MAKITA UR202C BATTERY POWERED GRASS TRIMMER SPARE PARTS

Spare Parts of Makita UR202C Battery Powered Grass Trimmer Ref. No. Part Name & Number Price 001 MAKITA GEAR CASE ASSEMBLY FOR DUR369 P/N:127380-0 Part No.: 127380-0 $38.37 Add To Cart 002 MAKITA '+HEX.BOLT M8X10 WITH R P/N:265590-2 Part No.: 265590-2 $0.22 Add To Cart 003 MAKITA RETAINING RING S-7 P/N:259070-8 Part No.: 259070-8 $0.33 Add To Cart 004 MAKITA BALL BEARING 627ZZ FOR MT811 P/N:210030-5 Part No.: 210030-5 $1.20 Add To Cart 005 MAKITA SPIRAL BEVEL GEAR 21 FOR DUR369 P/N:226954-5 Part No.: 226954-5 $2.73 Add To Cart 006 MAKITA CUTTER SHAFT ASS'Y FOR UR202C P/N:136234-0 Part No.: 136234-0 $16.13 Add To Cart 008 MAKITA RETAINING RING R-35 P/N:259069-3 Part No.: 259069-3 $0.22 Add To Cart 009 MAKITA RECEIVE WASHER FOR DUR369 P/N:140N88-3 Part No.: 140N88-3 $4.91 Add To Cart 010 MAKITA SPIRAL BEVEL GEAR FOR UR202C P/N:136236-6 Part No.: 136236-6 $5.23 Add To Cart 011 MAKITA BALL BEARING 609ZZ P/N:210049-4 Part No.: 210049-4 $3.49 Add To Cart 012 MAKITA RETAINING RING S-9 P/N:259071-6 Part No.: 259071-6 $0.33 Add To Cart 013 MAKITA RETAINING RING R-24 P/N:259072-4 Part No.: 259072-4 $0.22 Add To Cart 014 MAKITA SOCKET HEAD BOLT M5X 14 922216-6 FOR JR3000V P/N : 922216-6 Part No.: 922216-6 $0.44 Add To Cart 015 MAKITA HEX. SOCKET HEAD BOLT M5X25 P/N:922242-5 Part No.: 922242-5 $0.33 Add To Cart 016 MAKITA HEX. SOCKET HEAD BOLT M5X25 P/N:251513-6 Part No.: 251513-6 $0.33 Add To Cart 017 MAKITA PROTECTOR CLAMP 24 FOR DC-UR P/N:347107-4 Part No.: 347107-4 $1.96 Add To Cart 018 MAKITA SOCKET HEAD BOLT M5X 14 922216-6 FOR JR3000V P/N : 922216-6 Part No.: 922216-6 $0.44 Add To Cart 019 MAKITA PROTECTOR N 430 SET MG FOR UR008G P/N:191B55-9 Part No.: 191B55-9 $25.29 Add To Cart 021 MAKITA CUTTER EXTENSION FOR DUR369 P/N:459765-5 Part No.: 459765-5 $1.31 Add To Cart 022 MAKITA CUTTER FOR EM2900L P/N:347115-5 Part No.: 347115-5 $1.74 Add To Cart 023 MAKITA TAPPING SCREW M5X25 P/N:266459-3 Part No.: 266459-3 $0.33 Add To Cart 024 MAKITA H.S.H.BOLT M5X20 WITH WG P/N:922234-4 Part No.: 922234-4 $0.55 Add To Cart 025 MAKITA LOOP HANDLE 24 P/N:457267-5 Part No.: 457267-5 $10.14 Add To Cart 026 MAKITA UPPER CLAMP 35 FOR DC-UR/UX P/N:347113-9 Part No.: 347113-9 $0.87 Add To Cart 027 MAKITA LOWER CLAMP 35 FOR DC-UR/UX P/N:347114-7 Part No.: 347114-7 $1.31 Add To Cart 028 MAKITA SHAFT PIPE J COM FOR DC-UR-G/C P/N:140S83-3 Part No.: 140S83-3 $23.98 Add To Cart 029 MAKITA SHAFT FOR DUR369 P/N:327056-1 Part No.: 327056-1 $7.09 Add To Cart 030 MAKITA DAMPER FOR DC-UR/UX P/N:424942-8 Part No.: 424942-8 $1.31 Add To Cart 031 MAKITA PIPE HOLDER 24 FOR DC-UR/UX P/N:457269-1 Part No.: 457269-1 $1.64 Add To Cart 032 MAKITA H.S.H.BOLT M5X25 WITH WG P/N:922244-1 Part No.: 922244-1 $1.20 Add To Cart 033 MAKITA SPACER 24 FOR DUR369 P/N:451601-1 Part No.: 451601-1 $1.96 Add To Cart 034 MAKITA HEX. SOCKET HEAD BOLT M5X12 FOR HR3850 P/N:922211-6 Part No.: 922211-6 $0.33 Add To Cart 035 MAKITA H.S.H.BOLT M5X20 WITH WR P/N:922233-6 Part No.: 922233-6 $0.22 Add To Cart 037 MAKITA PAN HEAD SCREW M5X20 P/N:911233-1 Part No.: 911233-1 $0.33 Add To Cart 038 MAKITA RUBBER PIN 4 P/N:263002-9 Part No.: 263002-9 $0.11 Add To Cart 039 MAKITA SPINDLE HUB P/N:325811-5 Part No.: 325811-5 $4.47 Add To Cart 040 MAKITA BALL BEARING 6001DDW FOR 9016B BO4556 P/N:211131-2 Part No.: 211131-2 $3.27 Add To Cart 041 MAKITA HELICAL GEAR 29 P/N:226931-7 Part No.: 226931-7 $4.80 Add To Cart 042 MAKITA BALL BEARING 6901ZZ FOR 6916FD P/N:211150-8 Part No.: 211150-8 $4.58 Add To Cart 043 MAKITA TAPPING SCREW M5X25 P/N:266459-3 Part No.: 266459-3 $0.33 Add To Cart 044 MAKITA GEAR BOX ASS'Y P/N:136231-6 Part No.: 136231-6 $9.05 Add To Cart 045 MAKITA O RING 22 FOR UN001G P/N:213961-7 Part No.: 213961-7 $0.33 Add To Cart 047 MAKITA BALL BEARING 608DDW FOR HR4000C/PV7000C P/N:210005-4 Part No.: 210005-4 $1.53 Add To Cart 048 MAKITA ROTOR ASS'Y FOR DUR369L/UR202C P/N:519587-6 Part No.: 519587-6 $51.01 Add To Cart 049 MAKITA BALL BEARING 607ZZ FOR MT950 P/N:210062-2 Part No.: 210062-2 $0.98 Add To Cart 051 MAKITA BAFFLE PLATE FOR DC-OPE P/N:459764-7 Part No.: 459764-7 $1.31 Add To Cart 052 MAKITA STATOR FOR DUR369L P/N:629471-8 Part No.: 629471-8 $50.58 Add To Cart 055 MAKITA SWITCH CIRCUIT G COM FOR DC UR-G/C P/N:140W06-5 Part No.: 140W06-5 $17.99 Add To Cart 056 MAKITA LOCK OFF LEVER FOR DC-OPE P/N:459759-0 Part No.: 459759-0 $1.42 Add To Cart 057 MAKITA SPRING 4 FOR DC-OPE P/N:233101-1 Part No.: 233101-1 $0.22 Add To Cart 058 MAKITA SWITCH FOR UB001C/UX01G/UR202C P/N:651436-2 Part No.: 651436-2 $16.35 Add To Cart 059 MAKITA TORSION SPRING 12 FOR DC-OPE P/N:233622-3 Part No.: 233622-3 $0.22 Add To Cart 060 MAKITA SWITCH LEVER FOR DC-OPE P/N:459758-2 Part No.: 459758-2 $1.53 Add To Cart 063 MAKITA H.S.H.BOLT M5X20 WITH WR P/N:922233-6 Part No.: 922233-6 $0.22 Add To Cart 064 MAKITA HANDLE SET P/N:183N70-9 Part No.: 183N70-9 $36.52 Add To Cart 065 MAKITA MOTOR HOUSING FOR DUA301/UA002G/UR202C P/N:459763-9 Part No.: 459763-9 $5.67 Add To Cart 068 MAKITA POWER SUPPLY CORD UNIT FOR UR202C P/N:699147-1 Part No.: 699147-1 $108.13 Add To Cart 071 MAKITA CONTROLLER FOR UR202C P/N:620C71-5 Part No.: 620C71-5 $255.82 Add To Cart 072 MAKITA GUARD P/N:422609-2 Part No.: 422609-2 $4.91 Add To Cart 073 MAKITA HANDLE SET P/N:183N70-9 Part No.: 183N70-9 $36.52 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA GEAR CASE ASSEMBLY FOR DUR369 P/N:127380-0 Part No.: 127380-0
• 002: MAKITA '+HEX.BOLT M8X10 WITH R P/N:265590-2 Part No.: 265590-2
• 003: MAKITA RETAINING RING S-7 P/N:259070-8 Part No.: 259070-8
• 004: MAKITA BALL BEARING 627ZZ FOR MT811 P/N:210030-5 Part No.: 210030-5
• 005: MAKITA SPIRAL BEVEL GEAR 21 FOR DUR369 P/N:226954-5 Part No.: 226954-5
• 006: MAKITA CUTTER SHAFT ASS'Y FOR UR202C P/N:136234-0 Part No.: 136234-0
• 008: MAKITA RETAINING RING R-35 P/N:259069-3 Part No.: 259069-3
• 009: MAKITA RECEIVE WASHER FOR DUR369 P/N:140N88-3 Part No.: 140N88-3
• 010: MAKITA SPIRAL BEVEL GEAR FOR UR202C P/N:136236-6 Part No.: 136236-6
• 011: MAKITA BALL BEARING 609ZZ P/N:210049-4 Part No.: 210049-4
• 012: MAKITA RETAINING RING S-9 P/N:259071-6 Part No.: 259071-6
• 013: MAKITA RETAINING RING R-24 P/N:259072-4 Part No.: 259072-4
• 014: MAKITA SOCKET HEAD BOLT M5X 14 922216-6 FOR JR3000V P/N : 922216-6 Part No.: 922216-6
• 015: MAKITA HEX. SOCKET HEAD BOLT M5X25 P/N:922242-5 Part No.: 922242-5
• 016: MAKITA HEX. SOCKET HEAD BOLT M5X25 P/N:251513-6 Part No.: 251513-6
• 017: MAKITA PROTECTOR CLAMP 24 FOR DC-UR P/N:347107-4 Part No.: 347107-4
• 018: MAKITA SOCKET HEAD BOLT M5X 14 922216-6 FOR JR3000V P/N : 922216-6 Part No.: 922216-6
• 019: MAKITA PROTECTOR N 430 SET MG FOR UR008G P/N:191B55-9 Part No.: 191B55-9
• 021: MAKITA CUTTER EXTENSION FOR DUR369 P/N:459765-5 Part No.: 459765-5
• 022: MAKITA CUTTER FOR EM2900L P/N:347115-5 Part No.: 347115-5
• 023: MAKITA TAPPING SCREW M5X25 P/N:266459-3 Part No.: 266459-3
• 024: MAKITA H.S.H.BOLT M5X20 WITH WG P/N:922234-4 Part No.: 922234-4
• 025: MAKITA LOOP HANDLE 24 P/N:457267-5 Part No.: 457267-5
• 026: MAKITA UPPER CLAMP 35 FOR DC-UR/UX P/N:347113-9 Part No.: 347113-9
• 027: MAKITA LOWER CLAMP 35 FOR DC-UR/UX P/N:347114-7 Part No.: 347114-7
• 028: MAKITA SHAFT PIPE J COM FOR DC-UR-G/C P/N:140S83-3 Part No.: 140S83-3
• 029: MAKITA SHAFT FOR DUR369 P/N:327056-1 Part No.: 327056-1
• 030: MAKITA DAMPER FOR DC-UR/UX P/N:424942-8 Part No.: 424942-8
• 031: MAKITA PIPE HOLDER 24 FOR DC-UR/UX P/N:457269-1 Part No.: 457269-1
• 032: MAKITA H.S.H.BOLT M5X25 WITH WG P/N:922244-1 Part No.: 922244-1
• 033: MAKITA SPACER 24 FOR DUR369 P/N:451601-1 Part No.: 451601-1
• 034: MAKITA HEX. SOCKET HEAD BOLT M5X12 FOR HR3850 P/N:922211-6 Part No.: 922211-6
• 035: MAKITA H.S.H.BOLT M5X20 WITH WR P/N:922233-6 Part No.: 922233-6
• 037: MAKITA PAN HEAD SCREW M5X20 P/N:911233-1 Part No.: 911233-1
• 038: MAKITA RUBBER PIN 4 P/N:263002-9 Part No.: 263002-9
• 039: MAKITA SPINDLE HUB P/N:325811-5 Part No.: 325811-5
• 040: MAKITA BALL BEARING 6001DDW FOR 9016B BO4556 P/N:211131-2 Part No.: 211131-2
• 041: MAKITA HELICAL GEAR 29 P/N:226931-7 Part No.: 226931-7
• 042: MAKITA BALL BEARING 6901ZZ FOR 6916FD P/N:211150-8 Part No.: 211150-8
