MAKITA HB500 MAGNETIC DRILL SPARE PARTS

Spare Parts of Makita HB500 Magnetic Drill Ref. No. Part Name & Number Price 103 MAKITA ARMATURE 230V FOR HB500 P/N:EIB102-2 Part No.: EIB102-2 $451.15 Add To Cart 106 MAKITA CARBON BRUSH HOLDER CPL FOR HB500 P/N:EIB105 Part No.: EIB105 $26.27 Add To Cart 107 MAKITA D5000 C/BRUSH PR/CPL (1 STD/1 PUSH OFF) P/N:EIB106C Part No.: EIB106C $32.16 Add To Cart 108 MAKITA SPRING WASHER FOR HB500 P/N:EIB172 Part No.: EIB172 $2.40 Add To Cart 114 MAKITA 6001 2Z BEARING P/N:UDC023 Part No.: UDC023 $17.88 Add To Cart 117 MAKITA INTERMEDIATE GEAR FOR HB500 P/N:EIB117 Part No.: EIB117 $105.29 Add To Cart 118 MAKITA TWIN GEARED SHAFT FOR HB500 P/N:EIB007 Part No.: EIB007 $80.12 Add To Cart 119 MAKITA GEAR CHANGE ASSEMBLY FOR HB500 P/N:EIB017 Part No.: EIB017 $19.29 Add To Cart 120 MAKITA GEAR CHANGE BOLT FOR HB500 P/N:EIB008 Part No.: EIB008 $40.11 Add To Cart 122 MAKITA 6203 ZZ BEARING P/N:UDC014 Part No.: UDC014 $15.48 Add To Cart 123 MAKITA SPINDLE FOR HB500 P/N:EIB122 Part No.: EIB122 $144.97 Add To Cart 132 MAKITA MAIN GEAR FOR HB500 P/N:EIB004 Part No.: EIB004 $96.47 Add To Cart 136 MAKITA TRAILER GEAR FOR HB500 P/N:EIB131 Part No.: EIB131 $90.14 Add To Cart 138 MAKITA DOUBLE GEAR FOR HB500 P/N:EIB132 Part No.: EIB132 $150.31 Add To Cart 140 MAKITA NEEDLE BEARING P/N:UDC020 Part No.: UDC020 $14.72 Add To Cart 142 MAKITA FAN COVER FOR HB500 P/N:EIB135 Part No.: EIB135 $10.36 Add To Cart 144 MAKITA FIELD COIL 230V FOR HB500 P/N:EIB137-B Part No.: EIB137-B $169.28 Add To Cart 146 MAKITA CAPACITOR (SUPRESSSOR) P/N:EIB139 Part No.: EIB139 $14.61 Add To Cart 150 MAKITA SELF TAPPING SCREW HC2.9X9.5 for HB-500 P/N:EIB153 Part No.: EIB153 $8.28 Add To Cart 201 MAKITA MAGNET BASE (MIDI) FOR HB500 P/N:M0034 Part No.: M0034 $529.52 Add To Cart 204 MAKITA PINION - LARGE P/N:M0042 Part No.: M0042 $149.00 Add To Cart 206 MAKITA M6 X 20 CAP HEAD SCREW P/N:SC620CAP Part No.: SC620CAP $1.64 Add To Cart 207 MAKITA MINIBOR BRASS STRIP (ANGLED) P/N:60100A Part No.: 60100A $41.64 Add To Cart 215 MAKITA D5000 OIL CUP ASSEMBLY P/N:30046A Part No.: 30046A $41.86 Add To Cart 218 MAKITA M5X25 GRUB SCREW FOR HB500 STAND P/N:10085A Part No.: 10085A $2.83 Add To Cart 219 MAKITA M5 NYLOC NUT FOR HB500 STAND P/N:10085B Part No.: 10085B $3.05 Add To Cart 222 MAKITA ARBOR - QUICK RELEASE FOR HB500 P/N:BD062 Part No.: BD062 $274.79 Add To Cart 223 MAKITA HB500 SLIDE (D5000 UNIT) P/N:M0167 Part No.: M0167 $209.61 Add To Cart 224 MAKITA HB500 F/STEADY INTEGRAL OIL FEED P/N:M0516 Part No.: M0516 $160.56 Add To Cart 225 MAKITA HB500-D5000 DRILL-MAKITA BLUE-230V-0422Q P/N:EIB22 Part No.: EIB22 $773.57 Add To Cart 226 MAKITA INTEGRAL OILFEED SEAL - 2 P/N:M0050-2 Part No.: M0050-2 $10.57 Add To Cart 227 MAKITA BUSH (MB30 STEADY) P/N:M0521 Part No.: M0521 $43.38 Add To Cart 228 MAKITA INTEGRAL COOLANT SEAL - 1 P/N:M0050-1 Part No.: M0050-1 $10.57 Add To Cart 229 MAKITA 6MM PUSH FIT FITTING FOR HB500 P/N:M0066 Part No.: M0066 $6.10 Add To Cart 230 MAKITA M6X30 CAP SCREW FOR HB500 STAND P/N:SC630CAP Part No.: SC630CAP $2.62 Add To Cart 231 MAKITA PCB BOARD 230V FOR HB500 P/N:MM1-5G Part No.: MM1-5G $252.23 Add To Cart 232 MAKITA LED BOARD C/W LED'S FOR HB500 P/N:MM1-4M Part No.: MM1-4M $82.84 Add To Cart 233 MAKITA GREEN LATCHING SWITCH FOR HB500 P/N:MM1-22 Part No.: MM1-22 $15.70 Add To Cart 235 MAKITA MAGNET BUTTON - YELLOW FOR HB500 P/N:MM1-1 Part No.: MM1-1 $15.70 Add To Cart 236 MAKITA POWER BUTTON - RED FOR HB500 P/N:MM1-10 Part No.: MM1-10 $15.70 Add To Cart 237 MAKITA MM1 L.E.D. GROMMET P/N:MM1-3 Part No.: MM1-3 $3.71 Add To Cart 239 MAKITA 1/8 BSP - 6MM BLACK PUSH FIT P/N:50015C Part No.: 50015C $11.88 Add To Cart 240 MAKITA 6MM OIL PIPE P/N:BD029 Part No.: BD029 $3.38 Add To Cart 241 MAKITA CONDUIT (LARGE DIA 12MM) P/N:M0443 Part No.: M0443 $19.95 Add To Cart 242 MAKITA GUARD TO SUIT D5000 UNIT MACHINES P/N:VISO15 Part No.: VISO15 $82.73 Add To Cart 244 MAKITA M5X10 GUARD THUMBSCREW P/N:BD068 Part No.: BD068 $6.32 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 103: MAKITA ARMATURE 230V FOR HB500 P/N:EIB102-2 Part No.: EIB102-2
• 106: MAKITA CARBON BRUSH HOLDER CPL FOR HB500 P/N:EIB105 Part No.: EIB105
• 107: MAKITA D5000 C/BRUSH PR/CPL (1 STD/1 PUSH OFF) P/N:EIB106C Part No.: EIB106C
• 108: MAKITA SPRING WASHER FOR HB500 P/N:EIB172 Part No.: EIB172
• 114: MAKITA 6001 2Z BEARING P/N:UDC023 Part No.: UDC023
• 117: MAKITA INTERMEDIATE GEAR FOR HB500 P/N:EIB117 Part No.: EIB117
• 118: MAKITA TWIN GEARED SHAFT FOR HB500 P/N:EIB007 Part No.: EIB007
• 119: MAKITA GEAR CHANGE ASSEMBLY FOR HB500 P/N:EIB017 Part No.: EIB017
• 120: MAKITA GEAR CHANGE BOLT FOR HB500 P/N:EIB008 Part No.: EIB008
• 122: MAKITA 6203 ZZ BEARING P/N:UDC014 Part No.: UDC014
• 123: MAKITA SPINDLE FOR HB500 P/N:EIB122 Part No.: EIB122
• 132: MAKITA MAIN GEAR FOR HB500 P/N:EIB004 Part No.: EIB004
• 136: MAKITA TRAILER GEAR FOR HB500 P/N:EIB131 Part No.: EIB131
• 138: MAKITA DOUBLE GEAR FOR HB500 P/N:EIB132 Part No.: EIB132
• 140: MAKITA NEEDLE BEARING P/N:UDC020 Part No.: UDC020
• 142: MAKITA FAN COVER FOR HB500 P/N:EIB135 Part No.: EIB135
• 144: MAKITA FIELD COIL 230V FOR HB500 P/N:EIB137-B Part No.: EIB137-B
• 146: MAKITA CAPACITOR (SUPRESSSOR) P/N:EIB139 Part No.: EIB139
• 150: MAKITA SELF TAPPING SCREW HC2.9X9.5 for HB-500 P/N:EIB153 Part No.: EIB153
• 201: MAKITA MAGNET BASE (MIDI) FOR HB500 P/N:M0034 Part No.: M0034
• 204: MAKITA PINION - LARGE P/N:M0042 Part No.: M0042
• 206: MAKITA M6 X 20 CAP HEAD SCREW P/N:SC620CAP Part No.: SC620CAP
• 207: MAKITA MINIBOR BRASS STRIP (ANGLED) P/N:60100A Part No.: 60100A
• 215: MAKITA D5000 OIL CUP ASSEMBLY P/N:30046A Part No.: 30046A
• 218: MAKITA M5X25 GRUB SCREW FOR HB500 STAND P/N:10085A Part No.: 10085A
• 219: MAKITA M5 NYLOC NUT FOR HB500 STAND P/N:10085B Part No.: 10085B
• 222: MAKITA ARBOR - QUICK RELEASE FOR HB500 P/N:BD062 Part No.: BD062
• 223: MAKITA HB500 SLIDE (D5000 UNIT) P/N:M0167 Part No.: M0167
• 224: MAKITA HB500 F/STEADY INTEGRAL OIL FEED P/N:M0516 Part No.: M0516
• 225: MAKITA HB500-D5000 DRILL-MAKITA BLUE-230V-0422Q P/N:EIB22 Part No.: EIB22
• 226: MAKITA INTEGRAL OILFEED SEAL - 2 P/N:M0050-2 Part No.: M0050-2
• 227: MAKITA BUSH (MB30 STEADY) P/N:M0521 Part No.: M0521
• 228: MAKITA INTEGRAL COOLANT SEAL - 1 P/N:M0050-1 Part No.: M0050-1
• 229: MAKITA 6MM PUSH FIT FITTING FOR HB500 P/N:M0066 Part No.: M0066
• 230: MAKITA M6X30 CAP SCREW FOR HB500 STAND P/N:SC630CAP Part No.: SC630CAP
• 231: MAKITA PCB BOARD 230V FOR HB500 P/N:MM1-5G Part No.: MM1-5G
• 232: MAKITA LED BOARD C/W LED'S FOR HB500 P/N:MM1-4M Part No.: MM1-4M
• 233: MAKITA GREEN LATCHING SWITCH FOR HB500 P/N:MM1-22 Part No.: MM1-22
• 235: MAKITA MAGNET BUTTON - YELLOW FOR HB500 P/N:MM1-1 Part No.: MM1-1
