MAKITA HR4501C ROTARY HAMMER SPARE PARTS

Spare Parts of Makita HR4501C Rotary Hammer Ref. No. Part Name & Number Price 001 MAKITA TOOL HOLDER CAP FOR HR4001C P/N:286272-3 Part No.: 286272-3 $1.09 Add To Cart 002 MAKITA RING SPRING 25 FOR DC/AC-HR/HM P/N:233948-3 Part No.: 233948-3 $0.87 Add To Cart 003 MAKITA RING 28 FOR HR4501C P/N:257280-1 Part No.: 257280-1 $4.36 Add To Cart 005 MAKITA SPACER FOR HR4001C P/N:419002-9 Part No.: 419002-9 $1.42 Add To Cart 006 MAKITA RING SPRING 25 FOR DC/AC-HR/HM P/N:233948-3 Part No.: 233948-3 $0.87 Add To Cart 007 MAKITA CHUCK RING FOR HM1111C P/N:324752-2 Part No.: 324752-2 $18.53 Add To Cart 008 MAKITA RELEASE COVER FOR HR4501C P/N:450030-5 Part No.: 450030-5 $3.27 Add To Cart 009 MAKITA TOOL RETAINER FOR HM1111C P/N:310178-4 Part No.: 310178-4 $7.30 Add To Cart 010 MAKITA SPRING GUIDE FOR HM1111C P/N:345804-6 Part No.: 345804-6 $2.07 Add To Cart 011 MAKITA COMPRESSION SPRING 49 P/N:233496-2 Part No.: 233496-2 $1.96 Add To Cart 012 MAKITA SPRING GUIDE FOR HM1111C P/N:345804-6 Part No.: 345804-6 $2.07 Add To Cart 013 MAKITA HEX.SOCKET HEAD BOLT M4X25 FOR 6922NB P/N:922148-7 Part No.: 922148-7 $0.55 Add To Cart 015 MAKITA HEX SOCKET HEAD BOLT M6X30 FOR HM1202C P/N:922353-6 Part No.: 922353-6 $0.44 Add To Cart 016 MAKITA BARREL COMPLETE FOR HR4501C P/N:158576-2 Part No.: 158576-2 $84.26 Add To Cart 017 MAKITA O RING 71 FOR HM1201 P/N:213754-2 Part No.: 213754-2 $0.98 Add To Cart 018 MAKITA FLAT WASHER 36 FOR HR4501C P/N:267357-4 Part No.: 267357-4 $4.25 Add To Cart 019 MAKITA RUBBER RING 36 P/N:262135-7 Part No.: 262135-7 $1.85 Add To Cart 020 MAKITA FLAT WASHER 36 FOR HR4501C P/N:267357-4 Part No.: 267357-4 $4.25 Add To Cart 021 MAKITA TOOL HOLDER FOR HR4501C P/N:324872-2 Part No.: 324872-2 $257.79 Add To Cart 022 MAKITA X-RING 21 FOR HM1214C P/N:213980-3 Part No.: 213980-3 $4.03 Add To Cart 023 MAKITA FLUORIDE RING 28 FOR HM1202C P/N:213431-6 Part No.: 213431-6 $14.28 Add To Cart 024 MAKITA O RING 23 FOR HM1202C P/N:213394-6 Part No.: 213394-6 $0.55 Add To Cart 025 MAKITA IMPACT BOLT FOR HR4501C P/N:324802-3 Part No.: 324802-3 $18.97 Add To Cart 026 MAKITA RING 19 FOR HR4501C P/N:324805-7 Part No.: 324805-7 $6.76 Add To Cart 027 MAKITA RUBBER RING 20 FOR HR4501C P/N:424032-7 Part No.: 424032-7 $4.58 Add To Cart 029 MAKITA O RING 53 FOR HM1201 P/N:213656-2 Part No.: 213656-2 $0.33 Add To Cart 030 MAKITA LOCK SLEEVE FOR HR4501C P/N:450031-3 Part No.: 450031-3 $1.20 Add To Cart 031 MAKITA LINK ARM FOR HR4501C P/N:165465-4 Part No.: 165465-4 $23.22 Add To Cart 032 MAKITA LINK ARM GUIDE P/N:450032-1 Part No.: 450032-1 $0.87 Add To Cart 034 MAKITA DRIVING SLEEVE FOR HR4501C P/N:324800-7 Part No.: 324800-7 $21.47 Add To Cart 035 MAKITA RING 38 FOR HR4501C P/N:331599-7 Part No.: 331599-7 $10.79 Add To Cart 036 MAKITA COMPRESSION SPRING 39 FOR HR4501C P/N:234024-6 Part No.: 234024-6 $2.51 Add To Cart 037 MAKITA STRAIGHT BEVEL GEAR 35 FOR HR4501C P/N:227526-9 Part No.: 227526-9 $45.13 Add To Cart 038 MAKITA STRIKER FOR HR4501C P/N:324804-9 Part No.: 324804-9 $7.19 Add To Cart 039 MAKITA O-RING 27 FOR HR4501C P/N:213981-1 Part No.: 213981-1 $1.74 Add To Cart 040 MAKITA CYLINDER FOR HR4501C P/N:324803-1 Part No.: 324803-1 $66.05 Add To Cart 041 MAKITA RING SPRING 37 FOR HK1820 P/N:233956-4 Part No.: 233956-4 $0.87 Add To Cart 042 MAKITA O RING 35 FOR HM1201 P/N:213460-9 Part No.: 213460-9 $0.44 Add To Cart 043 MAKITA RING38 FOR HR4501C P/N:257283-5 Part No.: 257283-5 $4.14 Add To Cart 044 MAKITA RING SPRING 36 FOR HR4501C P/N:233955-6 Part No.: 233955-6 $0.44 Add To Cart 045 MAKITA PIPE 10 FOR HR4500C P/N:331598-9 Part No.: 331598-9 $2.73 Add To Cart 046 MAKITA PISTON FOR HR4501C P/N:450025-8 Part No.: 450025-8 $7.41 Add To Cart 048 MAKITA CONNECTING ROD FOR HR4501C P/N:450026-6 Part No.: 450026-6 $4.91 Add To Cart 049 MAKITA O-RING 27 FOR HR4501C P/N:213981-1 Part No.: 213981-1 $1.74 Add To Cart 064 MAKITA HEX SOCKET HEAD BOLT M6X30 FOR HM1202C P/N:922353-6 Part No.: 922353-6 $0.44 Add To Cart 065 MAKITA TAPPING SCREW 4X14 FOR 2012NB P/N:266192-7 Part No.: 266192-7 $0.33 Add To Cart 066 MAKITA CHANGE LEVER FOR HR4001C P/N:419020-7 Part No.: 419020-7 $4.36 Add To Cart 067 MAKITA COMPRESSION SPRING 3 FOR HR4001C P/N:233436-0 Part No.: 233436-0 $0.22 Add To Cart 068 MAKITA LOCK BUTTON FOR HR4001C P/N:419009-5 Part No.: 419009-5 $0.76 Add To Cart 069 MAKITA TAPPING SCREW 4X14 FOR 2012NB P/N:266192-7 Part No.: 266192-7 $0.33 Add To Cart 070 MAKITA CRANK CAP COVER P/N:318171-2 Part No.: 318171-2 $13.84 Add To Cart 072 MAKITA O RING 36 P/N:213515-0 Part No.: 213515-0 $0.33 Add To Cart 073 MAKITA TORSION SPRING 16 FOR HR5211C P/N:233506-5 Part No.: 233506-5 $0.76 Add To Cart 074 MAKITA LINK LEVER FOR HR5211C P/N:310207-3 Part No.: 310207-3 $6.43 Add To Cart 075 MAKITA PAN HEAD SCREW M4X18 FOR HM0810 P/N:911133-5 Part No.: 911133-5 $0.33 Add To Cart 076 MAKITA CRANK CAP FOR HR4501C P/N:450034-7 Part No.: 450034-7 $6.54 Add To Cart 077 MAKITA RETAINER PLATE FOR HR5211C P/N:345778-1 Part No.: 345778-1 $3.92 Add To Cart 078 MAKITA TAPPING SCREW 4X12 FOR BHR200SF BO4556 P/N:266020-6 Part No.: 266020-6 $0.33 Add To Cart 079 MAKITA SEAL RING FOR HR4501C P/N:424034-3 Part No.: 424034-3 $1.09 Add To Cart 080 MAKITA LINK PLATE FOR HR4501C P/N:345822-4 Part No.: 345822-4 $5.01 Add To Cart 081 MAKITA LINK PLATE GUIDE FOR HR4501C P/N:450029-0 Part No.: 450029-0 $1.42 Add To Cart 082 MAKITA CRANK HOUSING COMPLETE FOR HR4501C P/N:158298-4 Part No.: 158298-4 $145.19 Add To Cart 083 MAKITA FIX GUIDE FOR HR4001C P/N:419008-7 Part No.: 419008-7 $0.55 Add To Cart 084 MAKITA CUSHION PLATE FOR HR4001C P/N:423345-3 Part No.: 423345-3 $0.55 Add To Cart 085 MAKITA CRANK SHAFT FOR HR4511C P/N:324801-5 Part No.: 324801-5 $23.76 Add To Cart 086 MAKITA BALL BEARING 6303LLU FOR HM0810 P/N:211279-0 Part No.: 211279-0 $9.92 Add To Cart 087 MAKITA RETAINING RING S-17 P/N:961057-5 Part No.: 961057-5 $0.33 Add To Cart 088 MAKITA KEY 5 P/N:254220-0 Part No.: 254220-0 $1.42 Add To Cart 089 MAKITA SPUR GEAR 19 P/N:227181-7 Part No.: 227181-7 $10.79 Add To Cart 090 MAKITA HELICAL GEAR 36 FOR HR4501C P/N:226655-5 Part No.: 226655-5 $16.35 Add To Cart 091 MAKITA RETAINING RING S-14 FOR LS1212 P/N:961054-1 Part No.: 961054-1 $0.33 Add To Cart 092 MAKITA FLAT WASHER 10 P/N:253180-3 Part No.: 253180-3 $0.44 Add To Cart 093 MAKITA TORQUE LIMITER ASS'Y FOR HR4501C P/N:125415-1 Part No.: 125415-1 $229.34 Add To Cart 098 MAKITA SEAL RING FOR HR4501C/127V P/N:424033-5 Part No.: 424033-5 $1.31 Add To Cart 099 MAKITA GEAR HOUSING COMPLETE FOR HR4501C P/N:158299-2 Part No.: 158299-2 $59.84 Add To Cart 100 MAKITA HANDLE COVER FOR HR5211C P/N:419796-6 Part No.: 419796-6 $11.99 Add To Cart 101 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 103 MAKITA SWITCH HOLDER CPL FOR HR4001C P/N:154626-1 Part No.: 154626-1 $1.64 Add To Cart 104 MAKITA SWITCH LEVER FOR HR4001C P/N:419028-1 Part No.: 419028-1 $1.64 Add To Cart 107 MAKITA TAPPING SCREW M5X25 FOR GA5010 Part No.: 266041-8 $0.44 Add To Cart 117 MAKITA CRANK HOUSING COVER FOR HR4501C P/N:450037-1 Part No.: 450037-1 $10.57 Add To Cart 118 MAKITA CONTROLLER FOR HR4501C P/N:631751-0 Part No.: 631751-0 $53.52 Add To Cart 119 MAKITA TAPPING SCREW 4X14 FOR 2012NB P/N:266192-7 Part No.: 266192-7 $0.33 Add To Cart 121 MAKITA STRAIN RELIEF FOR HP1620 HR2810 P/N:687169-3 Part No.: 687169-3 $0.44 Add To Cart 122 MAKITA TAPPING SCREW 4X14 FOR 2012NB P/N:266192-7 Part No.: 266192-7 $0.33 Add To Cart 123 MAKITA CORD CLAMP BASE FOR HR4001C P/N:419024-9 Part No.: 419024-9 $1.09 Add To Cart 124 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 125 MAKITA TAPPING SCREW 4X14 FOR 2012NB P/N:266192-7 Part No.: 266192-7 $0.33 Add To Cart 127 MAKITA CORD GUARD 10 FOR HR3000C P/N:682560-0 Part No.: 682560-0 $1.64 Add To Cart 128 MAKITA POWER SUPPLY CORD 1.5-2-4.0 P/N:692623-4 Part No.: 692623-4 $33.03 Add To Cart 129 MAKITA TAPPING SCREW M5X25 FOR GA5010 Part No.: 266041-8 $0.44 Add To Cart 130 MAKITA REAR COVER FOR HR4501C P/N:450035-5 Part No.: 450035-5 $24.20 Add To Cart 131 MAKITA HEX. NUT M8-12 FOR 4112HS P/N:252178-7 Part No.: 252178-7 $0.55 Add To Cart 132 MAKITA FLAT WASHER 8 FOR HM1801 P/N:253165-9 Part No.: 253165-9 $0.55 Add To Cart 133 MAKITA FAN 90 FOR HR4501C P/N:240016-5 Part No.: 240016-5 $4.14 Add To Cart 134 MAKITA FAN GUIDE FOR HR4501C P/N:419782-7 Part No.: 419782-7 $2.07 Add To Cart 136 MAKITA BRUSH HOLDER UNIT FOR HR5211C P/N:638447-4 Part No.: 638447-4 $9.92 Add To Cart 137 MAKITA MOTOR HOUSING FOR HR4510C P/N:450041-0 Part No.: 450041-0 $62.78 Add To Cart 138 MAKITA FIELD 220-240V FOR HR4501C P/N:636313-9 Part No.: 636313-9 $33.35 Add To Cart 139 MAKITA TAPPING SCREW FLANGE PT 5X50 FOR HR3000C P/N:266046-8 Part No.: 266046-8 $0.55 Add To Cart 141 MAKITA INSULATION WASHER FOR LS1013 P/N:681642-5 Part No.: 681642-5 $9.70 Add To Cart 142 MAKITA ARMATURE 220-240V FOR HR4501C P/N:517768-6 Part No.: 517768-6 $121.32 Add To Cart 143 MAKITA FLAT WASHER 15 P/N:267025-9 Part No.: 267025-9 $0.55 Add To Cart 144 MAKITA BALL BEARING 6202LLU FOR HM1202C P/N:211238-4 Part No.: 211238-4 $7.30 Add To Cart 145 MAKITA SLEEVE 12 FOR DC/AC-HR/HM P/N:331596-3 Part No.: 331596-3 $1.20 Add To Cart 146 MAKITA OIL SEAL FOR HR4001C Part No.: 213231-4 $3.38 Add To Cart 147 MAKITA BAFFLE PLATE P/N:450033-9 Part No.: 450033-9 $1.42 Add To Cart 148 MAKITA TAPPING SCREW 4X14 FOR 2012NB P/N:266192-7 Part No.: 266192-7 $0.33 Add To Cart 151 MAKITA SWITCH ST115A-40 FOR HR4001C/9526B P/N:651418-4 Part No.: 651418-4 $2.73 Add To Cart 152 MAKITA LEAF SPRING FOR HR4001C P/N:232209-8 Part No.: 232209-8 $0.33 Add To Cart 153 MAKITA SLIDE LEVER CPL FOR HR4001C P/N:154635-0 Part No.: 154635-0 $6.32 Add To Cart 154 MAKITA CONTROL PLATE FOR HR4501C P/N:450042-8 Part No.: 450042-8 $7.85 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA TOOL HOLDER CAP FOR HR4001C P/N:286272-3 Part No.: 286272-3
• 002: MAKITA RING SPRING 25 FOR DC/AC-HR/HM P/N:233948-3 Part No.: 233948-3
• 003: MAKITA RING 28 FOR HR4501C P/N:257280-1 Part No.: 257280-1
• 005: MAKITA SPACER FOR HR4001C P/N:419002-9 Part No.: 419002-9
• 006: MAKITA RING SPRING 25 FOR DC/AC-HR/HM P/N:233948-3 Part No.: 233948-3
• 007: MAKITA CHUCK RING FOR HM1111C P/N:324752-2 Part No.: 324752-2
• 008: MAKITA RELEASE COVER FOR HR4501C P/N:450030-5 Part No.: 450030-5
• 009: MAKITA TOOL RETAINER FOR HM1111C P/N:310178-4 Part No.: 310178-4
• 010: MAKITA SPRING GUIDE FOR HM1111C P/N:345804-6 Part No.: 345804-6
• 011: MAKITA COMPRESSION SPRING 49 P/N:233496-2 Part No.: 233496-2
• 012: MAKITA SPRING GUIDE FOR HM1111C P/N:345804-6 Part No.: 345804-6
• 013: MAKITA HEX.SOCKET HEAD BOLT M4X25 FOR 6922NB P/N:922148-7 Part No.: 922148-7
• 015: MAKITA HEX SOCKET HEAD BOLT M6X30 FOR HM1202C P/N:922353-6 Part No.: 922353-6
• 016: MAKITA BARREL COMPLETE FOR HR4501C P/N:158576-2 Part No.: 158576-2
• 017: MAKITA O RING 71 FOR HM1201 P/N:213754-2 Part No.: 213754-2
• 018: MAKITA FLAT WASHER 36 FOR HR4501C P/N:267357-4 Part No.: 267357-4
• 019: MAKITA RUBBER RING 36 P/N:262135-7 Part No.: 262135-7
• 020: MAKITA FLAT WASHER 36 FOR HR4501C P/N:267357-4 Part No.: 267357-4
• 021: MAKITA TOOL HOLDER FOR HR4501C P/N:324872-2 Part No.: 324872-2
• 022: MAKITA X-RING 21 FOR HM1214C P/N:213980-3 Part No.: 213980-3
• 023: MAKITA FLUORIDE RING 28 FOR HM1202C P/N:213431-6 Part No.: 213431-6
• 024: MAKITA O RING 23 FOR HM1202C P/N:213394-6 Part No.: 213394-6
• 025: MAKITA IMPACT BOLT FOR HR4501C P/N:324802-3 Part No.: 324802-3
• 026: MAKITA RING 19 FOR HR4501C P/N:324805-7 Part No.: 324805-7
• 027: MAKITA RUBBER RING 20 FOR HR4501C P/N:424032-7 Part No.: 424032-7
• 029: MAKITA O RING 53 FOR HM1201 P/N:213656-2 Part No.: 213656-2
• 030: MAKITA LOCK SLEEVE FOR HR4501C P/N:450031-3 Part No.: 450031-3
• 031: MAKITA LINK ARM FOR HR4501C P/N:165465-4 Part No.: 165465-4
• 032: MAKITA LINK ARM GUIDE P/N:450032-1 Part No.: 450032-1
• 034: MAKITA DRIVING SLEEVE FOR HR4501C P/N:324800-7 Part No.: 324800-7
• 035: MAKITA RING 38 FOR HR4501C P/N:331599-7 Part No.: 331599-7
• 036: MAKITA COMPRESSION SPRING 39 FOR HR4501C P/N:234024-6 Part No.: 234024-6
• 037: MAKITA STRAIGHT BEVEL GEAR 35 FOR HR4501C P/N:227526-9 Part No.: 227526-9
• 038: MAKITA STRIKER FOR HR4501C P/N:324804-9 Part No.: 324804-9
• 039: MAKITA O-RING 27 FOR HR4501C P/N:213981-1 Part No.: 213981-1
• 040: MAKITA CYLINDER FOR HR4501C P/N:324803-1 Part No.: 324803-1
• 041: MAKITA RING SPRING 37 FOR HK1820 P/N:233956-4 Part No.: 233956-4
• 042: MAKITA O RING 35 FOR HM1201 P/N:213460-9 Part No.: 213460-9
• 043: MAKITA RING38 FOR HR4501C P/N:257283-5 Part No.: 257283-5
