OSS CURTAIN BOOTH TYPE SHOWER & EYEWASH (SQUARE CURTAIN) ESE-SB

Combination showers provide instant access to a safety shower and or an emergency eyewash in one location. Besides, the curtain gives the user privacy and prevents water splashing out into the surrounding area. Dimension: All height:2450 mm Shower height:2100 mm Eyewash height:1140 mm Features, All tubes of the equipment are made SUS304# material with special antirust process. Indication sign: PS material, 305x230mm,Chinese & English language with graphic. Meet ANSI Z358.1-1998, CNS14251 T2048-1998, DIN 12899.

Specifications:

• Bottom Drain Pan: SUS304# stainless material- 910(W) x 160(D) x 150(H)mm
• All height: 2450mm
• Shower height: 2100mm
• Eyewash height: 1140mm
• Bore: Supply water: 1-1/4" SUS304# Stainless Steel
• Waste Bore: 2" SUS304# Stainless Steel
• Eyewash tube: 3/8" SUS304# Stainless Steel
• Eyewash head: Nylon material- ?50mm x 44mm, Include two kinds of filter to remove impurities from water flow, with yellow plastic “flip top"dust cover.
• Bowl dimension: 345mm SUS304#stainless
• Shower head: SUS304#stainless Steel -Dimension: 200mm
• Hydraulic pressure: Above 1 kg/cm2
• Action: Shower: A stainless actuator Eyewash SAFETY SHOWER: Hand push plate
• Floor top: Grid plate FRP material two pieces for easy cleaning.
• Drain design: At the right and left back side, each has 2" drainage hole with removable sieve that is easy to clean.
• Curtain frame: SUS304# stainless tube material- 910(W)x 910(D)mm
• Curtain: Yellow PVC material,2 sets. Upper and lower with holes for installing curtain moving and fixing clips, by Velcro’s on both sides can combine two curtains to attach closely to avoid water splashing.
• Frame fixed clip: MS material，include two kinds of dimension 70 x 30mm & 70 x 15mm.
• Sign: 305x230mm,Chinese & English, language with graphic.
