FLUKE 374 FC TRUE-RMS AC/DC CLAMP METER

Fluke 374 FC delivers advanced troubleshooting performance and wireless connectivity The Fluke 374 FC, part of the Fluke Connect family of wireless test tools, delivers the standard features you need for everyday troubleshooting. Measure AC and DC current to 600 A with the fixed jaw clamp or add an optional iFlex® flexible current probe to measure all the way to 2500 A. The large diameter and flexible design of the iFlex probe make it easier to measure around large conductors in tight spaces or to access tightly packed wires. You can also use the 374 FC to measure AC and DC voltage to 1000 V and resistance to 6000 Ω. Use wireless connectivity to keep a safe distance The 374 FC is Fluke Connect-enabled to wirelessly transmit results via Bluetooth to Apple and Android devices. That means you can read the results out of the arc flash zone, wearing less PPE. You can even save results to the cloud and create and send reports in email right from the field. Or converse in real-time with ShareLive™ video calls. Versatile feature set With True-RMS AC voltage and current measurements, the 374 FC enables you to accurately troubleshoot non-linear signals. And you can log and trend measurements to pinpoint intermittents while you are performing other tasks. The Fluke 374 FC Clamp Meter is the direct replacement for the Fluke 374 Clamp Meter.

Specifications:

• Range: 600.0 A
• Resolution: 0.1 A
• Accuracy: 2% ±5 digits (10 Hz to 100 Hz)
• Crest Factor (50 Hz/60 Hz): 2.5 @ 600 A
• Range: 2500 A
• Resolution: 0.1 A (≤ 600 A)
• Accuracy: 3% ±5 digits (5 – 500 Hz)
• Crest Factor (50/60Hz): 2.5 at 1400 A
• Flexible current probe: Distance from Optimum
• A: 0.5 in (12.7 mm)
• B: 0.8 in (20.3 mm)
• C: 1.4 in (35.6 mm)
• Accuracy: 2% ±5 digits
• Range: 1000 V
• Resolution: 0.1 V (≤600.0 V)
• Accuracy: 1.5% ±5 digits (20 Hz to 500 Hz)
• Accuracy: 1% ±5 digits
• Range: 500.0 mV
• Resolution: 0.1 mV
• Range: 6000 Ω
• Resolution: 0.1 Ω (≤600 Ω)
• Range: 1000 μF
• Resolution: 0.1 μF (≤ 100 μF)
• Accuracy: 1% ±4 digits
• Maximum voltage between any terminal and earth ground: 1000 V
• Batteries: 2 AA, NEDA 15A, IEC LR6
• Operating temperature: -10 °C to +50 °C
• Storage temperature: -40 °C to +60 °C
• Operating humidity -: ≤90% RH (at 10 °C to 30 °C)
• non-condensing (< 10°C): ≤75% RH (at 30 °C to 40 °C)
• Operating altitude: 3000 m
• Storage altitude: 12,000 m
• Size (L x W x H): 249 x 85 x 45 mm
• Weight: 395 g
• Jaw opening: 34 mm
• Flexible current probe diameter: 7.5 mm
• Flexible current probe cable length: 1.8 m
• Safety: IEC 61010-1, Pollution Degree 2
• IP rating: IEC 60529: IP30, non-operating
• Radio Frequency Certification FCC ID: T68-FBLE IC:6627A-FBLE
