MAKITA HR166D 16MM CORDLESS ROTARY HAMMER SPARE PARTS

Spare Parts of Makita HR166D Rotary Hammer Ref. No. Part Name & Number Price 001 MAKITA CAP 34 FOR HR166D P/N:286037-3 Part No.: 286037-3 $0.76 Add To Cart 002 MAKITA RETAINING RING S-17 P/N:961057-5 Part No.: 961057-5 $0.33 Add To Cart 003 MAKITA FLAT WASHER 17 FOR HR166D P/N:253377-4 Part No.: 253377-4 $0.33 Add To Cart 004 MAKITA CHUCK COVER FOR HR166D P/N:457214-6 Part No.: 457214-6 $0.65 Add To Cart 005 MAKITA RING 21 FOR HR166D P/N:257416-2 Part No.: 257416-2 $0.98 Add To Cart 006 MAKITA STEEL BALL 7.0 FOR HR3000C HR2810 P/N:216022-2 Part No.: 216022-2 $0.11 Add To Cart 007 MAKITA GUIDE WASHER FOR HR2610 P/N:346177-0 Part No.: 346177-0 $0.44 Add To Cart 008 MAKITA CONICAL COMPRESSION SPRING FOR HR166D P/N:232347-6 Part No.: 232347-6 $0.33 Add To Cart 009 MAKITA HEX BOLT M8X120 FOR HR2020 P/N:921923-8 Part No.: 921923-8 $0.98 Add To Cart 010 MAKITA GRIP BASE FOR HR1830 P/N:417911-6 Part No.: 417911-6 $2.07 Add To Cart 011 MAKITA GRIP 36 COMPLETE FOR HR2470 P/N:158057-6 Part No.: 158057-6 $3.92 Add To Cart 012 MAKITA GEAR HOUSING COMPLETE FOR HR166D P/N:144218-4 Part No.: 144218-4 $15.81 Add To Cart 013 MAKITA CHANGE LEVER COMPLETE FOR HR166D P/N:161569-0 Part No.: 161569-0 $1.31 Add To Cart 014 MAKITA O RING 17 FOR HR2020 P/N:213278-8 Part No.: 213278-8 $0.33 Add To Cart 015 MAKITA LOCK BUTTON COMPLETE FOR HR166D P/N:161568-2 Part No.: 161568-2 $0.98 Add To Cart 016 MAKITA COMPRESSION SPRING 35 FOR HR166D P/N:232344-2 Part No.: 232344-2 $0.22 Add To Cart 017 MAKITA TOOL HOLDER FOR HR166D P/N:326841-9 Part No.: 326841-9 $15.48 Add To Cart 018 MAKITA RETAINING(EXT) WR-25 FOR HR1830 P/N:961135-1 Part No.: 961135-1 $0.87 Add To Cart 020 MAKITA SPUR GEAR 57 FOR HR166D P/N:221483-3 Part No.: 221483-3 $5.23 Add To Cart 021 MAKITA FLAT WASHER 24 P/N:267175-0 Part No.: 267175-0 $0.33 Add To Cart 022 MAKITA CHANGE PLATE COMPLETE FOR HR166D P/N:161570-5 Part No.: 161570-5 $2.07 Add To Cart 024 MAKITA STEEL BALL 3 FOR TD020SW P/N:216019-1 Part No.: 216019-1 $0.11 Add To Cart 025 MAKITA X-RING 13 FOR HR1830 P/N:213183-9 Part No.: 213183-9 $0.87 Add To Cart 026 MAKITA IMPACT BOLT FOR HR166D P/N:326843-5 Part No.: 326843-5 $1.09 Add To Cart 027 MAKITA RING 10 FOR HR166D P/N:326842-7 Part No.: 326842-7 $1.09 Add To Cart 028 MAKITA RING SPRING 23 FOR HR166D P/N:232343-4 Part No.: 232343-4 $0.11 Add To Cart 029 MAKITA STRIKER FOR HR166D P/N:326844-3 Part No.: 326844-3 $2.18 Add To Cart 030 MAKITA O RING 12 FOR HR2020 P/N:213128-7 Part No.: 213128-7 $0.87 Add To Cart 031 MAKITA PISTON CYLINDER FOR HR166D P/N:319510-9 Part No.: 319510-9 $5.01 Add To Cart 032 MAKITA GUIDE PLATE FOR HR166D P/N:347101-6 Part No.: 347101-6 $0.44 Add To Cart 033 MAKITA PISTON JOINT FOR HR166D P/N:326846-9 Part No.: 326846-9 $0.98 Add To Cart 034 MAKITA COMPRESSION SPRING 8 FOR HR166D P/N:232346-8 Part No.: 232346-8 $0.11 Add To Cart 035 MAKITA SPRING GUIDE FOR HR166D P/N:347102-4 Part No.: 347102-4 $0.44 Add To Cart 036 MAKITA CLUTCH CAM FOR HR166D P/N:326845-1 Part No.: 326845-1 $3.05 Add To Cart 037 MAKITA SPUR GEAR FOR HR166D P/N:221482-5 Part No.: 221482-5 $4.14 Add To Cart 038 MAKITA SWASH BEARING 6 FOR HR166D P/N:219026-3 Part No.: 219026-3 $10.36 Add To Cart 039 MAKITA SPIRAL BEVEL GEAR 37 FOR HR166D P/N:221481-7 Part No.: 221481-7 $6.54 Add To Cart 040 MAKITA BEARING RETAINER FOR HR166D P/N:347100-8 Part No.: 347100-8 $0.55 Add To Cart 041 MAKITA HEX SOCKET HEAD BOLT M4X12 FOR HR2020 P/N:266273-7 Part No.: 266273-7 $0.44 Add To Cart 042 MAKITA RING 5 FOR HR166D P/N:257415-4 Part No.: 257415-4 $0.55 Add To Cart 043 MAKITA BALL BEARING 625ZZ FOR HP451D P/N:210065-6 Part No.: 210065-6 $2.18 Add To Cart 044 MAKITA RING 5 FOR HR166D P/N:326847-7 Part No.: 326847-7 $0.98 Add To Cart 045 MAKITA HEX. SOCKET HEAD BOLT M3X12 FOR DJR183 P/N:265910-0 Part No.: 265910-0 $0.87 Add To Cart 046 MAKITA INNER SUPPORT COMPLETE FOR HR166D P/N:144219-2 Part No.: 144219-2 $5.45 Add To Cart 047 MAKITA O RING 60 FOR HR166D P/N:213092-2 Part No.: 213092-2 $0.65 Add To Cart 048 MAKITA FILTER FOR HR3200C P/N:443138-2 Part No.: 443138-2 $0.33 Add To Cart 050 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 051 MAKITA CONICAL COMPRESSION SPRING FOR HR166D P/N:232345-0 Part No.: 232345-0 $0.44 Add To Cart 052 MAKITA O RING 22.4 FOR 5600NB P/N:213008-7 Part No.: 213008-7 $0.33 Add To Cart 053 MAKITA ROTOR FOR HR166D P/N:619421-1 Part No.: 619421-1 $29.87 Add To Cart 059 MAKITA STATOR FOR HR166D P/N:629244-9 Part No.: 629244-9 $12.54 Add To Cart 060 MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9 $0.33 Add To Cart 061 MAKITA MOTOR CASE SET FOR HR166D P/N:183G09-0 Part No.: 183G09-0 $4.03 Add To Cart 062 MAKITA MOTOR CASE SET FOR HR166D P/N:183G09-0 Part No.: 183G09-0 $4.03 Add To Cart 063 MAKITA H.S.H. BOLT M3X12 WITH WRM FOR HR166D P/N:251510-2 Part No.: 251510-2 $0.55 Add To Cart 064 MAKITA TAPPING SCREW BIND PT 3X16 FOR 6226DWE P/N:266130-9 Part No.: 266130-9 $0.11 Add To Cart 065 MAKITA HOUSING SET FOR HR166D P/N:183G15-5 Part No.: 183G15-5 $17.33 Add To Cart 066 MAKITA HOUSING SET FOR HR166D P/N:183G15-5 Part No.: 183G15-5 $17.33 Add To Cart 067 MAKITA TAPPING SCREW BIND PT 3X16 FOR 6226DWE P/N:266130-9 Part No.: 266130-9 $0.11 Add To Cart 070 MAKITA F/R CHANGE LEVER FOR HR166D P/N:457210-4 Part No.: 457210-4 $0.87 Add To Cart 071 MAKITA SWITCH FOR DDF-DHP487/DF-HP332/HR166D P/N:650689-0 Part No.: 650689-0 $17.33 Add To Cart 072 MAKITA TERMINAL FOR TD110D P/N:644813-5 Part No.: 644813-5 $2.73 Add To Cart 073 MAKITA CONTROLLER FOR HR166D P/N:620578-3 Part No.: 620578-3 $77.94 Add To Cart 074 MAKITA LED CIRCUIT FOR HP332D P/N:620553-9 Part No.: 620553-9 $5.78 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA CAP 34 FOR HR166D P/N:286037-3 Part No.: 286037-3
• 002: MAKITA RETAINING RING S-17 P/N:961057-5 Part No.: 961057-5
• 003: MAKITA FLAT WASHER 17 FOR HR166D P/N:253377-4 Part No.: 253377-4
• 004: MAKITA CHUCK COVER FOR HR166D P/N:457214-6 Part No.: 457214-6
• 005: MAKITA RING 21 FOR HR166D P/N:257416-2 Part No.: 257416-2
• 006: MAKITA STEEL BALL 7.0 FOR HR3000C HR2810 P/N:216022-2 Part No.: 216022-2
• 007: MAKITA GUIDE WASHER FOR HR2610 P/N:346177-0 Part No.: 346177-0
• 008: MAKITA CONICAL COMPRESSION SPRING FOR HR166D P/N:232347-6 Part No.: 232347-6
• 009: MAKITA HEX BOLT M8X120 FOR HR2020 P/N:921923-8 Part No.: 921923-8
• 010: MAKITA GRIP BASE FOR HR1830 P/N:417911-6 Part No.: 417911-6
• 011: MAKITA GRIP 36 COMPLETE FOR HR2470 P/N:158057-6 Part No.: 158057-6
• 012: MAKITA GEAR HOUSING COMPLETE FOR HR166D P/N:144218-4 Part No.: 144218-4
• 013: MAKITA CHANGE LEVER COMPLETE FOR HR166D P/N:161569-0 Part No.: 161569-0
• 014: MAKITA O RING 17 FOR HR2020 P/N:213278-8 Part No.: 213278-8
• 015: MAKITA LOCK BUTTON COMPLETE FOR HR166D P/N:161568-2 Part No.: 161568-2
• 016: MAKITA COMPRESSION SPRING 35 FOR HR166D P/N:232344-2 Part No.: 232344-2
• 017: MAKITA TOOL HOLDER FOR HR166D P/N:326841-9 Part No.: 326841-9
• 018: MAKITA RETAINING(EXT) WR-25 FOR HR1830 P/N:961135-1 Part No.: 961135-1
• 020: MAKITA SPUR GEAR 57 FOR HR166D P/N:221483-3 Part No.: 221483-3
• 021: MAKITA FLAT WASHER 24 P/N:267175-0 Part No.: 267175-0
• 022: MAKITA CHANGE PLATE COMPLETE FOR HR166D P/N:161570-5 Part No.: 161570-5
• 024: MAKITA STEEL BALL 3 FOR TD020SW P/N:216019-1 Part No.: 216019-1
• 025: MAKITA X-RING 13 FOR HR1830 P/N:213183-9 Part No.: 213183-9
• 026: MAKITA IMPACT BOLT FOR HR166D P/N:326843-5 Part No.: 326843-5
• 027: MAKITA RING 10 FOR HR166D P/N:326842-7 Part No.: 326842-7
• 028: MAKITA RING SPRING 23 FOR HR166D P/N:232343-4 Part No.: 232343-4
• 029: MAKITA STRIKER FOR HR166D P/N:326844-3 Part No.: 326844-3
• 030: MAKITA O RING 12 FOR HR2020 P/N:213128-7 Part No.: 213128-7
• 031: MAKITA PISTON CYLINDER FOR HR166D P/N:319510-9 Part No.: 319510-9
• 032: MAKITA GUIDE PLATE FOR HR166D P/N:347101-6 Part No.: 347101-6
• 033: MAKITA PISTON JOINT FOR HR166D P/N:326846-9 Part No.: 326846-9
• 034: MAKITA COMPRESSION SPRING 8 FOR HR166D P/N:232346-8 Part No.: 232346-8
• 035: MAKITA SPRING GUIDE FOR HR166D P/N:347102-4 Part No.: 347102-4
• 036: MAKITA CLUTCH CAM FOR HR166D P/N:326845-1 Part No.: 326845-1
• 037: MAKITA SPUR GEAR FOR HR166D P/N:221482-5 Part No.: 221482-5
• 038: MAKITA SWASH BEARING 6 FOR HR166D P/N:219026-3 Part No.: 219026-3
• 039: MAKITA SPIRAL BEVEL GEAR 37 FOR HR166D P/N:221481-7 Part No.: 221481-7
• 040: MAKITA BEARING RETAINER FOR HR166D P/N:347100-8 Part No.: 347100-8
• 041: MAKITA HEX SOCKET HEAD BOLT M4X12 FOR HR2020 P/N:266273-7 Part No.: 266273-7
