POWER-GEN LEAD ACID BATTERY (6V - 4.5AH) 70LX48WX103H (MM)

POWER-GEN LEAD ACID BATTERY 6V - 4.5AH Absorbent glass mat technology Recognized by RoHS & CE ABS container

Specifications:

• NoMinal Voltage: 6V
• Capacity (25°C): 20HR (5.25V)
• 10HR(5.25V): 4.2Ah
• 1HR(4.80V): 2.93AH
• Dimension: Length
• Width: 47 +-1mm (1.85inch)
• Height: 101 +-1mm (3.98inch)
• Total Height: 107 +-1mm (4.21inch)
• Approx. Weight: 0.72kgs (1.59lbs) +- 5%
• Terminal Type: T1
• Internal reistance (Fully charged 25°C): Approx. 25m
• Capacity affected by Temperature (20HR): 40°C
• 25°C: 100%
• 0°C: 85%
• -15°C: 65%
• Self-discharge (25°C): 3 month
• 6 month: Remaining Capacity: 82%
• 12 month: Remaining Capacity: 65%
• NorMinal Operating Temperature: 25°C + 3°C (77F°F +- 5°F)
• Operating Temperature range: Discharge
• Charge: -10°C ~ 50°C (14°F ~ 122°F)
• Storage: -20°C ~ 50°C (-4°F ~ 122°F)
• Floating charging Voltage (25°C): 6.80 to 6.90V
• Cyclic charging Voltage (25°C): 7.25 to 7.45V
• Maximum charging Current: 1.35A
• Termainal Material: Copper
• Maximum discharge Current: 67.5A (5 sec)
• Designed floating life (20°C): 10 years
