MAKITA HS7010 CIRCULAR SAW SPARE PARTS

Spare Parts of Makita HS70100 Circular Saw Ref. No. Part Name & Number Price 001 MAKITA HEX. SOCKET HEAD BOLT M6X20 FOR 5740NB P/N:266024-8 Part No.: 266024-8 $0.44 Add To Cart 002 MAKITA OUTER FLANGE 35 FOR 5008MG P/N:224409-4 Part No.: 224409-4 $1.64 Add To Cart 003 MAKITA INNER FLANGE 35 FOR SP/DHS/HS/DLS P/N:224593-5 Part No.: 224593-5 $1.74 Add To Cart 004 MAKITA RETAINING RING S-38 FOR 5806B P/N:961155-5 Part No.: 961155-5 $0.98 Add To Cart 005 MAKITA TAPPING SCREW CT M4X16 P/N : 266034-5 FOR 9520B Part No.: 266034-5 $0.33 Add To Cart 006 MAKITA LEVER PLATE FOR 5007NFA P/N:345931-9 Part No.: 345931-9 $0.87 Add To Cart 007 MAKITA SAFETY COVER FOR HS7600 P/N:319188-8 Part No.: 319188-8 $14.17 Add To Cart 008 MAKITA TENSION SPRING 4 FOR HS7600 P/N:231887-1 Part No.: 231887-1 $1.85 Add To Cart 009 MAKITA THICKNESS RING FOR MT580 P/N:345391-5 Part No.: 345391-5 $0.33 Add To Cart 010 MAKITA SPINDLE FOR HS7600 P/N:326444-9 Part No.: 326444-9 $3.49 Add To Cart 011 MAKITA PAN HEAD SCREW M5X18MM FOR N1900B Part No.: 911226-8 $0.33 Add To Cart 012 MAKITA BEARING BOX ASSEMBLY FOR HS7010 P/N:135947-0 Part No.: 135947-0 $3.38 Add To Cart 014 MAKITA BEARING RETAINER 19-33 FOR MT412 P/N:285852-2 Part No.: 285852-2 $0.98 Add To Cart 015 MAKITA RING 12 FOR 5806B P/N:257173-2 Part No.: 257173-2 $0.33 Add To Cart 016 MAKITA HELICAL GEAR 43 FOR HS7010 P/N:221575-8 Part No.: 221575-8 $4.36 Add To Cart 017 MAKITA RETAINING RING S-12 P/N:961052-5 Part No.: 961052-5 $0.33 Add To Cart 018 MAKITA BALL BEARING 606ZZ FOR MT410 P/N:210028-2 Part No.: 210028-2 $1.20 Add To Cart 019 MAKITA O RING 44 FOR HK0500 P/N:213560-5 Part No.: 213560-5 $0.33 Add To Cart 020 MAKITA '+PAN HEAD SCREW M6X20 FOR MT580 P/N:265117-8 Part No.: 265117-8 $0.33 Add To Cart 021 MAKITA RUBBER SLEEVE 6 FOR MT580 P/N:262556-3 Part No.: 262556-3 $0.44 Add To Cart 022 MAKITA BLADE CASE COMPLETE FOR HS7010 P/N:144729-9 Part No.: 144729-9 $40.11 Add To Cart 023 MAKITA COMPRESSION SPRING 6 FOR GA7010C P/N:233117-6 Part No.: 233117-6 $0.22 Add To Cart 024 MAKITA SHAFT LOCK FOR HS7010 P/N:347284-2 Part No.: 347284-2 $1.09 Add To Cart 025 MAKITA BALL BEARING 6001DDW FOR 9016B BO4556 P/N:211131-2 Part No.: 211131-2 $3.27 Add To Cart 026 MAKITA FAN 76 FOR HR4000C P/N:241876-8 Part No.: 241876-8 $2.73 Add To Cart 027 MAKITA ARMATURE ASSEMBLY 240V FOR HS7010 P/N:515434-9 Part No.: 515434-9 $39.46 Add To Cart 028 MAKITA INSULATED WASHER FOR UB1100 P/N:681644-1 Part No.: 681644-1 $0.33 Add To Cart 029 MAKITA BALL BEARING 608DDW FOR HR4000C/PV7000C P/N:210005-4 Part No.: 210005-4 $1.53 Add To Cart 030 MAKITA FLAT WASHER 14 FOR 5806B P/N:253192-6 Part No.: 253192-6 $0.33 Add To Cart 031 MAKITA RUBBER WASHER 13 FOR 5606B P/N:261109-5 Part No.: 261109-5 $0.44 Add To Cart 032 MAKITA BAFFLE PLATE FOR HS7010 P/N:458033-3 Part No.: 458033-3 $0.76 Add To Cart 033 MAKITA TAPPING SCREW 5X65 FOR MT910 P/N:266352-1 Part No.: 266352-1 $0.33 Add To Cart 034 MAKITA FIELD ASSY 220-240V FOR HS7010 P/N:594679-2 Part No.: 594679-2 $20.71 Add To Cart 037 MAKITA PAN HEAD SCREW M5X40 FOR MT410 P/N:265104-7 Part No.: 265104-7 $0.33 Add To Cart 038 MAKITA BRUSH HOLDER CAP FOR 4100NH/PV7000C P/N:643750-0 Part No.: 643750-0 $0.44 Add To Cart 040 MAKITA MOTOR HOUSING COMPLETE FOR HS7010 P/N:144728-1 Part No.: 144728-1 $16.35 Add To Cart 041 MAKITA CORD GUARD 9.3-90 FOR LS1040 P/N:682540-6 Part No.: 682540-6 $0.76 Add To Cart 042 MAKITA POWER S.CORD BS 1.0-2-2.5 P/N:692527-0 Part No.: 692527-0 $12.21 Add To Cart 043 MAKITA STRAIN RELIEF FOR DLM480/LM001G P/N:687124-5 Part No.: 687124-5 $0.33 Add To Cart 045 MAKITA HANDLE COVER FOR HS7010 P/N:458032-5 Part No.: 458032-5 $4.80 Add To Cart 046 MAKITA SWITCH FOR HS7600 P/N:651284-9 Part No.: 651284-9 $7.63 Add To Cart 049 MAKITA LEVER PLATE FOR MT582 P/N:346311-2 Part No.: 346311-2 $1.64 Add To Cart 050 MAKITA BOW STOP RING E-12 FOR 5008MG P/N:257953-6 Part No.: 257953-6 $0.44 Add To Cart 051 MAKITA HEX. NUT M8-13 FOR 5008MG P/N:252199-9 Part No.: 252199-9 $0.55 Add To Cart 052 MAKITA FLAT WASHER 8 P/N:941201-0 Part No.: 941201-0 $0.11 Add To Cart 054 MAKITA F.HEAD SQUARE NECK BOLT M8X24 P/N:266396-1 Part No.: 266396-1 $0.44 Add To Cart 055 MAKITA THUMB SCREW M6X12 FOR MT580 P/N:265754-8 Part No.: 265754-8 $0.44 Add To Cart 056 MAKITA BASE FOR HS7601 P/N:161773-1 Part No.: 161773-1 $12.64 Add To Cart 057 MAKITA '+PAN HEAD SCREW M5 FOR MT580 P/N:265118-6 Part No.: 265118-6 $0.44 Add To Cart 058 MAKITA SPRING WASHER 6 FOR HM0810 P/N:942151-2 Part No.: 942151-2 $0.11 Add To Cart 059 MAKITA FLAT WASHER 6 FOR HM0810 P/N:941151-9 Part No.: 941151-9 $0.11 Add To Cart 060 MAKITA HEX. LOCK NUT M5-8 P/N:252103-8 Part No.: 252103-8 $0.33 Add To Cart 061 MAKITA THUMB SCREW M6X12 FOR MT580 P/N:265754-8 Part No.: 265754-8 $0.44 Add To Cart 062 MAKITA SPRING 8 FOR DC/AC-GA/HS P/N:233376-2 Part No.: 233376-2 $0.11 Add To Cart 063 MAKITA FLAT WASHER 6 FOR HM0810 P/N:941151-9 Part No.: 941151-9 $0.11 Add To Cart 064 MAKITA SPRING WASHER 6 FOR HM0810 P/N:942151-2 Part No.: 942151-2 $0.11 Add To Cart 065 MAKITA THUMB SCREW M6X12 FOR MT580 P/N:265754-8 Part No.: 265754-8 $0.44 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA HEX. SOCKET HEAD BOLT M6X20 FOR 5740NB P/N:266024-8 Part No.: 266024-8
• 002: MAKITA OUTER FLANGE 35 FOR 5008MG P/N:224409-4 Part No.: 224409-4
• 003: MAKITA INNER FLANGE 35 FOR SP/DHS/HS/DLS P/N:224593-5 Part No.: 224593-5
• 004: MAKITA RETAINING RING S-38 FOR 5806B P/N:961155-5 Part No.: 961155-5
• 005: MAKITA TAPPING SCREW CT M4X16 P/N : 266034-5 FOR 9520B Part No.: 266034-5
• 006: MAKITA LEVER PLATE FOR 5007NFA P/N:345931-9 Part No.: 345931-9
• 007: MAKITA SAFETY COVER FOR HS7600 P/N:319188-8 Part No.: 319188-8
• 008: MAKITA TENSION SPRING 4 FOR HS7600 P/N:231887-1 Part No.: 231887-1
• 009: MAKITA THICKNESS RING FOR MT580 P/N:345391-5 Part No.: 345391-5
• 010: MAKITA SPINDLE FOR HS7600 P/N:326444-9 Part No.: 326444-9
• 011: MAKITA PAN HEAD SCREW M5X18MM FOR N1900B Part No.: 911226-8
• 012: MAKITA BEARING BOX ASSEMBLY FOR HS7010 P/N:135947-0 Part No.: 135947-0
• 014: MAKITA BEARING RETAINER 19-33 FOR MT412 P/N:285852-2 Part No.: 285852-2
• 015: MAKITA RING 12 FOR 5806B P/N:257173-2 Part No.: 257173-2
• 016: MAKITA HELICAL GEAR 43 FOR HS7010 P/N:221575-8 Part No.: 221575-8
• 017: MAKITA RETAINING RING S-12 P/N:961052-5 Part No.: 961052-5
• 018: MAKITA BALL BEARING 606ZZ FOR MT410 P/N:210028-2 Part No.: 210028-2
• 019: MAKITA O RING 44 FOR HK0500 P/N:213560-5 Part No.: 213560-5
• 020: MAKITA '+PAN HEAD SCREW M6X20 FOR MT580 P/N:265117-8 Part No.: 265117-8
• 021: MAKITA RUBBER SLEEVE 6 FOR MT580 P/N:262556-3 Part No.: 262556-3
• 022: MAKITA BLADE CASE COMPLETE FOR HS7010 P/N:144729-9 Part No.: 144729-9
• 023: MAKITA COMPRESSION SPRING 6 FOR GA7010C P/N:233117-6 Part No.: 233117-6
• 024: MAKITA SHAFT LOCK FOR HS7010 P/N:347284-2 Part No.: 347284-2
• 025: MAKITA BALL BEARING 6001DDW FOR 9016B BO4556 P/N:211131-2 Part No.: 211131-2
• 026: MAKITA FAN 76 FOR HR4000C P/N:241876-8 Part No.: 241876-8
• 027: MAKITA ARMATURE ASSEMBLY 240V FOR HS7010 P/N:515434-9 Part No.: 515434-9
• 028: MAKITA INSULATED WASHER FOR UB1100 P/N:681644-1 Part No.: 681644-1
• 029: MAKITA BALL BEARING 608DDW FOR HR4000C/PV7000C P/N:210005-4 Part No.: 210005-4
• 030: MAKITA FLAT WASHER 14 FOR 5806B P/N:253192-6 Part No.: 253192-6
• 031: MAKITA RUBBER WASHER 13 FOR 5606B P/N:261109-5 Part No.: 261109-5
• 032: MAKITA BAFFLE PLATE FOR HS7010 P/N:458033-3 Part No.: 458033-3
• 033: MAKITA TAPPING SCREW 5X65 FOR MT910 P/N:266352-1 Part No.: 266352-1
• 034: MAKITA FIELD ASSY 220-240V FOR HS7010 P/N:594679-2 Part No.: 594679-2
• 037: MAKITA PAN HEAD SCREW M5X40 FOR MT410 P/N:265104-7 Part No.: 265104-7
• 038: MAKITA BRUSH HOLDER CAP FOR 4100NH/PV7000C P/N:643750-0 Part No.: 643750-0
• 040: MAKITA MOTOR HOUSING COMPLETE FOR HS7010 P/N:144728-1 Part No.: 144728-1
• 041: MAKITA CORD GUARD 9.3-90 FOR LS1040 P/N:682540-6 Part No.: 682540-6
• 042: MAKITA POWER S.CORD BS 1.0-2-2.5 P/N:692527-0 Part No.: 692527-0
• 043: MAKITA STRAIN RELIEF FOR DLM480/LM001G P/N:687124-5 Part No.: 687124-5
