MAKITA HM1213C DEMOLITION HAMMER SPARE PARTS

Spare Parts of Makita HM1213C Demolition Hammer Ref. No. Part Name & Number Price 001 MAKITA TOOL HOLDER CAP FOR HM1213C P/N:424165-8 Part No.: 424165-8 $2.51 Add To Cart 002 MAKITA RING SPRING 26 FOR HM1203C P/N:233973-4 Part No.: 233973-4 $0.98 Add To Cart 003 MAKITA FLAT WASHER 30 FOR HM1213C P/N:267386-7 Part No.: 267386-7 $6.00 Add To Cart 004 MAKITA CHUCK COVER FOR HM1214C P/N:450894-7 Part No.: 450894-7 $2.40 Add To Cart 005 MAKITA RUBBER RING 30 FOR HM1203C P/N:262147-0 Part No.: 262147-0 $4.03 Add To Cart 006 MAKITA CHUCK RING FOR HM1203C P/N:324987-5 Part No.: 324987-5 $17.88 Add To Cart 007 MAKITA RELEASE COVER FOR HM1203C P/N:450895-5 Part No.: 450895-5 $3.49 Add To Cart 008 MAKITA TOOL RETAINER FOR HM1213C P/N:310279-8 Part No.: 310279-8 $5.56 Add To Cart 009 MAKITA SPRING GUIDE FOR HM1203C P/N:346015-6 Part No.: 346015-6 $3.92 Add To Cart 010 MAKITA COMPRESSION SPRING 56 FOR HM1203C P/N:234086-4 Part No.: 234086-4 $0.87 Add To Cart 011 MAKITA RETAINING RING WR-45 FOR HM1202C P/N:961232-3 Part No.: 961232-3 $1.64 Add To Cart 012 MAKITA CHANGE RING COVER FOR HM1203C P/N:450893-9 Part No.: 450893-9 $3.16 Add To Cart 013 MAKITA CHANGE RING FOR HM1203C P/N:324969-7 Part No.: 324969-7 $35.43 Add To Cart 014 MAKITA LOCK RING P/N:324988-3 Part No.: 324988-3 $15.37 Add To Cart 015 MAKITA HEX. SOCKET HEAD BOLT M5X25 FOR 2702 P/N:922243-3 Part No.: 922243-3 $0.44 Add To Cart 016 MAKITA HOUSING COVER FOR HM1213C P/N:450902-4 Part No.: 450902-4 $10.25 Add To Cart 017 MAKITA RING SPRING 35 FOR HM1203C P/N:233970-0 Part No.: 233970-0 $0.76 Add To Cart 018 MAKITA BARREL COMPLETE FOR HM1213C P/N:158858-2 Part No.: 158858-2 $28.12 Add To Cart 019 MAKITA HEX. SOCKET HEAD BOLT M8X35 FOR 5500S P/N:922456-6 Part No.: 922456-6 $0.55 Add To Cart 020 MAKITA O RING 67 FOR HR2410 P/N:213720-9 Part No.: 213720-9 $0.55 Add To Cart 021 MAKITA RUBBER RING 39 FOR HM1203C P/N:262148-8 Part No.: 262148-8 $2.62 Add To Cart 022 MAKITA FLAT WASHER 39 FOR HM1203C P/N:267387-5 Part No.: 267387-5 $1.42 Add To Cart 023 MAKITA O-RING 35.5 FOR HM1205C P/N:213079-4 Part No.: 213079-4 $2.07 Add To Cart 024 MAKITA TOOL HOLDER FOR HM1214C P/N:324985-9 Part No.: 324985-9 $163.17 Add To Cart 025 MAKITA X-RING 21 FOR HM1214C P/N:213980-3 Part No.: 213980-3 $4.03 Add To Cart 026 MAKITA FLUORIDE RING 28 FOR HM1202C P/N:213431-6 Part No.: 213431-6 $14.28 Add To Cart 027 MAKITA O RING 23 FOR HM1202C P/N:213394-6 Part No.: 213394-6 $0.55 Add To Cart 028 MAKITA IMPACT BOLT P/N:324990-6 Part No.: 324990-6 $12.10 Add To Cart 029 MAKITA SHOULDER SLEEVE FOR HM1213C P/N:324993-0 Part No.: 324993-0 $5.45 Add To Cart 030 MAKITA RUBBER RING 24 FOR HM1214C P/N:262149-6 Part No.: 262149-6 $5.89 Add To Cart 031 MAKITA SHOULDER SLEEVE FOR HM1213C P/N:324993-0 Part No.: 324993-0 $5.45 Add To Cart 033 MAKITA O-RING 31.5 FOR HM1214C P/N:213499-2 Part No.: 213499-2 $4.03 Add To Cart 034 MAKITA O-RING 44 FOR HM1214C P/N:213581-7 Part No.: 213581-7 $2.18 Add To Cart 035 MAKITA ONE WAY VALVE GUIDE FOR HM1213C P/N:450889-0 Part No.: 450889-0 $0.65 Add To Cart 037 MAKITA PIN 12 FOR JR3050T P/N:268121-6 Part No.: 268121-6 $0.65 Add To Cart 038 MAKITA O-RING 31.5 FOR HM1214C P/N:213499-2 Part No.: 213499-2 $4.03 Add To Cart 039 MAKITA PISTON P/N:450961-8 Part No.: 450961-8 $8.50 Add To Cart 040 MAKITA O RING 35 P/N:213149-9 Part No.: 213149-9 $1.20 Add To Cart 041 MAKITA CONNECTING ROD P/N:450890-5 Part No.: 450890-5 $8.39 Add To Cart 042 MAKITA O RING 12 P/N:213118-0 Part No.: 213118-0 $0.33 Add To Cart 043 MAKITA PIPE HOLDER FOR HM1213C P/N:318361-7 Part No.: 318361-7 $8.94 Add To Cart 044 MAKITA O RING 12 P/N:213118-0 Part No.: 213118-0 $0.33 Add To Cart 045 MAKITA SPRING GUIDE P/N:419773-8 Part No.: 419773-8 $1.09 Add To Cart 047 MAKITA O RING 24 FOR HR1830 P/N:213953-6 Part No.: 213953-6 $0.33 Add To Cart 048 MAKITA PIPE 22 FOR HR5211C P/N:331745-2 Part No.: 331745-2 $2.73 Add To Cart 049 MAKITA O RING 24 FOR HR1830 P/N:213953-6 Part No.: 213953-6 $0.33 Add To Cart 052 MAKITA SPRING GUIDE P/N:419773-8 Part No.: 419773-8 $1.09 Add To Cart 053 MAKITA O RING 12 P/N:213118-0 Part No.: 213118-0 $0.33 Add To Cart 054 MAKITA PIPE HOLDER FOR HM1213C P/N:318361-7 Part No.: 318361-7 $8.94 Add To Cart 055 MAKITA O RING 12 P/N:213118-0 Part No.: 213118-0 $0.33 Add To Cart 056 MAKITA CRANK CAP COVER FOR HM1203C P/N:450899-7 Part No.: 450899-7 $1.42 Add To Cart 057 MAKITA PAN HEAD SCREW M4X18 FOR HM0810 P/N:911133-5 Part No.: 911133-5 $0.33 Add To Cart 058 MAKITA FILTER FOR HR4030C P/N:443127-7 Part No.: 443127-7 $0.87 Add To Cart 059 MAKITA CRANK CAP FOR HM1203C P/N:450898-9 Part No.: 450898-9 $1.74 Add To Cart 060 MAKITA SEAL RING FOR HM1203C P/N:424166-6 Part No.: 424166-6 $0.87 Add To Cart 061 MAKITA AIR PIPE FOR HM1213C P/N:450892-1 Part No.: 450892-1 $0.65 Add To Cart 062 MAKITA CRANK HOUSING FOR HM1213C P/N:318363-3 Part No.: 318363-3 $70.85 Add To Cart 063 MAKITA H.S.BOTTON HEAD SCREW M6X40 FOR HM1203C P/N:266482-8 Part No.: 266482-8 $0.44 Add To Cart 064 MAKITA FIX GUIDE FOR HR4001C P/N:419008-7 Part No.: 419008-7 $0.55 Add To Cart 065 MAKITA CUSHION PLATE P/N:423366-5 Part No.: 423366-5 $0.65 Add To Cart 066 MAKITA CRANK SHAFT P/N:324994-8 Part No.: 324994-8 $15.26 Add To Cart 067 MAKITA BALL BEARING 6206LLU P/N:211424-7 Part No.: 211424-7 $16.57 Add To Cart 068 MAKITA HELICAL GEAR 57 P/N:226691-1 Part No.: 226691-1 $11.55 Add To Cart 069 MAKITA FLAT WASHER 12 P/N:267398-0 Part No.: 267398-0 $0.65 Add To Cart 070 MAKITA SEAL RING FOR HM1203C P/N:424167-4 Part No.: 424167-4 $0.87 Add To Cart 071 MAKITA GEAR HOUSING CPL FOR HM1213C P/N:158859-0 Part No.: 158859-0 $20.06 Add To Cart 072 MAKITA OIL SEAL FOR HR4001C Part No.: 213231-4 $3.38 Add To Cart 073 MAKITA SLEEVE 12 FOR DC/AC-HR/HM P/N:331596-3 Part No.: 331596-3 $1.20 Add To Cart 074 MAKITA BALL BEARING 6302LLU FOR HM1317C P/N:211249-9 Part No.: 211249-9 $11.23 Add To Cart 075 MAKITA FLAT WASHER 15 FOR HM1203C P/N:267397-2 Part No.: 267397-2 $0.44 Add To Cart 076 MAKITA FAN 80 FOR 2012NB 5008MG P/N:240003-4 Part No.: 240003-4 $1.42 Add To Cart 077 MAKITA ARMATURE ASS'Y 220-240V FOR HM1213C P/N:517818-7 Part No.: 517818-7 $79.79 Add To Cart 078 MAKITA INSULATION WASHER FOR LS1013 P/N:681642-5 Part No.: 681642-5 $9.70 Add To Cart 080 MAKITA BAFFLE PLATE FOR HM1203C P/N:450900-8 Part No.: 450900-8 $1.20 Add To Cart 081 MAKITA TAPPING SCREW 5X55 FOR 5606B P/N:266095-5 Part No.: 266095-5 $0.65 Add To Cart 082 MAKITA FIELD 220-240V FOR HM1203/HM1213 P/N:636303-2 Part No.: 636303-2 $24.31 Add To Cart 083 MAKITA MOTOR HOUSING FOR HM1203C P/N:450904-0 Part No.: 450904-0 $16.57 Add To Cart 084 MAKITA BRUSH HOLDER UNIT FOR HR5211C P/N:638447-4 Part No.: 638447-4 $9.92 Add To Cart 086 MAKITA REAR COVER FOR HM1203C P/N:450901-6 Part No.: 450901-6 $4.91 Add To Cart 087 MAKITA TAPPING SCREW M5X25 FOR GA5010 Part No.: 266041-8 $0.44 Add To Cart 088 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 089 MAKITA TAPPING SCREW 4X14 FOR 2012NB P/N:266192-7 Part No.: 266192-7 $0.33 Add To Cart 090 MAKITA CONTROLLER FOR HM1213C P/N:631871-0 Part No.: 631871-0 $54.06 Add To Cart 091 MAKITA LEAD UNIT FOR HM1203C P/N:638650-7 Part No.: 638650-7 $6.00 Add To Cart 092 MAKITA LENS FOR HR4001C P/N:419010-0 Part No.: 419010-0 $0.87 Add To Cart 093 MAKITA COMPRESSION SPRING 11 FOR HR4011C P/N:233434-4 Part No.: 233434-4 $0.76 Add To Cart 094 MAKITA TAPPING SCREW FLANGE PT 5X30 FOR 9015B P/N:266173-1 Part No.: 266173-1 $0.44 Add To Cart 095 MAKITA FLAT WASHER 5 FOR 6095DWE P/N:253807-5 Part No.: 253807-5 $0.33 Add To Cart 096 MAKITA HANDLE BASE P/N:450905-8 Part No.: 450905-8 $11.99 Add To Cart 097 MAKITA DUST COVER SUPPORT FOR HR5211C P/N:419783-5 Part No.: 419783-5 $0.76 Add To Cart 098 MAKITA DUST COVER FOR HR5211C P/N:424001-8 Part No.: 424001-8 $3.16 Add To Cart 099 MAKITA LEAF SPRING FOR HR4001C P/N:232209-8 Part No.: 232209-8 $0.33 Add To Cart 102 MAKITA TAPPING SCREW M5X25 FOR GA5010 Part No.: 266041-8 $0.44 Add To Cart 104 MAKITA TAPPING SCREW M5X25 FOR GA5010 Part No.: 266041-8 $0.44 Add To Cart 105 MAKITA SHOULDER SLEEVE 6 P/N:313124-6 Part No.: 313124-6 $2.62 Add To Cart 106 MAKITA HANDLE FOR HM1213C P/N:450906-6 Part No.: 450906-6 $9.37 Add To Cart 108 MAKITA SWITCH FOR BO6050/DTM51/HM1205C P/N:651423-1 Part No.: 651423-1 $5.56 Add To Cart 110 MAKITA TERMINAL BLOCK 2P FOR TW1000/5008MG P/N:654531-7 Part No.: 654531-7 $0.98 Add To Cart 111 MAKITA CORD GUARD 10 FOR HR3000C P/N:682560-0 Part No.: 682560-0 $1.64 Add To Cart 113 MAKITA STRAIN RELIEF FOR HP1620 HR2810 P/N:687169-3 Part No.: 687169-3 $0.44 Add To Cart 114 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 115 MAKITA HANDLE COVER FOR HM1213C P/N:450908-2 Part No.: 450908-2 $6.32 Add To Cart 116 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 117 MAKITA HEX. BOLT M8X150 FOR HR4000C P/N:265439-6 Part No.: 265439-6 $2.83 Add To Cart 118 MAKITA SIDE HANDLE CAM FOR HM1202C P/N:417002-3 Part No.: 417002-3 $1.20 Add To Cart 120 MAKITA SPRING PIN 5-24 FOR LC1210 P/N:951166-8 Part No.: 951166-8 $0.44 Add To Cart 122 MAKITA SIDE HANDLE FOR HM1202C P/N:417003-1 Part No.: 417003-1 $15.59 Add To Cart 123 MAKITA SIDE HANDLE CAM FOR HM1202C P/N:417002-3 Part No.: 417002-3 $1.20 Add To Cart 124 MAKITA WING NUT M8 FOR HR4000C P/N:252640-2 Part No.: 252640-2 $5.45 Add To Cart 125 MAKITA FLAT WASHER 15 FOR HP2040 P/N:267164-5 Part No.: 267164-5 $0.33 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA TOOL HOLDER CAP FOR HM1213C P/N:424165-8 Part No.: 424165-8
• 002: MAKITA RING SPRING 26 FOR HM1203C P/N:233973-4 Part No.: 233973-4
• 003: MAKITA FLAT WASHER 30 FOR HM1213C P/N:267386-7 Part No.: 267386-7
• 004: MAKITA CHUCK COVER FOR HM1214C P/N:450894-7 Part No.: 450894-7
• 005: MAKITA RUBBER RING 30 FOR HM1203C P/N:262147-0 Part No.: 262147-0
• 006: MAKITA CHUCK RING FOR HM1203C P/N:324987-5 Part No.: 324987-5
• 007: MAKITA RELEASE COVER FOR HM1203C P/N:450895-5 Part No.: 450895-5
• 008: MAKITA TOOL RETAINER FOR HM1213C P/N:310279-8 Part No.: 310279-8
• 009: MAKITA SPRING GUIDE FOR HM1203C P/N:346015-6 Part No.: 346015-6
• 010: MAKITA COMPRESSION SPRING 56 FOR HM1203C P/N:234086-4 Part No.: 234086-4
• 011: MAKITA RETAINING RING WR-45 FOR HM1202C P/N:961232-3 Part No.: 961232-3
• 012: MAKITA CHANGE RING COVER FOR HM1203C P/N:450893-9 Part No.: 450893-9
• 013: MAKITA CHANGE RING FOR HM1203C P/N:324969-7 Part No.: 324969-7
• 014: MAKITA LOCK RING P/N:324988-3 Part No.: 324988-3
• 015: MAKITA HEX. SOCKET HEAD BOLT M5X25 FOR 2702 P/N:922243-3 Part No.: 922243-3
• 016: MAKITA HOUSING COVER FOR HM1213C P/N:450902-4 Part No.: 450902-4
• 017: MAKITA RING SPRING 35 FOR HM1203C P/N:233970-0 Part No.: 233970-0
• 018: MAKITA BARREL COMPLETE FOR HM1213C P/N:158858-2 Part No.: 158858-2
• 019: MAKITA HEX. SOCKET HEAD BOLT M8X35 FOR 5500S P/N:922456-6 Part No.: 922456-6
• 020: MAKITA O RING 67 FOR HR2410 P/N:213720-9 Part No.: 213720-9
• 021: MAKITA RUBBER RING 39 FOR HM1203C P/N:262148-8 Part No.: 262148-8
• 022: MAKITA FLAT WASHER 39 FOR HM1203C P/N:267387-5 Part No.: 267387-5
• 023: MAKITA O-RING 35.5 FOR HM1205C P/N:213079-4 Part No.: 213079-4
• 024: MAKITA TOOL HOLDER FOR HM1214C P/N:324985-9 Part No.: 324985-9
• 025: MAKITA X-RING 21 FOR HM1214C P/N:213980-3 Part No.: 213980-3
• 026: MAKITA FLUORIDE RING 28 FOR HM1202C P/N:213431-6 Part No.: 213431-6
• 027: MAKITA O RING 23 FOR HM1202C P/N:213394-6 Part No.: 213394-6
• 028: MAKITA IMPACT BOLT P/N:324990-6 Part No.: 324990-6
• 029: MAKITA SHOULDER SLEEVE FOR HM1213C P/N:324993-0 Part No.: 324993-0
• 030: MAKITA RUBBER RING 24 FOR HM1214C P/N:262149-6 Part No.: 262149-6
• 031: MAKITA SHOULDER SLEEVE FOR HM1213C P/N:324993-0 Part No.: 324993-0
• 033: MAKITA O-RING 31.5 FOR HM1214C P/N:213499-2 Part No.: 213499-2
• 034: MAKITA O-RING 44 FOR HM1214C P/N:213581-7 Part No.: 213581-7
• 035: MAKITA ONE WAY VALVE GUIDE FOR HM1213C P/N:450889-0 Part No.: 450889-0
• 037: MAKITA PIN 12 FOR JR3050T P/N:268121-6 Part No.: 268121-6
• 038: MAKITA O-RING 31.5 FOR HM1214C P/N:213499-2 Part No.: 213499-2
• 039: MAKITA PISTON P/N:450961-8 Part No.: 450961-8
• 040: MAKITA O RING 35 P/N:213149-9 Part No.: 213149-9
• 041: MAKITA CONNECTING ROD P/N:450890-5 Part No.: 450890-5
