HIOKI DIGITAL CLAMP METER 3280-10F

Hioki clamp meters are best-in-class measuring devices incorporating Hioki expertise in current sensing technology. The 3280-10F is an average rectifying 1000A AC clamp meter that features a broad operating temperature range of -25°C to 65°C, thin and compact clamp core and optional flexible current sensor that you can attach to let you get into the tightest spots.

Specifications:

• AC Current: 41.99 to 1000 A, 3 ranges (50 to 60 Hz, Average rectified),
• DC Voltage: 419.9 mV to 600 V, 5 ranges, Basic accuracy: ±1.0 % rdg. ±3 dgt.
• AC Voltage: 4.199 V to 600 V, 4 ranges (45 to 500 Hz, Average rectified),
• Crest factor: N/A
• Resistance: 419.9 Ω to 41.99 MΩ, 6 ranges, Basic accuracy: ±2 % rdg. ±4 dgt.
• Other functions: Continuity: Buzzer sounds at 50 Ω ±40 Ω or less, Data hold, Auto Power save, Drop-proof from Height of 1 meter
• Display: LCD, Max. 4199 dgt., Display refresh rate: 400 ms
• Environmental protection: IP40 dustproof and waterproof
• Power supply: Coin Type Lithium Battery (CR2032) &Times;1, Continuous use 120 hours
• Core jaw dia.: φ 33 mm (1.30 in)
• Dimension and mass: 57 mm (2.24 in) W &Times; 175 mm (6.89 in) H &Times; 16 mm (0.63 in) D, 100 g (3.5 oz)
• Name: File Type
• Hioki 3280-10F Manual: .pdf
