MAKITA UC003G 300MM CORDLESS CHAIN SAW SPARE PARTS

Spare Parts of Makita UC003G Cordless Chain Saw Ref. No. Part Name & Number Price 001 MAKITA FRONT HANDLE FOR UC002G P/N:413979-0 Part No.: 413979-0 $4.25 Add To Cart 002 MAKITA TANK CAP ASSEMBLY P/N:122A77-2 Part No.: 122A77-2 $12.10 Add To Cart 006 MAKITA SWITCH CIRCUIT COMPLETE FOR UC002G P/N:141G07-0 Part No.: 141G07-0 $15.91 Add To Cart 007 MAKITA TAPPING SCREW 5X20 FOR HR2810 P/N:266420-0 Part No.: 266420-0 $0.33 Add To Cart 011 MAKITA SWITCH FOR UC002G P/N:650011-1 Part No.: 650011-1 $23.22 Add To Cart 014 MAKITA SWITCH UNIT FOR DUC/UC-G/UB P/N:632L48-2 Part No.: 632L48-2 $16.02 Add To Cart 016 MAKITA PAN HEAD SCREW M3X6 P/N:652031-1 Part No.: 652031-1 $0.11 Add To Cart 017 MAKITA TERMINAL UNIT FOR UC002G P/N:632S63-8 Part No.: 632S63-8 $7.74 Add To Cart 019 MAKITA CAP P/N:422467-6 Part No.: 422467-6 $0.55 Add To Cart 020 MAKITA OIL TUBE 3-85 FOR UC002G P/N:422764-0 Part No.: 422764-0 $1.42 Add To Cart 021 MAKITA PAN HEAD SCREW M4X10 FOR 3700B P/N:911113-1 Part No.: 911113-1 $0.22 Add To Cart 022 MAKITA OIL PUMP CPL FOR MUC3041 P/N:142156-4 Part No.: 142156-4 $16.90 Add To Cart 023 MAKITA OIL TUBE 3-109 FOR UC002G P/N:422765-8 Part No.: 422765-8 $1.31 Add To Cart 024 MAKITA SPRING FOR UC3520A P/N:231975-4 Part No.: 231975-4 $0.33 Add To Cart 026 MAKITA PAN HEAD SCREW M5X14 FOR 2702 P/N:911218-7 Part No.: 911218-7 $0.33 Add To Cart 027 MAKITA STOP RING E-4 FOR HR3850 P/N:961011-9 Part No.: 961011-9 $0.11 Add To Cart 028 MAKITA WORM GEAR P/N:226884-0 Part No.: 226884-0 $0.87 Add To Cart 029 MAKITA MOTOR HOUSING FOR UC002G P/N:413904-1 Part No.: 413904-1 $9.16 Add To Cart 031 MAKITA SENSOR UNIT FOR UC002G P/N:620F73-9 Part No.: 620F73-9 $29.76 Add To Cart 032 MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6 $0.22 Add To Cart 033 MAKITA STATOR FOR UC001G P/N:629A85-9 Part No.: 629A85-9 $24.31 Add To Cart 036 MAKITA BALL BEARING 696ZZ P/N:210026-6 Part No.: 210026-6 $3.27 Add To Cart 037 MAKITA ROTOR ASSY FOR UC002G P/N:519710-3 Part No.: 519710-3 $53.19 Add To Cart 039 MAKITA PAN HEAD SCREW M4X12 FOR BO4540 HR2810 P/N:911118-1 Part No.: 911118-1 $0.33 Add To Cart 040 MAKITA FRONT HAND GUARD RETAINER FOR UC002G P/N:413907-5 Part No.: 413907-5 $1.96 Add To Cart 041 MAKITA FRONT HAND GUARD COMPLETE FOR UC002G P/N:141E58-1 Part No.: 141E58-1 $7.41 Add To Cart 042 MAKITA COMPRESSION SPRING 3 FOR UC002G P/N:232714-5 Part No.: 232714-5 $0.33 Add To Cart 043 MAKITA HARD GUARD GUIDE FOR EA3200S P/N:313212-9 Part No.: 313212-9 $0.55 Add To Cart 047 MAKITA GROMET P/N:422466-8 Part No.: 422466-8 $0.55 Add To Cart 048 MAKITA DRIVE GEAR P/N:227620-7 Part No.: 227620-7 $1.20 Add To Cart 049 MAKITA STRAIGHT BEVEL GEAR 14 FOR EA3700T P/N:227634-6 Part No.: 227634-6 $3.49 Add To Cart 050 MAKITA TENSION SLIDE P/N:347517-5 Part No.: 347517-5 $1.42 Add To Cart 051 MAKITA ADJUST SCREW FOR UC003G P/N:327317-9 Part No.: 327317-9 $1.85 Add To Cart 052 MAKITA BEVEL GEAR 14 FOR UC4030A Part No.: 227496-2 $1.20 Add To Cart 053 MAKITA HOOK FOR EA3700T P/N:281222-3 Part No.: 281222-3 $0.55 Add To Cart 055 MAKITA CHAIN CATCHER P/N:347516-7 Part No.: 347516-7 $0.76 Add To Cart 058 MAKITA SPIKE BUMPER FOR EA3700T P/N:346809-9 Part No.: 346809-9 $0.98 Add To Cart 059 MAKITA LINK PLATE COMPLETE FOR UC002G P/N:141E60-4 Part No.: 141E60-4 $5.01 Add To Cart 060 MAKITA COMPRESSION SPRING 7 FOR UC254D P/N:232452-9 Part No.: 232452-9 $0.65 Add To Cart 061 MAKITA BRAKE BAND FOR UC002G P/N:347864-4 Part No.: 347864-4 $3.71 Add To Cart 062 MAKITA HOUSING R COVER FOR UC002G P/N:413981-3 Part No.: 413981-3 $2.94 Add To Cart 064 MAKITA BRAKE DRUM FOR UC002G P/N:162979-4 Part No.: 162979-4 $8.18 Add To Cart 067 MAKITA STOP RING E-7 FOR JN3200 P/N:961013-5 Part No.: 961013-5 $0.22 Add To Cart 068 MAKITA GUIDE PLATE L P/N:347533-7 Part No.: 347533-7 $0.87 Add To Cart 069 MAKITA H.L. SOCKET HEAD BOLT M5X12 FOR EA3700T P/N:266905-6 Part No.: 266905-6 $0.55 Add To Cart 070 MAKITA TAPPING SCREW BIND PT3X10 FOR BTW201 P/N:266007-8 Part No.: 266007-8 $0.11 Add To Cart 071 MAKITA GUIDE PLATE R P/N:347534-5 Part No.: 347534-5 $0.87 Add To Cart 072 MAKITA SPROCKET COVER ASS'Y FOR UC002G P/N:136573-8 Part No.: 136573-8 $12.64 Add To Cart 077 MAKITA HOSE CLAMP P/N:345920-4 Part No.: 345920-4 $0.33 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA FRONT HANDLE FOR UC002G P/N:413979-0 Part No.: 413979-0
• 002: MAKITA TANK CAP ASSEMBLY P/N:122A77-2 Part No.: 122A77-2
• 006: MAKITA SWITCH CIRCUIT COMPLETE FOR UC002G P/N:141G07-0 Part No.: 141G07-0
• 007: MAKITA TAPPING SCREW 5X20 FOR HR2810 P/N:266420-0 Part No.: 266420-0
• 011: MAKITA SWITCH FOR UC002G P/N:650011-1 Part No.: 650011-1
• 014: MAKITA SWITCH UNIT FOR DUC/UC-G/UB P/N:632L48-2 Part No.: 632L48-2
• 016: MAKITA PAN HEAD SCREW M3X6 P/N:652031-1 Part No.: 652031-1
• 017: MAKITA TERMINAL UNIT FOR UC002G P/N:632S63-8 Part No.: 632S63-8
• 019: MAKITA CAP P/N:422467-6 Part No.: 422467-6
• 020: MAKITA OIL TUBE 3-85 FOR UC002G P/N:422764-0 Part No.: 422764-0
• 021: MAKITA PAN HEAD SCREW M4X10 FOR 3700B P/N:911113-1 Part No.: 911113-1
• 022: MAKITA OIL PUMP CPL FOR MUC3041 P/N:142156-4 Part No.: 142156-4
• 023: MAKITA OIL TUBE 3-109 FOR UC002G P/N:422765-8 Part No.: 422765-8
• 024: MAKITA SPRING FOR UC3520A P/N:231975-4 Part No.: 231975-4
• 026: MAKITA PAN HEAD SCREW M5X14 FOR 2702 P/N:911218-7 Part No.: 911218-7
• 027: MAKITA STOP RING E-4 FOR HR3850 P/N:961011-9 Part No.: 961011-9
• 028: MAKITA WORM GEAR P/N:226884-0 Part No.: 226884-0
• 029: MAKITA MOTOR HOUSING FOR UC002G P/N:413904-1 Part No.: 413904-1
• 031: MAKITA SENSOR UNIT FOR UC002G P/N:620F73-9 Part No.: 620F73-9
• 032: MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6
• 033: MAKITA STATOR FOR UC001G P/N:629A85-9 Part No.: 629A85-9
• 036: MAKITA BALL BEARING 696ZZ P/N:210026-6 Part No.: 210026-6
• 037: MAKITA ROTOR ASSY FOR UC002G P/N:519710-3 Part No.: 519710-3
• 039: MAKITA PAN HEAD SCREW M4X12 FOR BO4540 HR2810 P/N:911118-1 Part No.: 911118-1
• 040: MAKITA FRONT HAND GUARD RETAINER FOR UC002G P/N:413907-5 Part No.: 413907-5
• 041: MAKITA FRONT HAND GUARD COMPLETE FOR UC002G P/N:141E58-1 Part No.: 141E58-1
• 042: MAKITA COMPRESSION SPRING 3 FOR UC002G P/N:232714-5 Part No.: 232714-5
• 043: MAKITA HARD GUARD GUIDE FOR EA3200S P/N:313212-9 Part No.: 313212-9
• 047: MAKITA GROMET P/N:422466-8 Part No.: 422466-8
• 048: MAKITA DRIVE GEAR P/N:227620-7 Part No.: 227620-7
• 049: MAKITA STRAIGHT BEVEL GEAR 14 FOR EA3700T P/N:227634-6 Part No.: 227634-6
• 050: MAKITA TENSION SLIDE P/N:347517-5 Part No.: 347517-5
• 051: MAKITA ADJUST SCREW FOR UC003G P/N:327317-9 Part No.: 327317-9
• 052: MAKITA BEVEL GEAR 14 FOR UC4030A Part No.: 227496-2
• 053: MAKITA HOOK FOR EA3700T P/N:281222-3 Part No.: 281222-3
• 055: MAKITA CHAIN CATCHER P/N:347516-7 Part No.: 347516-7
• 058: MAKITA SPIKE BUMPER FOR EA3700T P/N:346809-9 Part No.: 346809-9
• 059: MAKITA LINK PLATE COMPLETE FOR UC002G P/N:141E60-4 Part No.: 141E60-4
• 060: MAKITA COMPRESSION SPRING 7 FOR UC254D P/N:232452-9 Part No.: 232452-9
