343799-7 $0.44 Add To Cart 082 MAKITA HEX. BOLT M8X30 FOR LS1040 P/N:921452-1 Part No.: 921452-1 $0.55 Add To Cart 083 MAKITA PAN HEAD SCREW M5X12 FOR LS1040 P/N:911213-7 Part No.: 911213-7 $0.33 Add To Cart 085 MAKITA KNOCK SPRING FOR LS1040 P/N:344381-5 Part No.: 344381-5 $1.64 Add To Cart 088 MAKITA KERF BOARD FOR LS1040 P/N:416001-2 Part No.: 416001-2 $1.20 Add To Cart 089 MAKITA KERF BOARD FOR LS1040 P/N:416001-2 Part No.: 416001-2 $1.20 Add To Cart 090 MAKITA HEX. BOLT M8X30 FOR LS1040 P/N:921452-1 Part No.: 921452-1 $0.55 Add To Cart 091 MAKITA HEX NUT M8 FOR 5008B Part No.: 931402-8 $0.33 Add To Cart 092 MAKITA HEX. LOCK NUT M8-13 FOR LS1212 P/N:252105-4 Part No.: 252105-4 $0.76 Add To Cart 094 MAKITA HEX NUT M8 FOR 5008B Part No.: 931402-8 $0.33 Add To Cart 095 MAKITA HEX. BOLT M8X30 FOR LS1040 P/N:921452-1 Part No.: 921452-1 $0.55 Add To Cart 096 MAKITA RING 15.8 FOR LS1040 P/N:257060-5 Part No.: 257060-5 $1.53 Add To Cart 097 MAKITA SCREW M6X10 FOR 2414B P/N:251887-5 Part No.: 251887-5 $0.76 Add To Cart 098 MAKITA SCREW M6X20 FOR LS1040 P/N:265708-5 Part No.: 265708-5 $0.76 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 004: MAKITA SHAFT LOCK FOR LS1040 Part No.: 343641-2
• 005: MAKITA FAN 80 FOR LS1045 P/N:241909-9 Part No.: 241909-9
• 007: MAKITA INSULATION WASHER FOR LS1040 P/N:681640-9 Part No.: 681640-9
• 008: MAKITA BALL BEARING 6000LLB P/N:211061-7 Part No.: 211061-7
• 011: MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6
• 016: MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6
• 017: MAKITA PAN HEAD SCREW M6X60 FOR LS1030 P/N:911383-2 Part No.: 911383-2
• 018: MAKITA SWITCH BUTTON FOR 2414NB P/N:411478-6 Part No.: 411478-6
• 019: MAKITA BRUSH HOLDER CAP 6.5-13.5 FOR 3612BR P/N:643650-4 Part No.: 643650-4
• 022: MAKITA SWITCH TG70B FOR LS1045 P/N:651923-1 Part No.: 651923-1
• 023: MAKITA COMPRESSION SPRING 3 FOR HM1302 P/N:231457-6 Part No.: 231457-6
• 024: MAKITA LOCK OFF LEVER FOR LS1040 P/N:416000-4 Part No.: 416000-4
• 025: MAKITA SWITCH LEVER FOR LS1040 P/N:415999-0 Part No.: 415999-0
• 026: MAKITA CAM FOR LS1040 Part No.: 414546-4
• 027: MAKITA TAPPING SCREW FLANGE PT 5X65 FOR 4100NH P/N:266029-8 Part No.: 266029-8
• 028: MAKITA COMPRESSION SPRING 9 FOR LS1040 Part No.: 231297-2
• 029: MAKITA HEX. BOLT M8X75 FOR LS1040 P/N:251667-9 Part No.: 251667-9
• 030: MAKITA RUBBER SLEEVE 6 FOR LS1040 P/N:262511-5 Part No.: 262511-5
• 031: MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6
• 033: MAKITA HELICAL GEAR 42 FOR LS1040 P/N : 226465-0 Part No.: 226465-0
• 034: MAKITA BEARING BOX FOR LS1040 P/N : 316821-3 Part No.: 316821-3
• 035: MAKITA BALL BEARING 6203LLB FOR HM1214C P/N:211256-2 Part No.: 211256-2
• 036: MAKITA BEARING RETAINER 64 FOR LS1040 P/N:285685-5 Part No.: 285685-5
• 037: MAKITA SPINDLE FOR LS1040 Part No.: 322865-3
• 038: MAKITA FLANGE 53 FOR LS1040 P/N:224333-1 Part No.: 224333-1
• 039: MAKITA FLANGE 53 FOR LS1040 P/N:224333-1 Part No.: 224333-1
• 040: MAKITA HEX. FLANGE HEAD BOLT M8X20 FOR LS1040 P/N:265355-2 Part No.: 265355-2
• 041: MAKITA CENTER PLATE FOR LS1040 P/N:343639-9 Part No.: 343639-9
• 042: MAKITA CENTER COVER FOR LS1040 P/N:344380-7 Part No.: 344380-7
• 043: MAKITA HEX. FLANGE HEAD BOLT M8X12 FOR LS1040 P/N:265324-3 Part No.: 265324-3
• 044: MAKITA TORSION SPRING 36 FOR LS1040 P/N:231593-8 Part No.: 231593-8
• 045: MAKITA SAFETY COVER FOR LS1040 P/N:416003-8 Part No.: 416003-8
• 046: MAKITA FLAT WASHER 5 FOR LS1040 P/N:267136-0 Part No.: 267136-0
• 047: MAKITA PAN HEAD SCREW M5X12 FOR LS1040 P/N:911213-7 Part No.: 911213-7
• 048: MAKITA HEX.SOCKET HEAD BOLT M6 FOR LS1040 P/N:265985-9 Part No.: 265985-9
• 049: MAKITA PAN HEAD SCREW M5X16 FOR LS1040 P/N:911223-4 Part No.: 911223-4
• 054: MAKITA COUNTERSUNK HEAD SCREW M6X25 FOR LS1040 P/N:912342-9 Part No.: 912342-9
• 055: MAKITA FLAT WASHER 6 FOR 2012NB P/N:253715-0 Part No.: 253715-0
• 057: MAKITA SUB FENCE PLATE FOR LS1040 P/N:344476-4 Part No.: 344476-4
