SRC SS RIVETS STAINLESS STEEL MANDREL

SRC SS RIVETS Stainless Steel Mandrel STSS Rivet with Stainless Steel Mandrel Materials: stainless steel rivet with stainless steel mandrel Standards: IFI-114 and DIN 7337 Can be installed quickly and easily from one side of the work piece Can be used in various applications including automotive industry, furniture industry, domestic appliances, aircraft, and more Rivets are ideal for settings requiring high strength and corrosion resistance

Specifications:

• Rivet Length L(Nom.): Hole Size (inch)
• Shear: Tensile
• 1/4": 0.097~0.100
• 5/16": 0.097~0.100
• 3/8": 0.097~0.100
• 1/2": 0.097~0.100
• 3/16": 0.129~0.133
• 1/4": 0.129~0.133
• 5/16": 0.129~0.133
• 3/8": 0.129~0.133
• 7/16": 0.129~0.133
• 1/2": 0.129~0.133
• 5/8": 0.129~0.133
• 3/4": 0.129~0.133
• 7/8": 0.129~0.133
• 1": 0.129~0.133
• 1/4": 0.160~0.164
• 5/16": 0.160~0.164
• 3/8": 0.160~0.164
• 7/16": 0.160~0.164
• 1/2": 0.160~0.164
• 5/8": 0.160~0.164
• 3/4": 0.160~0.164
• 7/8": 0.160~0.164
• 1": 0.160~0.164
• 1/4": 0.192~0.196
• 5/16": 0.192~0.196
• 3/8": 0.192~0.196
• 7/16": 0.192~0.196
• 1/2": 0.192~0.196
• 5/8": 0.192~0.196
• 3/4": 0.192~0.196
• 7/8": 0.192~0.196
• 1": 0.192~0.196
• 1/2": 0.257~0.261
• 5/8": 0.257~0.261
• 3/4": 0.257~0.261
• 7/8": 0.257~0.261
• 1": 0.257~0.261
