HUGHES SELF-DRAINING COMBINATION SAFETY SHOWER H-EXPSD18GS85G

This floor mounted self-draining emergency safety shower, constructed with Marine 316 Stainless Steel, features an integrated eye/face wash unit. Its innovative design facilitates the drainage of standing water away from the standpipe, ensuring the delivery of tepid water (16-36°C). Positioned directly above the water inlet, the valve is accompanied by a bleed pipe to enable the drainage of standing water into the ground, preventing the formation of stagnant water and potential overheating from solar radiation. This design mitigates the risk of further injury to the operator. Additionally, this unit is suitable for applications exposed to ambient temperatures of up to 45 degrees Celsius in direct sunlight.

Specifications:

• OPERATING PRESSURE: 2 to 6 BAR G / 29 to 87 PSI (higher supply pressures accommodated with the incorporation of the optional pressure reducing valve)
• MINIMUM FLOW RATES: Shower: 76 L per minute / 20 US gal per minute Eye wash: 12 L per minute / 3 US gal per minute
• AMBIENT OPERATING TEMPERATURE: MINIMUM 5C / 41F MAXIMUM 55C / 131F
