MAKITA LS0714 SLIDE COMPOUND SAW 190MM SPARE PARTS

Spare Parts of Makita LS0714 Slide Compound Saw Ref. No. Part Name & Number Price 001 MAKITA PAN HEAD SCREW M5X18 FOR 1100 P/N:911228-4 Part No.: 911228-4 $0.33 Add To Cart 002 MAKITA FLAT WASHER 5 FOR LS1040 P/N:267136-0 Part No.: 267136-0 $0.33 Add To Cart 004 MAKITA '+FLAT HEAD SCREW M5 FOR LS1013 P/N:265008-3 Part No.: 265008-3 $0.33 Add To Cart 005 MAKITA HEX.BOLT M6X18MM FOR LS0714 Part No.: 265461-3 $0.44 Add To Cart 006 MAKITA INNER FLANGE 40 FOR LS0714 P/N:224397-5 Part No.: 224397-5 $3.05 Add To Cart 008 MAKITA SPINDLE FOR LS0714 Part No.: 323798-5 $5.12 Add To Cart 010 MAKITA BEARING BOX FOR LS0711B P/N:317037-3 Part No.: 317037-3 $3.05 Add To Cart 011 MAKITA O RING 42 FOR LS0714 P/N:213565-5 Part No.: 213565-5 $0.65 Add To Cart 012 MAKITA RING 12 FOR LS0711B P/N:257010-0 Part No.: 257010-0 $0.44 Add To Cart 013 MAKITA HELICAL GEAR 47 FOR LS0711B P/N:226497-7 Part No.: 226497-7 $6.43 Add To Cart 014 MAKITA BALL BEARING 607LLB FOR BTW201 / HR2410 P/N:211021-9 Part No.: 211021-9 $1.85 Add To Cart 015 MAKITA RUBBER PIN 6 P/N:263005-3 Part No.: 263005-3 $0.22 Add To Cart 017 MAKITA SPIRAL SPRING 26 FOR LS0711B P/N:231934-8 Part No.: 231934-8 $0.44 Add To Cart 019 MAKITA HEX.BOLT M6X14 FOR LS0711B P/N:265473-6 Part No.: 265473-6 $0.55 Add To Cart 020 MAKITA CENTER COVER FOR LS0711B P/N:344641-5 Part No.: 344641-5 $1.42 Add To Cart 022 MAKITA OUTER FLANGE 40 FOR LS0711B P/N:224282-2 Part No.: 224282-2 $3.27 Add To Cart 023 MAKITA PAN HEAD SCREW M5X16 FOR LS1040 P/N:911223-4 Part No.: 911223-4 $0.33 Add To Cart 024 MAKITA HEX. SOCKET HEAD BOLT M6X20 FOR LS1013 P/N:922331-6 Part No.: 922331-6 $0.55 Add To Cart 025 MAKITA FLAT WASHER 6 FOR 6095DWE P/N:253804-1 Part No.: 253804-1 $0.33 Add To Cart 026 MAKITA RING 6 FOR LS1013 Part No.: 257163-5 $0.33 Add To Cart 028 MAKITA RING 6 FOR LS1013 Part No.: 257163-5 $0.33 Add To Cart 029 MAKITA FLAT WASHER 6 FOR 6095DWE P/N:253804-1 Part No.: 253804-1 $0.33 Add To Cart 030 MAKITA STOP RING E-5 FOR 4300BV P/N:961018-5 Part No.: 961018-5 $0.11 Add To Cart 032 MAKITA O RING 35 FOR HM1201 P/N:213460-9 Part No.: 213460-9 $0.44 Add To Cart 035 MAKITA HEX.BOLT M6X16 FOR LS0711B P/N:265381-1 Part No.: 265381-1 $0.98 Add To Cart 036 MAKITA URETHANE RING 5 FOR 6905B P/N:262001-8 Part No.: 262001-8 $0.87 Add To Cart 039 MAKITA PAN HEAD SCREW M4X10 FOR 3700B P/N:911113-1 Part No.: 911113-1 $0.22 Add To Cart 072 MAKITA TAPPING SCREW FLANGE PT 5X50 FOR HR3000C P/N:266046-8 Part No.: 266046-8 $0.55 Add To Cart 073 MAKITA RUBBER PIN 4 P/N:263002-9 Part No.: 263002-9 $0.11 Add To Cart 074 MAKITA BALL BEARING 6001LLB FOR 9218PB P/N:211101-1 Part No.: 211101-1 $3.82 Add To Cart 075 MAKITA RUBBER PIN 4 P/N:263002-9 Part No.: 263002-9 $0.11 Add To Cart 076 MAKITA COMPRESSION SPRING 5 FOR 5806B P/N:233092-6 Part No.: 233092-6 $0.22 Add To Cart 077 MAKITA SHAFT LOCK FOR LS0711B P/N:344642-3 Part No.: 344642-3 $1.42 Add To Cart 079 MAKITA ARMATURE ASS'Y 240V FOR LS0714 P/N:510060-9 Part No.: 510060-9 $48.51 Add To Cart 080 MAKITA INSULATED WASHER FOR UB1100 P/N:681644-1 Part No.: 681644-1 $0.33 Add To Cart 082 MAKITA URETHANE WASHER 18 FOR LS0711B P/N:261110-0 Part No.: 261110-0 $1.53 Add To Cart 083 MAKITA BAFFLE PLATE FOR LS0711B P/N:416537-1 Part No.: 416537-1 $2.40 Add To Cart 085 MAKITA *SUPPORT CPL FOR LS0714 P/N:638360-6 Part No.: 638360-6 $6.21 Add To Cart 088 MAKITA CORD GUARD 9.3-90 FOR LS1040 P/N:682540-6 Part No.: 682540-6 $0.76 Add To Cart 090 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 091 MAKITA MOTOR HOUSING COMPLETE FOR LS0711B P/N:151900-8 Part No.: 151900-8 $13.73 Add To Cart 093 MAKITA PAN HEAD SCREW M5X50 FOR 2414B P/N:911273-9 Part No.: 911273-9 $0.33 Add To Cart 095 MAKITA BRUSH HOLDER CAP FOR 4100NH/PV7000C P/N:643750-0 Part No.: 643750-0 $0.44 Add To Cart 097 MAKITA SWITCH TG71B FOR 2414B/HR4000C P/N:651922-3 Part No.: 651922-3 $9.70 Add To Cart 103 MAKITA LOCK OFF LEVER FOR LS0711B P/N:416533-9 Part No.: 416533-9 $0.55 Add To Cart 104 MAKITA COMPRESSION SPRING 4 FOR 8416 P/N:231026-3 Part No.: 231026-3 $0.22 Add To Cart 105 MAKITA PAN HEAD SCREW M5X50 FOR 2414B P/N:911273-9 Part No.: 911273-9 $0.33 Add To Cart 107 MAKITA SWITCH BUTTON FOR 2414NB P/N:411478-6 Part No.: 411478-6 $0.44 Add To Cart 110 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 116 MAKITA SCREW M6X10 FOR 2414B P/N:251887-5 Part No.: 251887-5 $0.76 Add To Cart 117 MAKITA SLEEVE 17 FOR LS0711B P/N:416535-5 Part No.: 416535-5 $1.42 Add To Cart 118 MAKITA TORSION SPRING 28 FOR LS0711B P/N:231638-2 Part No.: 231638-2 $6.10 Add To Cart 119 MAKITA SLEEVE 17 FOR LS0711B P/N:416535-5 Part No.: 416535-5 $1.42 Add To Cart 120 MAKITA SCREW M6X33 FOR LS0711B P/N:251897-2 Part No.: 251897-2 $1.42 Add To Cart 121 MAKITA COMPRESSION SPRING 6 FOR LS0711B P/N:231325-3 Part No.: 231325-3 $0.22 Add To Cart 124 MAKITA HEX.SOCKET HEAD BOLT M6X8 FOR LS0714 P/N:266208-8 Part No.: 266208-8 $0.65 Add To Cart 126 MAKITA TAPPING SCREW BIND CT 4X12 FOR 5806B P/N:266026-4 Part No.: 266026-4 $0.33 Add To Cart 128 MAKITA TAPPING SCREW BIND CT 4X12 FOR 5806B P/N:266026-4 Part No.: 266026-4 $0.33 Add To Cart 129 MAKITA PAN HEAD SCREW M4X10 FOR 3700B P/N:911113-1 Part No.: 911113-1 $0.22 Add To Cart 130 MAKITA LEVER 100 FOR LS1212 P/N:416006-2 Part No.: 416006-2 $1.31 Add To Cart 132 MAKITA HEX. NUT M10-17 FOR LS1212 P/N:252144-4 Part No.: 252144-4 $1.53 Add To Cart 133 MAKITA COMPRESSION SPRING 5 FOR LS1212 P/N:231266-3 Part No.: 231266-3 $0.33 Add To Cart 134 MAKITA FLAT WASHER 10 FOR LS1212 P/N:253024-7 Part No.: 253024-7 $0.44 Add To Cart 135 MAKITA CAP 16 FOR LS1211 P/N:286236-7 Part No.: 286236-7 $0.65 Add To Cart 136 MAKITA ARM CPL FOR LS0714 P/N:153463-0 Part No.: 153463-0 $97.01 Add To Cart 137 MAKITA RELEASE PIN FOR LS0714 P/N:324295-4 Part No.: 324295-4 $3.27 Add To Cart 138 MAKITA HEX.BOLT M6X16 FOR LS0711B P/N:265381-1 Part No.: 265381-1 $0.98 Add To Cart 140 MAKITA FLAT WASHER 6 FOR 6793D P/N:253726-5 Part No.: 253726-5 $0.22 Add To Cart 144 MAKITA TAPPING SCREW BIND CT 4X12 FOR 5806B P/N:266026-4 Part No.: 266026-4 $0.33 Add To Cart 145 MAKITA FRONT ARM CPL FOR LS0714 P/N:153462-2 Part No.: 153462-2 $82.19 Add To Cart 147 MAKITA WAVE WASHER 8 FOR LS1020/1440 Part No.: 253948-7 $0.33 Add To Cart 148 MAKITA FLAT WASHER 8 FOR LS0711B P/N:253835-0 Part No.: 253835-0 $0.33 Add To Cart 149 MAKITA '+PAN HEAD SCREW M6 FOR 3501N P/N:251267-5 Part No.: 251267-5 $0.44 Add To Cart 150 MAKITA HEX. SOCKET HEAD BOLT M6X10 FOR LS1040 P/N:251961-9 Part No.: 251961-9 $0.33 Add To Cart 151 MAKITA HEX. SOCKET HEAD BOLT M6X10 FOR LS1040 P/N:251961-9 Part No.: 251961-9 $0.33 Add To Cart 152 MAKITA KNOB 20 FOR LS1030 Part No.: 271601-3 $0.55 Add To Cart 153 MAKITA O RING 5 FOR LS1040 P/N:213021-5 Part No.: 213021-5 $0.11 Add To Cart 154 MAKITA STOPPER PIN FOR LS0714 P/N:324183-5 Part No.: 324183-5 $0.55 Add To Cart 155 MAKITA PIN 16-90 FOR LS0714 P/N:331350-5 Part No.: 331350-5 $1.64 Add To Cart 157 MAKITA PIN 5 FOR LS0711B P/N:256100-6 Part No.: 256100-6 $0.33 Add To Cart 158 MAKITA SCREW M10 FOR LS0711B P/N:266320-4 Part No.: 266320-4 $2.51 Add To Cart 159 MAKITA FLAT WASHER 10 FOR LS1212 P/N:253024-7 Part No.: 253024-7 $0.44 Add To Cart 160 MAKITA THRUST NEEDLE CAGE 1024 FOR BLS713 P/N:216413-7 Part No.: 216413-7 $1.64 Add To Cart 161 MAKITA FLAT WASHER 10 FOR LS1212 P/N:253024-7 Part No.: 253024-7 $0.44 Add To Cart 162 MAKITA HEX. LOCK NUT M10-17 FOR 2414B P/N:252130-5 Part No.: 252130-5 $0.55 Add To Cart 164 MAKITA SCREW M6X33 FOR LS0711B P/N:251897-2 Part No.: 251897-2 $1.42 Add To Cart 165 MAKITA HEX. LOCK NUT M8-13 FOR LS1212 P/N:252105-4 Part No.: 252105-4 $0.76 Add To Cart 166 MAKITA FLAT WASHER 8 FOR 2414B P/N:253731-2 Part No.: 253731-2 $0.33 Add To Cart 168 MAKITA TAPPING SCREW BIND CT 4X12 FOR 5806B P/N:266026-4 Part No.: 266026-4 $0.33 Add To Cart 169 MAKITA TAPPING SCREW BIND CT 4X12 FOR 5806B P/N:266026-4 Part No.: 266026-4 $0.33 Add To Cart 170 MAKITA TAPPING SCREW BIND CT 4X12 FOR 5806B P/N:266026-4 Part No.: 266026-4 $0.33 Add To Cart 171 MAKITA KERF BOARD FOR LS0714 P/N:417993-8 Part No.: 417993-8 $3.38 Add To Cart 172 MAKITA KERF BOARD FOR LS0714 P/N:417993-8 Part No.: 417993-8 $3.38 Add To Cart 174 MAKITA HEX. SOCKET HEAD BOLT M4X10 P/N:922111-0 Part No.: 922111-0 $0.33 Add To Cart 175 MAKITA SQUARE ROD CPL FOR LS0714 P/N:153580-6 Part No.: 153580-6 $2.73 Add To Cart 176 MAKITA HEX.BOLT M5X30 FOR LS0711B P/N:925251-3 Part No.: 925251-3 $0.33 Add To Cart 177 MAKITA TAPPING SCREW CT M4X16 P/N : 266034-5 FOR 9520B Part No.: 266034-5 $0.33 Add To Cart 179 MAKITA PIN HOLDER FOR LS0714 P/N:317616-7 Part No.: 317616-7 $2.07 Add To Cart 180 MAKITA PIN 3 FOR LS1045 Part No.: 256158-5 $0.33 Add To Cart 181 MAKITA LOCK PIN FOR LS0714 P/N:324288-1 Part No.: 324288-1 $1.31 Add To Cart 182 MAKITA COMPRESSION SPRING 6 FOR LS0711B P/N:231325-3 Part No.: 231325-3 $0.22 Add To Cart 183 MAKITA ROD 6 FOR LS0714 P/N:324289-9 Part No.: 324289-9 $0.55 Add To Cart 184 MAKITA LOCK LEVER FOR LS1045 P/N:416450-3 Part No.: 416450-3 $1.53 Add To Cart 185 MAKITA LOCK LEVER PLATE FOR LS0714 P/N:345272-3 Part No.: 345272-3 $0.44 Add To Cart 186 MAKITA TAPPING SCREW CT M4X16 P/N : 266034-5 FOR 9520B Part No.: 266034-5 $0.33 Add To Cart 187 MAKITA COMPRESSION SPRING 9 FOR LC1210 P/N:231418-6 Part No.: 231418-6 $0.33 Add To Cart 188 MAKITA FLAT WASHER 8 FOR 2414B P/N:253731-2 Part No.: 253731-2 $0.33 Add To Cart 191 MAKITA CAP 20 FOR LS1212 P/N:286212-1 Part No.: 286212-1 $0.44 Add To Cart 193 MAKITA SCREW M6X10 FOR 2414B P/N:251887-5 Part No.: 251887-5 $0.76 Add To Cart 194 MAKITA BASE CPL FOR LS0714 P/N:153949-4 Part No.: 153949-4 $72.70 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA PAN HEAD SCREW M5X18 FOR 1100 P/N:911228-4 Part No.: 911228-4
• 002: MAKITA FLAT WASHER 5 FOR LS1040 P/N:267136-0 Part No.: 267136-0
• 004: MAKITA '+FLAT HEAD SCREW M5 FOR LS1013 P/N:265008-3 Part No.: 265008-3
• 005: MAKITA HEX.BOLT M6X18MM FOR LS0714 Part No.: 265461-3
• 006: MAKITA INNER FLANGE 40 FOR LS0714 P/N:224397-5 Part No.: 224397-5
• 008: MAKITA SPINDLE FOR LS0714 Part No.: 323798-5
• 010: MAKITA BEARING BOX FOR LS0711B P/N:317037-3 Part No.: 317037-3
• 011: MAKITA O RING 42 FOR LS0714 P/N:213565-5 Part No.: 213565-5
• 012: MAKITA RING 12 FOR LS0711B P/N:257010-0 Part No.: 257010-0
• 013: MAKITA HELICAL GEAR 47 FOR LS0711B P/N:226497-7 Part No.: 226497-7
• 014: MAKITA BALL BEARING 607LLB FOR BTW201 / HR2410 P/N:211021-9 Part No.: 211021-9
• 015: MAKITA RUBBER PIN 6 P/N:263005-3 Part No.: 263005-3
• 017: MAKITA SPIRAL SPRING 26 FOR LS0711B P/N:231934-8 Part No.: 231934-8
• 019: MAKITA HEX.BOLT M6X14 FOR LS0711B P/N:265473-6 Part No.: 265473-6
• 020: MAKITA CENTER COVER FOR LS0711B P/N:344641-5 Part No.: 344641-5
• 022: MAKITA OUTER FLANGE 40 FOR LS0711B P/N:224282-2 Part No.: 224282-2
• 023: MAKITA PAN HEAD SCREW M5X16 FOR LS1040 P/N:911223-4 Part No.: 911223-4
• 024: MAKITA HEX. SOCKET HEAD BOLT M6X20 FOR LS1013 P/N:922331-6 Part No.: 922331-6
• 025: MAKITA FLAT WASHER 6 FOR 6095DWE P/N:253804-1 Part No.: 253804-1
• 026: MAKITA RING 6 FOR LS1013 Part No.: 257163-5
• 028: MAKITA RING 6 FOR LS1013 Part No.: 257163-5
• 029: MAKITA FLAT WASHER 6 FOR 6095DWE P/N:253804-1 Part No.: 253804-1
• 030: MAKITA STOP RING E-5 FOR 4300BV P/N:961018-5 Part No.: 961018-5
• 032: MAKITA O RING 35 FOR HM1201 P/N:213460-9 Part No.: 213460-9
• 035: MAKITA HEX.BOLT M6X16 FOR LS0711B P/N:265381-1 Part No.: 265381-1
• 036: MAKITA URETHANE RING 5 FOR 6905B P/N:262001-8 Part No.: 262001-8
• 039: MAKITA PAN HEAD SCREW M4X10 FOR 3700B P/N:911113-1 Part No.: 911113-1
• 072: MAKITA TAPPING SCREW FLANGE PT 5X50 FOR HR3000C P/N:266046-8 Part No.: 266046-8
• 073: MAKITA RUBBER PIN 4 P/N:263002-9 Part No.: 263002-9
• 074: MAKITA BALL BEARING 6001LLB FOR 9218PB P/N:211101-1 Part No.: 211101-1
• 075: MAKITA RUBBER PIN 4 P/N:263002-9 Part No.: 263002-9
• 076: MAKITA COMPRESSION SPRING 5 FOR 5806B P/N:233092-6 Part No.: 233092-6
• 077: MAKITA SHAFT LOCK FOR LS0711B P/N:344642-3 Part No.: 344642-3
• 079: MAKITA ARMATURE ASS'Y 240V FOR LS0714 P/N:510060-9 Part No.: 510060-9
• 080: MAKITA INSULATED WASHER FOR UB1100 P/N:681644-1 Part No.: 681644-1
• 082: MAKITA URETHANE WASHER 18 FOR LS0711B P/N:261110-0 Part No.: 261110-0
• 083: MAKITA BAFFLE PLATE FOR LS0711B P/N:416537-1 Part No.: 416537-1
• 085: MAKITA *SUPPORT CPL FOR LS0714 P/N:638360-6 Part No.: 638360-6
• 088: MAKITA CORD GUARD 9.3-90 FOR LS1040 P/N:682540-6 Part No.: 682540-6
