MAKITA PJ7000 JOINT CUTTER SPARE PARTS

Spare Parts of Makita PJ7000 Jointer Cutter Ref. No. Part Name & Number Price 001 MAKITA CAP HEAD BOLT M8 X 16 P/N:922422-3 Part No.: 922422-3 $0.55 Add To Cart 002 MAKITA FLAT WASHER 8 FOR UT1301 P/N:941202-8 Part No.: 941202-8 $0.22 Add To Cart 003 MAKITA GRIP FOR PJ7000 P/N:453218-6 Part No.: 453218-6 $3.05 Add To Cart 004 MAKITA TAPPING SCREW 4X22MM FOR GA4030 Part No.: 266324-6 $0.11 Add To Cart 005 MAKITA PIN CAP FOR MT950 P/N:417771-6 Part No.: 417771-6 $0.33 Add To Cart 006 MAKITA COMPRESSION SPRING 7 FOR CA5000 P/N:234057-1 Part No.: 234057-1 $0.11 Add To Cart 007 MAKITA HEX. NUT M6 FOR DC/AC-GA P/N:252186-8 Part No.: 252186-8 $0.11 Add To Cart 008 MAKITA SPIRAL BEVEL GEAR 10 FOR GA4030 P/N:227545-5 Part No.: 227545-5 $3.05 Add To Cart 009 MAKITA O RING 26 FOR HR2810 P/N:213445-5 Part No.: 213445-5 $0.33 Add To Cart 010 MAKITA BALL BEARING 629DDW FOR 3612C BO4556 P/N:211092-6 Part No.: 211092-6 $2.40 Add To Cart 011 MAKITA RETAINING RING R-26 P/N:962105-3 Part No.: 962105-3 $0.55 Add To Cart 012 MAKITA GUIDE PLATE FOR GA4030 P/N:413126-3 Part No.: 413126-3 $0.33 Add To Cart 015 MAKITA INSULATION WASHER FOR 4304 P/N:681636-0 Part No.: 681636-0 $0.33 Add To Cart 016 MAKITA BALL BEARING 607LLB FOR 9553NB BO4556 P/N:210034-7 Part No.: 210034-7 $0.98 Add To Cart 018 MAKITA BAFFLE PLATE FOR GA4030 Part No.: 450796-7 $0.44 Add To Cart 019 MAKITA TAPPING SCREW 4X70 FOR 9553NB HR2810 P/N:266325-4 Part No.: 266325-4 $0.33 Add To Cart 022 MAKITA TAPPING SCREW 3X8 P/N:266492-5 Part No.: 266492-5 $0.11 Add To Cart 023 MAKITA BRUSH HOLDER FOR GA4030 P/N:643839-4 Part No.: 643839-4 $1.31 Add To Cart 025 MAKITA SWITCH DPX-2110-R DOUBLE FOR 9556NB P/N:650621-4 Part No.: 650621-4 $2.94 Add To Cart 026 MAKITA STRAIN RELIEF FOR GA4030 P/N:687681-3 Part No.: 687681-3 $0.33 Add To Cart 029 MAKITA CORD GUARD FOR MT410 BO4556 P/N:682569-2 Part No.: 682569-2 $0.65 Add To Cart 030 MAKITA POWER S.CORD BASEC CORD P/N:692021-2 Part No.: 692021-2 $9.92 Add To Cart 032 MAKITA REAR COVER FOR GA4030 P/N:450794-1 Part No.: 450794-1 $2.07 Add To Cart 033 MAKITA SWITCH LEVER FOR GA4030 P/N:450797-5 Part No.: 450797-5 $0.55 Add To Cart 034 MAKITA SPRING 4 FOR DC/AC-GA P/N:233121-5 Part No.: 233121-5 $0.11 Add To Cart 035 MAKITA MOTOR HOUSING FOR GA4030 P/N:450795-9 Part No.: 450795-9 $6.54 Add To Cart 036 MAKITA SWITCH KNOB FOR 9556NB P/N:419566-3 Part No.: 419566-3 $0.44 Add To Cart 037 MAKITA O RING 4 P/N:213032-0 Part No.: 213032-0 $0.22 Add To Cart 038 MAKITA SHOULDER PIN 4 FOR GA4030 P/N:256510-7 Part No.: 256510-7 $0.55 Add To Cart 039 MAKITA GEAR HOUSING COMPLETE FOR PJ7000 P/N:141327-0 Part No.: 141327-0 $10.03 Add To Cart 041 MAKITA RING SPRING 11 FOR 9553HN P/N:233950-6 Part No.: 233950-6 $0.11 Add To Cart 042 MAKITA SPIRAL BEVEL GEAR 37 FOR GA4030 P/N:227546-3 Part No.: 227546-3 $5.34 Add To Cart 043 MAKITA RETAINING RING R-32 P/N:962151-6 Part No.: 962151-6 $0.55 Add To Cart 045 MAKITA SPINDLE FOR PJ7000 P/N:326120-5 Part No.: 326120-5 $5.45 Add To Cart 046 MAKITA O RING 42 FOR GA4030 P/N:213561-3 Part No.: 213561-3 $0.33 Add To Cart 047 MAKITA BEARING BOX FOR PJ7000 P/N:318811-2 Part No.: 318811-2 $16.79 Add To Cart 048 MAKITA PAN HEAD SCREW M4X20 FOR N1900B P/N:911136-9 Part No.: 911136-9 $0.33 Add To Cart 049 MAKITA PAN HEAD SCREW M4X20 FOR N1900B P/N:911136-9 Part No.: 911136-9 $0.33 Add To Cart 050 MAKITA HEX. NUT M5 FOR JS3200 P/N:931203-4 Part No.: 931203-4 $0.22 Add To Cart 051 MAKITA PANHEAD SCREW M5*45 FOR PJ7000 P/N:266741-0 Part No.: 266741-0 $0.33 Add To Cart 052 MAKITA BASE COVER FOR PJ7000 P/N:453406-5 Part No.: 453406-5 $1.31 Add To Cart 053 MAKITA ROD 10 FOR PJ7000 P/N:326145-9 Part No.: 326145-9 $2.40 Add To Cart 054 MAKITA FENCE COMPLETE FOR PJ7000 P/N:141247-8 Part No.: 141247-8 $15.81 Add To Cart 055 MAKITA STOP RING E-3 FOR 4304 P/N:961017-7 Part No.: 961017-7 $0.11 Add To Cart 056 MAKITA PIN 4 FOR 3901 P/N:256689-4 Part No.: 256689-4 $1.85 Add To Cart 057 MAKITA BASE FOR PJ7000 P/N:318813-8 Part No.: 318813-8 $26.60 Add To Cart 058 MAKITA COMPRESSION SPRING 2.4 P/N:231282-5 Part No.: 231282-5 $0.44 Add To Cart 059 MAKITA STEEL BALL 3.5 FOR 6409 P/N : 216001-0 Part No.: 216001-0 $0.11 Add To Cart 060 MAKITA STOPPER FOR PJ7000 P/N:318814-6 Part No.: 318814-6 $6.10 Add To Cart 061 MAKITA HEX.SOCKET SET SCREW M5*6 FOR SS610D P/N:266264-8 Part No.: 266264-8 $0.33 Add To Cart 062 MAKITA PAN HEAD SCREW M4 FOR PJ7000 P/N:266738-9 Part No.: 266738-9 $0.55 Add To Cart 063 MAKITA O RING 22.4 FOR 5600NB P/N:213008-7 Part No.: 213008-7 $0.33 Add To Cart 064 MAKITA DUST NOZZLE P/N:415252-4 Part No.: 415252-4 $1.53 Add To Cart 066 MAKITA DISK SPRING P/N:232131-9 Part No.: 232131-9 $0.44 Add To Cart 067 MAKITA O RING 4 FOR HR3000R P/N:213023-1 Part No.: 213023-1 $0.22 Add To Cart 068 MAKITA FLAT HEAD SQUARE NECK BOLT M6* PJ7000 P/N:266737-1 Part No.: 266737-1 $0.33 Add To Cart 069 MAKITA COMPRESSION SPRING 2.4 P/N:231282-5 Part No.: 231282-5 $0.44 Add To Cart 070 MAKITA STEEL BALL 3.5 FOR 6409 P/N : 216001-0 Part No.: 216001-0 $0.11 Add To Cart 071 MAKITA TENSION SPRING 8 P/N:231795-6 Part No.: 231795-6 $2.07 Add To Cart 073 MAKITA HEX NUT M6 FOR CS550D P/N:252159-1 Part No.: 252159-1 $0.55 Add To Cart 074 MAKITA STOP RING E-8 FOR LC1210 P/N:961014-3 Part No.: 961014-3 $0.33 Add To Cart 075 MAKITA FLAT WASHER 6 FOR 6095DWE P/N:253804-1 Part No.: 253804-1 $0.33 Add To Cart 077 MAKITA LOCK NUT 10-40 P/N:224505-8 Part No.: 224505-8 $2.51 Add To Cart 079 MAKITA RUBBER SPIKE PJ7000 P/N:424479-5 Part No.: 424479-5 $0.44 Add To Cart 080 MAKITA O RING 4 FOR HR3000R P/N:213023-1 Part No.: 213023-1 $0.22 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA CAP HEAD BOLT M8 X 16 P/N:922422-3 Part No.: 922422-3
• 002: MAKITA FLAT WASHER 8 FOR UT1301 P/N:941202-8 Part No.: 941202-8
• 003: MAKITA GRIP FOR PJ7000 P/N:453218-6 Part No.: 453218-6
• 004: MAKITA TAPPING SCREW 4X22MM FOR GA4030 Part No.: 266324-6
• 005: MAKITA PIN CAP FOR MT950 P/N:417771-6 Part No.: 417771-6
• 006: MAKITA COMPRESSION SPRING 7 FOR CA5000 P/N:234057-1 Part No.: 234057-1
• 007: MAKITA HEX. NUT M6 FOR DC/AC-GA P/N:252186-8 Part No.: 252186-8
• 008: MAKITA SPIRAL BEVEL GEAR 10 FOR GA4030 P/N:227545-5 Part No.: 227545-5
• 009: MAKITA O RING 26 FOR HR2810 P/N:213445-5 Part No.: 213445-5
• 010: MAKITA BALL BEARING 629DDW FOR 3612C BO4556 P/N:211092-6 Part No.: 211092-6
• 011: MAKITA RETAINING RING R-26 P/N:962105-3 Part No.: 962105-3
• 012: MAKITA GUIDE PLATE FOR GA4030 P/N:413126-3 Part No.: 413126-3
• 015: MAKITA INSULATION WASHER FOR 4304 P/N:681636-0 Part No.: 681636-0
• 016: MAKITA BALL BEARING 607LLB FOR 9553NB BO4556 P/N:210034-7 Part No.: 210034-7
• 018: MAKITA BAFFLE PLATE FOR GA4030 Part No.: 450796-7
• 019: MAKITA TAPPING SCREW 4X70 FOR 9553NB HR2810 P/N:266325-4 Part No.: 266325-4
• 022: MAKITA TAPPING SCREW 3X8 P/N:266492-5 Part No.: 266492-5
• 023: MAKITA BRUSH HOLDER FOR GA4030 P/N:643839-4 Part No.: 643839-4
• 025: MAKITA SWITCH DPX-2110-R DOUBLE FOR 9556NB P/N:650621-4 Part No.: 650621-4
• 026: MAKITA STRAIN RELIEF FOR GA4030 P/N:687681-3 Part No.: 687681-3
• 029: MAKITA CORD GUARD FOR MT410 BO4556 P/N:682569-2 Part No.: 682569-2
• 030: MAKITA POWER S.CORD BASEC CORD P/N:692021-2 Part No.: 692021-2
• 032: MAKITA REAR COVER FOR GA4030 P/N:450794-1 Part No.: 450794-1
• 033: MAKITA SWITCH LEVER FOR GA4030 P/N:450797-5 Part No.: 450797-5
• 034: MAKITA SPRING 4 FOR DC/AC-GA P/N:233121-5 Part No.: 233121-5
• 035: MAKITA MOTOR HOUSING FOR GA4030 P/N:450795-9 Part No.: 450795-9
• 036: MAKITA SWITCH KNOB FOR 9556NB P/N:419566-3 Part No.: 419566-3
• 037: MAKITA O RING 4 P/N:213032-0 Part No.: 213032-0
• 038: MAKITA SHOULDER PIN 4 FOR GA4030 P/N:256510-7 Part No.: 256510-7
• 039: MAKITA GEAR HOUSING COMPLETE FOR PJ7000 P/N:141327-0 Part No.: 141327-0
• 041: MAKITA RING SPRING 11 FOR 9553HN P/N:233950-6 Part No.: 233950-6
• 042: MAKITA SPIRAL BEVEL GEAR 37 FOR GA4030 P/N:227546-3 Part No.: 227546-3
• 043: MAKITA RETAINING RING R-32 P/N:962151-6 Part No.: 962151-6
• 045: MAKITA SPINDLE FOR PJ7000 P/N:326120-5 Part No.: 326120-5
• 046: MAKITA O RING 42 FOR GA4030 P/N:213561-3 Part No.: 213561-3
• 047: MAKITA BEARING BOX FOR PJ7000 P/N:318811-2 Part No.: 318811-2
• 048: MAKITA PAN HEAD SCREW M4X20 FOR N1900B P/N:911136-9 Part No.: 911136-9
• 049: MAKITA PAN HEAD SCREW M4X20 FOR N1900B P/N:911136-9 Part No.: 911136-9
• 050: MAKITA HEX. NUT M5 FOR JS3200 P/N:931203-4 Part No.: 931203-4
