HIKMICRO ECO-V HANDHELD INFRARED CAMERA

The handheld thermal camera is based on the thermal technology, specially designed for the needs of temperature measuring applications. People can quickly troubleshoot faults on-site. • Thermal resolution: 96 × 96 (9,216 pixels) • 112:1 Distance to spot ratio (D:S) • SuperIR: 240 × 240 (57,600 pixels) • NETD: < 50 mK (@ 25°C, F# = 1.0) • Measurement presets: center spot, hot spot, cold spot, off • 25 Hz image frequency • Laser pointer • Built-in 4 GB flash memory: 30,000 pictures • Up to 8 hours continuous running • Thermal/Visual/Fusion

Brand: ECO-V

Specifications:

• NO BRAND: ECO-V
• IR Resolution: 96 × 96 (9,216 pixels)
• SuperIR: 240 × 240 (57,600 pixels)
• Distance to Spot Ratio (D:S): 112:1
• Image Frequency: 25 Hz
• NETD: < 50 mK (@ 25°C, F# = 1.0)
• Detector Pitch: 12 μm
• Focal Length: 1.35 mm
• Spectral Range: 7.5 to 14 μm
• F-number: F1.0
• Field of View (FOV): 50° × 50°
• Spatial Resolution (IFOV): 8.89 mrad
• Min. Focus Distance: 0.1 m (0.33 ft)
• Focus Mode: Focus Free
• Display: 240 × 320 Resolution, 2.4”LCD Screen
• Image Modes: Thermal/Visual/Fusion
• Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion
• Color Alarm: Above alarm
• Visual Camera: 640 × 480
• Object Temperature Range: -20°C to 550°C (-4°F to 1022°F)
• Accuracy: Max (±2°C/3.6°F, ±2%) at ambient temperature 25°C (77°F) and object temperature above 0°C (32°F)
• Measurement Tools: Center Spot, Hot Spot, Cold Spot
• Level and Span Mode: Auto/Manual
• Storage Media: Built-in 4 GB flash memory
• Image Storage Capacity: Approx. 30,000 Images
• USB Interface: USB Type-C
• Laser: Yes, Class II
• Battery Type: Rechargeable Li-ion battery
• Battery Charging Time: Approx. 3 hours fully charged(Adapter Output: 5 V 2 A)
• Battery Operating Time: Approx. 8 hours
• Protection Level: IP54
• Drop Test Height: 2 m (6.56 ft)
• Working Temperature Range: -10°C to 50°C (14°F to 122°F)
• Storage Temperature Range: -40°C to 70°C (-40°F to 158°F)
• Relative Humidity: < 95% non-condensing
• Weight: Approx. 290 g (0.64 lb)
• Dimension: 196 × 117 × 59 mm (7.7” × 4.6” × 2.3”)
• Tripod Mounting: UNC ¼”-20
• Name: File Type
• Hikmicro ECO-V Datasheet: .pdf
