KYORITSU DIGITAL MULTI FUNCTION TESTER 6010B

6 In 1 Multifunction Tester Continuity Insulation Loop RCD Compact Voltage Mains Voltage

Specifications:

• Measuring Range: 20/200Ω (Auto-Ranging)
• Open Circuit Voltage: > 6V
• Short Circuit Current: > 200mA
• Accuracy: ±(3%rdg + 3dgt)
• Measuring Range: 20/200MΩ (Auto-Ranging)
• Test Voltage: 500/1000V
• Open Circuit Voltage: 0.2
• Rated Current: > 1mA
• Accuracy: ± (3%rdg + 3dgt)
• Impedance Range: 20/2000Ω
• Rated Voltage: 230V + 10% - 15%(50Hz)
• Normal Test Current: 20Ω:25A/10ms
• Accuracy: ±(3%rdg + 8dgt)
• Test Current: x1/2, x1
• (Test Current Duration): Fast
• Accuracy: Test Current
• Measuring Range: 100V
• Rated Voltage: 230V + 10% - 15% (50Hz)
• Test Current: 5mA at IΔn = 10mA
• Accuracy: +5%+15%rdg, ±8dgt
• Safety Standard: IEC 61010-1 CAT III 300V Pollution Degree 2
• Power Source: R6 or LR6 &Times 8
• Dimension: 175(L) &Times 115(W) &Times 86(D)mm
• Weight: 840g approx.
