MAKITA DWT310 CORDLESS SHEAR WRENCH SPARE PARTS

Spare Parts of Makita DWT310 Cordless Shear Wrench Ref. No. Part Name & Number Price 004 MAKITA COMPRESSION SPRING 13 FOR 6922NB P/N:233087-9 Part No.: 233087-9 $1.74 Add To Cart 006 MAKITA SPIRO LOCK WASHER 62 FOR 6922NB P/N:257941-3 Part No.: 257941-3 $5.45 Add To Cart 008 MAKITA SPIRO LOCK WASHER 70 FOR 6922NB P/N:257940-5 Part No.: 257940-5 $7.19 Add To Cart 009 MAKITA '- SCREW M8X8 FOR 6924N P/N:266022-2 Part No.: 266022-2 $3.38 Add To Cart 012 MAKITA BALL BEARING 6810 FOR 6922NB P/N:211611-8 Part No.: 211611-8 $35.97 Add To Cart 014 MAKITA NEEDLE CAGE 810 FOR 6922NB P/N:212954-1 Part No.: 212954-1 $7.63 Add To Cart 020 MAKITA NEEDLE CAGE 810 FOR 6922NB P/N:212954-1 Part No.: 212954-1 $7.63 Add To Cart 021 MAKITA SPUR GEAR 25 FOR 6922NB P/N:226270-5 Part No.: 226270-5 $13.63 Add To Cart 022 MAKITA SPUR GEAR 11 FOR 6922NB P/N:226275-5 Part No.: 226275-5 $303.35 Add To Cart 023 MAKITA PIN 8 FOR 6922NB P/N:256227-2 Part No.: 256227-2 $0.87 Add To Cart 025 MAKITA SPUR GEAR 14 FOR 6922NB P/N:226273-9 Part No.: 226273-9 $247.65 Add To Cart 026 MAKITA BALL BEARING 694 FOR 9500DW P/N:211044-7 Part No.: 211044-7 $5.78 Add To Cart 027 MAKITA SPUR GEAR 25 FOR 6922NB P/N:226269-0 Part No.: 226269-0 $13.63 Add To Cart 028 MAKITA PIN 4 FOR 2012NB P/N:256226-4 Part No.: 256226-4 $0.22 Add To Cart 029 MAKITA THRUST NEEDLE GAUGE 1528 FOR 6922NB P/N:216403-0 Part No.: 216403-0 $5.78 Add To Cart 031 MAKITA BRACKET FOR 6922NB P/N:323855-9 Part No.: 323855-9 $80.01 Add To Cart 034 MAKITA BALL BEARING 6902 FOR 6922NB P/N:211221-1 Part No.: 211221-1 $9.59 Add To Cart 035 MAKITA GEAR CASE COMPLETE FOR 6922NB P/N:159930-3 Part No.: 159930-3 $69.32 Add To Cart 036 MAKITA BALL BEARING 698VV FOR 6922NB P/N:210013-5 Part No.: 210013-5 $4.14 Add To Cart 037 MAKITA HELICAL GEAR 30 FOR XTW01 P/N:226651-3 Part No.: 226651-3 $68.89 Add To Cart 038 MAKITA THRUST NEEDLE BEARING 617 FOR 6922NB P/N:212048-2 Part No.: 212048-2 $16.24 Add To Cart 040 MAKITA SPIRAL BEVEL GEAR 12 FOR 6922NB P/N:226711-1 Part No.: 226711-1 $59.30 Add To Cart 041 MAKITA BALL BEARING 6000LLB P/N:211097-6 Part No.: 211097-6 $3.27 Add To Cart 042 MAKITA HELICAL GEAR 18 6922NB P/N:226476-5 Part No.: 226476-5 $20.82 Add To Cart 044 MAKITA GEAR HOUSING ASS'Y FOR 6922NB P/N:134788-1 Part No.: 134788-1 $90.80 Add To Cart 045 MAKITA HEX.SOCKET HEAD BOLT M4X25 FOR 6922NB P/N:922148-7 Part No.: 922148-7 $0.55 Add To Cart 046 MAKITA BALL BEARING 6000LLB P/N:211097-6 Part No.: 211097-6 $3.27 Add To Cart 047 MAKITA BEARING RETAINER FOR 6922NB P/N:344470-6 Part No.: 344470-6 $3.82 Add To Cart 048 MAKITA PAN HEAD SCREW M4X10 FOR 4304 P/N:911111-5 Part No.: 911111-5 $0.11 Add To Cart 049 MAKITA ROTOR ASSY FOR DWT310 P/N:519497-7 Part No.: 519497-7 $77.72 Add To Cart 050 MAKITA BALL BEARING 607LB FOR 4140 P/N:211023-5 Part No.: 211023-5 $4.14 Add To Cart 051 MAKITA HEX.SOCKET HEAD BOLT M4X14 FOR 6922NB P/N:922123-3 Part No.: 922123-3 $0.44 Add To Cart 052 MAKITA GEAR 14-41 FOR 6922NB P/N:226812-5 Part No.: 226812-5 $98.86 Add To Cart 053 MAKITA BALL BEARING 699 FOR 6922NB P/N:211082-9 Part No.: 211082-9 $6.54 Add To Cart 055 MAKITA COMPRESSION SPRING 4 FOR 6922NB P/N:233098-4 Part No.: 233098-4 $1.31 Add To Cart 057 MAKITA REAR COVER FOR XTW01 P/N:319669-2 Part No.: 319669-2 $241.00 Add To Cart 058 MAKITA H.S.H.BOLT M4X18 WITH WR FOR XTW01 P/N:922133-0 Part No.: 922133-0 $5.34 Add To Cart 059 MAKITA PAN HEAD SCREW M4X12 FOR BO4540 HR2810 P/N:911118-1 Part No.: 911118-1 $0.33 Add To Cart 060 MAKITA RUBBER PIN 6 P/N:263005-3 Part No.: 263005-3 $0.22 Add To Cart 062 MAKITA PLATE FOR TW1000 P/N:345517-9 Part No.: 345517-9 $2.18 Add To Cart 063 MAKITA HEX.SOCKET HEAD BOLT M6X12 P/N:266157-9 Part No.: 266157-9 $0.76 Add To Cart 064 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 065 MAKITA BAFFLE PLATE FOR XTW01 P/N:458306-4 Part No.: 458306-4 $6.43 Add To Cart 066 MAKITA STATOR FOR DTW310 P/N:629337-2 Part No.: 629337-2 $73.90 Add To Cart 067 MAKITA MOTOR HOUSING FOR TW001G/DWT310 P/N:458302-2 Part No.: 458302-2 $33.14 Add To Cart 070 MAKITA CONTROLLER FOR DWT310 P/N:632L40-8 Part No.: 632L40-8 $241.22 Add To Cart 071 MAKITA H.S.H.BOLT M4X25 WITH WG FOR XTW01 P/N:922149-5 Part No.: 922149-5 $5.34 Add To Cart 073 MAKITA PROTECTION BLOCK FOR GA700D P/N:327048-0 Part No.: 327048-0 $1.96 Add To Cart 074 MAKITA H.L.TAPPING SCREW 5X18 FOR GA700D P/N:251587-7 Part No.: 251587-7 $0.33 Add To Cart 075 MAKITA CAP FOR UR008G P/N:422230-7 Part No.: 422230-7 $0.22 Add To Cart 076 MAKITA GUARD PIPE ASS'Y FOR GA700D P/N:135919-5 Part No.: 135919-5 $18.53 Add To Cart 077 MAKITA H.L.TAPPING SCREW 5X18 FOR GA700D P/N:251587-7 Part No.: 251587-7 $0.33 Add To Cart 079 MAKITA TERMINAL FOR DLM330 P/N:644809-6 Part No.: 644809-6 $3.60 Add To Cart 080 MAKITA LED CIRCUIT FOR WT310D P/N:620809-0 Part No.: 620809-0 $9.37 Add To Cart 081 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 082 MAKITA SWITCH C3XA-1PSPM FOR DKP181 P/N:651083-9 Part No.: 651083-9 $18.42 Add To Cart 083 MAKITA SWITCH LEVER FOR XTW01 P/N:458303-0 Part No.: 458303-0 $5.89 Add To Cart 084 MAKITA TRIGGER LOCK FOR XTW01 P/N:458307-2 Part No.: 458307-2 $5.01 Add To Cart 085 MAKITA CHIP LEVER FOR 6922NB P/N:311928-0 Part No.: 311928-0 $20.60 Add To Cart 087 MAKITA TAPPING SCREW 4X18 P/N:265995-6 Part No.: 265995-6 $0.33 Add To Cart 088 MAKITA GEAR ASS'Y FOR 6922NB P/N:134790-4 Part No.: 134790-4 $89.82 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 004: MAKITA COMPRESSION SPRING 13 FOR 6922NB P/N:233087-9 Part No.: 233087-9
• 006: MAKITA SPIRO LOCK WASHER 62 FOR 6922NB P/N:257941-3 Part No.: 257941-3
• 008: MAKITA SPIRO LOCK WASHER 70 FOR 6922NB P/N:257940-5 Part No.: 257940-5
• 009: MAKITA '- SCREW M8X8 FOR 6924N P/N:266022-2 Part No.: 266022-2
• 012: MAKITA BALL BEARING 6810 FOR 6922NB P/N:211611-8 Part No.: 211611-8
• 014: MAKITA NEEDLE CAGE 810 FOR 6922NB P/N:212954-1 Part No.: 212954-1
• 020: MAKITA NEEDLE CAGE 810 FOR 6922NB P/N:212954-1 Part No.: 212954-1
• 021: MAKITA SPUR GEAR 25 FOR 6922NB P/N:226270-5 Part No.: 226270-5
• 022: MAKITA SPUR GEAR 11 FOR 6922NB P/N:226275-5 Part No.: 226275-5
• 023: MAKITA PIN 8 FOR 6922NB P/N:256227-2 Part No.: 256227-2
• 025: MAKITA SPUR GEAR 14 FOR 6922NB P/N:226273-9 Part No.: 226273-9
• 026: MAKITA BALL BEARING 694 FOR 9500DW P/N:211044-7 Part No.: 211044-7
• 027: MAKITA SPUR GEAR 25 FOR 6922NB P/N:226269-0 Part No.: 226269-0
• 028: MAKITA PIN 4 FOR 2012NB P/N:256226-4 Part No.: 256226-4
• 029: MAKITA THRUST NEEDLE GAUGE 1528 FOR 6922NB P/N:216403-0 Part No.: 216403-0
• 031: MAKITA BRACKET FOR 6922NB P/N:323855-9 Part No.: 323855-9
• 034: MAKITA BALL BEARING 6902 FOR 6922NB P/N:211221-1 Part No.: 211221-1
• 035: MAKITA GEAR CASE COMPLETE FOR 6922NB P/N:159930-3 Part No.: 159930-3
• 036: MAKITA BALL BEARING 698VV FOR 6922NB P/N:210013-5 Part No.: 210013-5
• 037: MAKITA HELICAL GEAR 30 FOR XTW01 P/N:226651-3 Part No.: 226651-3
• 038: MAKITA THRUST NEEDLE BEARING 617 FOR 6922NB P/N:212048-2 Part No.: 212048-2
• 040: MAKITA SPIRAL BEVEL GEAR 12 FOR 6922NB P/N:226711-1 Part No.: 226711-1
• 041: MAKITA BALL BEARING 6000LLB P/N:211097-6 Part No.: 211097-6
• 042: MAKITA HELICAL GEAR 18 6922NB P/N:226476-5 Part No.: 226476-5
• 044: MAKITA GEAR HOUSING ASS'Y FOR 6922NB P/N:134788-1 Part No.: 134788-1
• 045: MAKITA HEX.SOCKET HEAD BOLT M4X25 FOR 6922NB P/N:922148-7 Part No.: 922148-7
• 046: MAKITA BALL BEARING 6000LLB P/N:211097-6 Part No.: 211097-6
• 047: MAKITA BEARING RETAINER FOR 6922NB P/N:344470-6 Part No.: 344470-6
• 048: MAKITA PAN HEAD SCREW M4X10 FOR 4304 P/N:911111-5 Part No.: 911111-5
• 049: MAKITA ROTOR ASSY FOR DWT310 P/N:519497-7 Part No.: 519497-7
• 050: MAKITA BALL BEARING 607LB FOR 4140 P/N:211023-5 Part No.: 211023-5
• 051: MAKITA HEX.SOCKET HEAD BOLT M4X14 FOR 6922NB P/N:922123-3 Part No.: 922123-3
• 052: MAKITA GEAR 14-41 FOR 6922NB P/N:226812-5 Part No.: 226812-5
• 053: MAKITA BALL BEARING 699 FOR 6922NB P/N:211082-9 Part No.: 211082-9
• 055: MAKITA COMPRESSION SPRING 4 FOR 6922NB P/N:233098-4 Part No.: 233098-4
• 057: MAKITA REAR COVER FOR XTW01 P/N:319669-2 Part No.: 319669-2
• 058: MAKITA H.S.H.BOLT M4X18 WITH WR FOR XTW01 P/N:922133-0 Part No.: 922133-0
• 059: MAKITA PAN HEAD SCREW M4X12 FOR BO4540 HR2810 P/N:911118-1 Part No.: 911118-1
• 060: MAKITA RUBBER PIN 6 P/N:263005-3 Part No.: 263005-3
