MAKITA HR2470 ROTARY HAMMER 24MM SPARE PARTS

Spare Parts of Makita HR2470 Rotary Hammer Ref. No. Part Name & Number Price 001 MAKITA CAP 35 FOR HR2020 HR2810 P/N:286263-4 Part No.: 286263-4 $0.76 Add To Cart 002 MAKITA RING SPRING 19 FOR HR2453 HR2810 P/N:233940-9 Part No.: 233940-9 $0.33 Add To Cart 003 MAKITA CHUCK COVER FOR HR2020 HR2810 P/N:417629-9 Part No.: 417629-9 $0.44 Add To Cart 004 MAKITA RING 21 FOR HR2020 HR2810 P/N:257241-1 Part No.: 257241-1 $1.09 Add To Cart 005 MAKITA GUIDE WASHER FOR HR2020 HR2810 P/N:345187-4 Part No.: 345187-4 $0.65 Add To Cart 006 MAKITA CONICAL COMP.SPRING 21-20 /HR2020 HR2810 P/N:233916-6 Part No.: 233916-6 $0.33 Add To Cart 007 MAKITA HEX BOLT M8X120 FOR HR2020 P/N:921923-8 Part No.: 921923-8 $0.98 Add To Cart 008 MAKITA HEX. WASHER FOR HP2050 P/N:345280-4 Part No.: 345280-4 $0.33 Add To Cart 009 MAKITA GRIP BASE FOR HR2450 P/N:417630-4 Part No.: 417630-4 $1.42 Add To Cart 010 MAKITA GRIP 36 COMPLETE FOR HR2470 P/N:158057-6 Part No.: 158057-6 $3.92 Add To Cart 013 MAKITA CHANGE LEVER FOR HR2470 P/N:162245-9 Part No.: 162245-9 $1.64 Add To Cart 014 MAKITA COMPRESSION SPRING 3 FOR HR2470 Part No.: 233459-8 $0.11 Add To Cart 015 MAKITA LOCK BUTTON FOR HR2470 Part No.: 419192-8 $0.44 Add To Cart 016 MAKITA O RING 17 FOR HR2020 P/N:213278-8 Part No.: 213278-8 $0.33 Add To Cart 017 MAKITA GEAR HOUSING COMPLETE FOR HR2470 P/N:158216-2 Part No.: 158216-2 $13.52 Add To Cart 018 MAKITA PAN HEAD SCREW M4X35 P/N:266351-3 Part No.: 266351-3 $0.33 Add To Cart 019 MAKITA NEEDLE BEARING COMPLETE FOR HR2020 P/N:153290-5 Part No.: 153290-5 $4.58 Add To Cart 020 MAKITA RING SPRING 29 FOR HR2453 P/N:233929-7 Part No.: 233929-7 $0.11 Add To Cart 022 MAKITA COMPRESSION SPRING 32 FOR HR4001C P/N:233401-9 Part No.: 233401-9 $0.55 Add To Cart 023 MAKITA SPUR GEAR 51 FOR HR2453 P/N:227109-5 Part No.: 227109-5 $5.89 Add To Cart 024 MAKITA STEEL BALL 7.0 FOR HR3000C HR2810 P/N:216022-2 Part No.: 216022-2 $0.11 Add To Cart 026 MAKITA FLAT WASHER 28 FOR HR2020 P/N:267229-3 Part No.: 267229-3 $0.44 Add To Cart 027 MAKITA SLEEVE 9 FOR HR2470 HR2810 P/N:331769-8 Part No.: 331769-8 $1.96 Add To Cart 028 MAKITA IMPACT BOLT FOR HR2453 HR2810 P/N:324669-9 Part No.: 324669-9 $1.96 Add To Cart 029 MAKITA RING 10 FOR HR2453 HR2810 P/N:324402-9 Part No.: 324402-9 $1.53 Add To Cart 030 MAKITA CUSHION RING 13 FOR HR2453 HR2810 P/N:421955-0 Part No.: 421955-0 $0.76 Add To Cart 031 MAKITA O RING CASE FOR HR2020 HR2810 P/N:324216-6 Part No.: 324216-6 $2.94 Add To Cart 032 MAKITA O RING 9 FOR HR2020 HR2810 P/N:213073-6 Part No.: 213073-6 $0.44 Add To Cart 033 MAKITA RING SPRING 28 FOR HR2810 P/N:233917-4 Part No.: 233917-4 $0.33 Add To Cart 034 MAKITA STRIKER FOR HR2470 HR2810 P/N:324733-6 Part No.: 324733-6 $2.51 Add To Cart 035 MAKITA O RING 16 FOR HR2020 HR2810 P/N:213227-5 Part No.: 213227-5 $0.55 Add To Cart 036 MAKITA PISTON CYLINDER FOR HR2470 P/N:318132-2 Part No.: 318132-2 $15.26 Add To Cart 037 MAKITA FLAT WASHER 12 FOR HR2400 P/N:267104-3 Part No.: 267104-3 $0.11 Add To Cart 038 MAKITA PISTON JOINT FOR HR2020 P/N:324215-8 Part No.: 324215-8 $0.87 Add To Cart 039 MAKITA FLAT WASHER 12 FOR HR2400 P/N:267104-3 Part No.: 267104-3 $0.11 Add To Cart 040 MAKITA O-RING 63 FOR HR2453 P/N:213727-5 Part No.: 213727-5 $0.87 Add To Cart 042 MAKITA RETAINING RING S-7 FOR MT110/N1923B P/N:961003-8 Part No.: 961003-8 $0.11 Add To Cart 043 MAKITA COMPRESSION SPRING 7 FOR HR2450 P/N:233343-7 Part No.: 233343-7 $0.22 Add To Cart 045 MAKITA CAM SHAFT FOR HR2453 P/N:324668-1 Part No.: 324668-1 $10.36 Add To Cart 046 MAKITA SWASH BEARING 10 FOR HR2020 P/N:219014-0 Part No.: 219014-0 $11.66 Add To Cart 047 MAKITA HELICAL GEAR 26 FOR HR2470 P/N:226656-3 Part No.: 226656-3 $4.36 Add To Cart 048 MAKITA HEX SOCKET HEAD BOLT M4X12 FOR HR2020 P/N:266273-7 Part No.: 266273-7 $0.44 Add To Cart 049 MAKITA BEARING RETAINER FOR HR2020 P/N:345179-3 Part No.: 345179-3 $0.55 Add To Cart 050 MAKITA FLAT WASHER 8 FOR HR2020 P/N:267234-0 Part No.: 267234-0 $0.33 Add To Cart 052 MAKITA RING 8 FOR HR2020 P/N:324212-4 Part No.: 324212-4 $0.76 Add To Cart 053 MAKITA STOP RING E-4 FOR HR3850 P/N:961011-9 Part No.: 961011-9 $0.11 Add To Cart 054 MAKITA COMPRESSION SPRING 6 FOR HR2450 P/N:233342-9 Part No.: 233342-9 $0.11 Add To Cart 055 MAKITA CHANGE PLATE FOR HR2450 P/N:345363-0 Part No.: 345363-0 $0.98 Add To Cart 059 MAKITA OIL SEAL 10 FOR HR2470 P/N:213077-8 Part No.: 213077-8 $1.96 Add To Cart 061 MAKITA FLAT WASHER 10 FOR HR2470 P/N:267213-8 Part No.: 267213-8 $0.33 Add To Cart 062 MAKITA FAN 64 FOR HR2470 P/N:240092-9 Part No.: 240092-9 $0.87 Add To Cart 063 MAKITA ARMATURE ASS'Y 240V FOR HR2470 P/N:515289-2 Part No.: 515289-2 $29.21 Add To Cart 065 MAKITA BALL BEARING 627DDW FOR GD0800C HR2810 P/N:210023-2 Part No.: 210023-2 $2.07 Add To Cart 066 MAKITA WAVE WASHER 15 FOR HR2470 P/N:267804-5 Part No.: 267804-5 $0.33 Add To Cart 067 MAKITA TAPPING SCREW 4X60 FOR MT190 P/N:266334-3 Part No.: 266334-3 $0.33 Add To Cart 068 MAKITA RETAINER FOR HR2470 Part No.: 344871-8 $0.33 Add To Cart 069 MAKITA BAFFLE PLATE FOR HR2460 Part No.: 419716-0 $0.44 Add To Cart 070 MAKITA FIELD 240V FOR HR2470 P/N:626579-9 Part No.: 626579-9 $20.60 Add To Cart 071 MAKITA MOTOR HOUSING FOR HR2470 P/N:419731-4 Part No.: 419731-4 $9.92 Add To Cart 073 MAKITA CARBON BRUSH CB-325 Part No.: 194074-2 $1.90 Add To Cart 074 MAKITA BRUSH HOLDER UNIT FOR HR2470 P/N:638500-6 Part No.: 638500-6 $8.18 Add To Cart 075 MAKITA SWITCH C3VA-2L FOR HR2470 P/N:650589-4 Part No.: 650589-4 $14.50 Add To Cart 077 MAKITA CORD GUARD 10 FOR HR2020 P/N:682566-8 Part No.: 682566-8 $0.76 Add To Cart 078 MAKITA POWER S.CORD BS 1.0-2-2.5 P/N:692527-0 Part No.: 692527-0 $12.21 Add To Cart 079 MAKITA CORD CLAMP FOR GA5010 P/N:687260-7 Part No.: 687260-7 $0.33 Add To Cart 080 MAKITA TAPPING SCREW 4X22MM FOR GA4030 Part No.: 266324-6 $0.11 Add To Cart 082 MAKITA HANDLE COVER FOR HR2470 P/N:419717-8 Part No.: 419717-8 $5.56 Add To Cart 083 MAKITA TAPPING SCREW 4X22MM FOR GA4030 Part No.: 266324-6 $0.11 Add To Cart 084 MAKITA TAPPING SCREW 4X22MM FOR GA4030 Part No.: 266324-6 $0.11 Add To Cart 085 MAKITA STOP RING E-3 FOR 4304 P/N:961017-7 Part No.: 961017-7 $0.11 Add To Cart 086 MAKITA GUIDE BASE FOR HR2470 Part No.: 417796-0 $0.44 Add To Cart 087 MAKITA COMPRESSION SPRING 4 FOR HR2470 Part No.: 233344-5 $0.11 Add To Cart 088 MAKITA TAPPING SCREW 4X25 FOR GA7020 Part No.: 266374-1 $0.11 Add To Cart 089 MAKITA LOCKING PLATE FOR HR2470 Part No.: 163430-7 $1.42 Add To Cart 090 MAKITA SPUR GEAR 10 FOR HR2470 P/N:227179-4 Part No.: 227179-4 $6.76 Add To Cart 091 MAKITA FLAT WASHER 5 FOR 4100NH P/N:941102-2 Part No.: 941102-2 $0.22 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA CAP 35 FOR HR2020 HR2810 P/N:286263-4 Part No.: 286263-4
• 002: MAKITA RING SPRING 19 FOR HR2453 HR2810 P/N:233940-9 Part No.: 233940-9
• 003: MAKITA CHUCK COVER FOR HR2020 HR2810 P/N:417629-9 Part No.: 417629-9
• 004: MAKITA RING 21 FOR HR2020 HR2810 P/N:257241-1 Part No.: 257241-1
• 005: MAKITA GUIDE WASHER FOR HR2020 HR2810 P/N:345187-4 Part No.: 345187-4
• 006: MAKITA CONICAL COMP.SPRING 21-20 /HR2020 HR2810 P/N:233916-6 Part No.: 233916-6
• 007: MAKITA HEX BOLT M8X120 FOR HR2020 P/N:921923-8 Part No.: 921923-8
• 008: MAKITA HEX. WASHER FOR HP2050 P/N:345280-4 Part No.: 345280-4
• 009: MAKITA GRIP BASE FOR HR2450 P/N:417630-4 Part No.: 417630-4
• 010: MAKITA GRIP 36 COMPLETE FOR HR2470 P/N:158057-6 Part No.: 158057-6
• 013: MAKITA CHANGE LEVER FOR HR2470 P/N:162245-9 Part No.: 162245-9
• 014: MAKITA COMPRESSION SPRING 3 FOR HR2470 Part No.: 233459-8
• 015: MAKITA LOCK BUTTON FOR HR2470 Part No.: 419192-8
• 016: MAKITA O RING 17 FOR HR2020 P/N:213278-8 Part No.: 213278-8
• 017: MAKITA GEAR HOUSING COMPLETE FOR HR2470 P/N:158216-2 Part No.: 158216-2
• 018: MAKITA PAN HEAD SCREW M4X35 P/N:266351-3 Part No.: 266351-3
• 019: MAKITA NEEDLE BEARING COMPLETE FOR HR2020 P/N:153290-5 Part No.: 153290-5
• 020: MAKITA RING SPRING 29 FOR HR2453 P/N:233929-7 Part No.: 233929-7
• 022: MAKITA COMPRESSION SPRING 32 FOR HR4001C P/N:233401-9 Part No.: 233401-9
• 023: MAKITA SPUR GEAR 51 FOR HR2453 P/N:227109-5 Part No.: 227109-5
• 024: MAKITA STEEL BALL 7.0 FOR HR3000C HR2810 P/N:216022-2 Part No.: 216022-2
• 026: MAKITA FLAT WASHER 28 FOR HR2020 P/N:267229-3 Part No.: 267229-3
• 027: MAKITA SLEEVE 9 FOR HR2470 HR2810 P/N:331769-8 Part No.: 331769-8
• 028: MAKITA IMPACT BOLT FOR HR2453 HR2810 P/N:324669-9 Part No.: 324669-9
• 029: MAKITA RING 10 FOR HR2453 HR2810 P/N:324402-9 Part No.: 324402-9
• 030: MAKITA CUSHION RING 13 FOR HR2453 HR2810 P/N:421955-0 Part No.: 421955-0
• 031: MAKITA O RING CASE FOR HR2020 HR2810 P/N:324216-6 Part No.: 324216-6
• 032: MAKITA O RING 9 FOR HR2020 HR2810 P/N:213073-6 Part No.: 213073-6
• 033: MAKITA RING SPRING 28 FOR HR2810 P/N:233917-4 Part No.: 233917-4
• 034: MAKITA STRIKER FOR HR2470 HR2810 P/N:324733-6 Part No.: 324733-6
• 035: MAKITA O RING 16 FOR HR2020 HR2810 P/N:213227-5 Part No.: 213227-5
• 036: MAKITA PISTON CYLINDER FOR HR2470 P/N:318132-2 Part No.: 318132-2
• 037: MAKITA FLAT WASHER 12 FOR HR2400 P/N:267104-3 Part No.: 267104-3
• 038: MAKITA PISTON JOINT FOR HR2020 P/N:324215-8 Part No.: 324215-8
• 039: MAKITA FLAT WASHER 12 FOR HR2400 P/N:267104-3 Part No.: 267104-3
• 040: MAKITA O-RING 63 FOR HR2453 P/N:213727-5 Part No.: 213727-5
• 042: MAKITA RETAINING RING S-7 FOR MT110/N1923B P/N:961003-8 Part No.: 961003-8
• 043: MAKITA COMPRESSION SPRING 7 FOR HR2450 P/N:233343-7 Part No.: 233343-7
• 045: MAKITA CAM SHAFT FOR HR2453 P/N:324668-1 Part No.: 324668-1
