MAKITA GA5010 ANGLE GRINDER 125MM SPARE PARTS

Spare Parts of Makita GA5010 Angle Grinder Ref. No. Part Name & Number Price 001 MAKITA TAPPING SCREW M5X25 FOR GA5010 Part No.: 266041-8 $0.44 Add To Cart 002 MAKITA PIN CAP FOR MT950 P/N:417771-6 Part No.: 417771-6 $0.33 Add To Cart 003 MAKITA COMPRESSION SPRING 7 FOR 3612C P/N:231037-8 Part No.: 231037-8 $0.11 Add To Cart 004 MAKITA GEAR HOUSING FOR GA5010 P/N:318158-4 Part No.: 318158-4 $11.45 Add To Cart 005 MAKITA RUBBER RING 27 FOR GA5010 P/N:262132-3 Part No.: 262132-3 $0.33 Add To Cart 006 MAKITA HEX.NUT M7 FOR GA5010 P/N:264010-3 Part No.: 264010-3 $0.33 Add To Cart 007 MAKITA SPIRAL BEVEL GEAR 13 FOR GA5010 Part No.: 227517-0 $4.03 Add To Cart 009 MAKITA FLAT WASHER 22 FOR GA5010 P/N:267352-4 Part No.: 267352-4 $0.44 Add To Cart 010 MAKITA RETAINER RING R-30 FOR GA6010 Part No.: 962107-9 $0.44 Add To Cart 011 MAKITA FAN 70 P/N:240094-5 Part No.: 240094-5 $1.20 Add To Cart 012 MAKITA ARMATURE ASS'Y 240V FOR GA5010 P/N:513704-0 Part No.: 513704-0 $31.17 Add To Cart 013 MAKITA INSULATED WASHER FOR UB1100 P/N:681644-1 Part No.: 681644-1 $0.33 Add To Cart 014 MAKITA BALL BEARING 608DDW FOR GA5010 P/N:210044-4 Part No.: 210044-4 $1.20 Add To Cart 015 MAKITA BAFFLE PLATE FOR GA5010 P/N:419961-7 Part No.: 419961-7 $0.87 Add To Cart 016 MAKITA FIELD ASS'Y 220-240V FOR GA5010 P/N:525768-2 Part No.: 525768-2 $29.43 Add To Cart 017 MAKITA TAPPING SCREW 4X65 FOR MT370 P/N:266340-8 Part No.: 266340-8 $0.33 Add To Cart 018 MAKITA MOTOR HOUSING COMPLETE FOR GA5010 P/N:158278-0 Part No.: 158278-0 $14.72 Add To Cart 019 MAKITA HANDLE SET SWITCH LOCK TYPE FOR GA5010 P/N:188291-4 Part No.: 188291-4 $10.14 Add To Cart 022 MAKITA BRUSH HOLDER CAP FOR 4100NH/PV7000C P/N:643750-0 Part No.: 643750-0 $0.44 Add To Cart 025 MAKITA SWITCH (LOCK ON) FOR GA6010 P/N:651193-2 Part No.: 651193-2 $12.86 Add To Cart 026 MAKITA CORD CLAMP FOR GA5010 P/N:687260-7 Part No.: 687260-7 $0.33 Add To Cart 028 MAKITA HANDLE SET SWITCH LOCK TYPE FOR GA5010 P/N:188291-4 Part No.: 188291-4 $10.14 Add To Cart 029 MAKITA CORD GUARD 8-90 FOR 5806B P/N:682503-2 Part No.: 682503-2 $0.76 Add To Cart 030 MAKITA POWER S.CORD BASEC CORD P/N:692021-2 Part No.: 692021-2 $9.92 Add To Cart 031 MAKITA O RING 7 FOR GA5010 P/N:213977-2 Part No.: 213977-2 $0.11 Add To Cart 032 MAKITA SHOULDER PIN 5 FOR GA5010 P/N:256505-0 Part No.: 256505-0 $0.55 Add To Cart 033 MAKITA RUBBER PIN 4 P/N:263002-9 Part No.: 263002-9 $0.11 Add To Cart 035 MAKITA RING SPRING 11 FOR 9553HN P/N:233950-6 Part No.: 233950-6 $0.11 Add To Cart 038 MAKITA SPIRAL BEVEL GEAR 34 A FOR GA5010 P/N:227518-8 Part No.: 227518-8 $7.96 Add To Cart 041 MAKITA PAN HEAD SCREW M3X6 FOR 6226D P/N:911003-8 Part No.: 911003-8 $0.11 Add To Cart 042 MAKITA BEARING RETAINER 39 FOR GA5010 P/N:285728-3 Part No.: 285728-3 $0.44 Add To Cart 043 MAKITA BALL BEARING 6202DDW FOR MT811 P/N:211241-5 Part No.: 211241-5 $2.18 Add To Cart 044 MAKITA FLAT WASHER 15 FOR LS1040 P/N:253853-8 Part No.: 253853-8 $0.33 Add To Cart 045 MAKITA O RING 48 FOR GA5010 P/N:213624-5 Part No.: 213624-5 $0.33 Add To Cart 047 MAKITA PAN HEAD SCREW M5X18 P/N:265131-4 Part No.: 265131-4 $0.33 Add To Cart 048 MAKITA LABYRINTH RING FOR 9553NB P/N:345464-4 Part No.: 345464-4 $0.44 Add To Cart 049 MAKITA SPINDLE FOR GA5010 P/N:324786-5 Part No.: 324786-5 $5.78 Add To Cart 050 MAKITA P.H. SCREW M5X14 FOR MT950 P/N:265103-9 Part No.: 265103-9 $0.11 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA TAPPING SCREW M5X25 FOR GA5010 Part No.: 266041-8
• 002: MAKITA PIN CAP FOR MT950 P/N:417771-6 Part No.: 417771-6
• 003: MAKITA COMPRESSION SPRING 7 FOR 3612C P/N:231037-8 Part No.: 231037-8
• 004: MAKITA GEAR HOUSING FOR GA5010 P/N:318158-4 Part No.: 318158-4
• 005: MAKITA RUBBER RING 27 FOR GA5010 P/N:262132-3 Part No.: 262132-3
• 006: MAKITA HEX.NUT M7 FOR GA5010 P/N:264010-3 Part No.: 264010-3
• 007: MAKITA SPIRAL BEVEL GEAR 13 FOR GA5010 Part No.: 227517-0
• 009: MAKITA FLAT WASHER 22 FOR GA5010 P/N:267352-4 Part No.: 267352-4
• 010: MAKITA RETAINER RING R-30 FOR GA6010 Part No.: 962107-9
• 011: MAKITA FAN 70 P/N:240094-5 Part No.: 240094-5
• 012: MAKITA ARMATURE ASS'Y 240V FOR GA5010 P/N:513704-0 Part No.: 513704-0
• 013: MAKITA INSULATED WASHER FOR UB1100 P/N:681644-1 Part No.: 681644-1
• 014: MAKITA BALL BEARING 608DDW FOR GA5010 P/N:210044-4 Part No.: 210044-4
• 015: MAKITA BAFFLE PLATE FOR GA5010 P/N:419961-7 Part No.: 419961-7
• 016: MAKITA FIELD ASS'Y 220-240V FOR GA5010 P/N:525768-2 Part No.: 525768-2
• 017: MAKITA TAPPING SCREW 4X65 FOR MT370 P/N:266340-8 Part No.: 266340-8
• 018: MAKITA MOTOR HOUSING COMPLETE FOR GA5010 P/N:158278-0 Part No.: 158278-0
• 019: MAKITA HANDLE SET SWITCH LOCK TYPE FOR GA5010 P/N:188291-4 Part No.: 188291-4
• 022: MAKITA BRUSH HOLDER CAP FOR 4100NH/PV7000C P/N:643750-0 Part No.: 643750-0
• 025: MAKITA SWITCH (LOCK ON) FOR GA6010 P/N:651193-2 Part No.: 651193-2
• 026: MAKITA CORD CLAMP FOR GA5010 P/N:687260-7 Part No.: 687260-7
• 028: MAKITA HANDLE SET SWITCH LOCK TYPE FOR GA5010 P/N:188291-4 Part No.: 188291-4
• 029: MAKITA CORD GUARD 8-90 FOR 5806B P/N:682503-2 Part No.: 682503-2
• 030: MAKITA POWER S.CORD BASEC CORD P/N:692021-2 Part No.: 692021-2
• 031: MAKITA O RING 7 FOR GA5010 P/N:213977-2 Part No.: 213977-2
• 032: MAKITA SHOULDER PIN 5 FOR GA5010 P/N:256505-0 Part No.: 256505-0
• 033: MAKITA RUBBER PIN 4 P/N:263002-9 Part No.: 263002-9
• 035: MAKITA RING SPRING 11 FOR 9553HN P/N:233950-6 Part No.: 233950-6
• 038: MAKITA SPIRAL BEVEL GEAR 34 A FOR GA5010 P/N:227518-8 Part No.: 227518-8
• 041: MAKITA PAN HEAD SCREW M3X6 FOR 6226D P/N:911003-8 Part No.: 911003-8
• 042: MAKITA BEARING RETAINER 39 FOR GA5010 P/N:285728-3 Part No.: 285728-3
• 043: MAKITA BALL BEARING 6202DDW FOR MT811 P/N:211241-5 Part No.: 211241-5
• 044: MAKITA FLAT WASHER 15 FOR LS1040 P/N:253853-8 Part No.: 253853-8
• 045: MAKITA O RING 48 FOR GA5010 P/N:213624-5 Part No.: 213624-5
• 047: MAKITA PAN HEAD SCREW M5X18 P/N:265131-4 Part No.: 265131-4
• 048: MAKITA LABYRINTH RING FOR 9553NB P/N:345464-4 Part No.: 345464-4
• 049: MAKITA SPINDLE FOR GA5010 P/N:324786-5 Part No.: 324786-5
• 050: MAKITA P.H. SCREW M5X14 FOR MT950 P/N:265103-9 Part No.: 265103-9
