FLUKE INFRARED THERMOMETER 568

Easily trend and analyze data with included FlukeView® Forms software Quickly download stored data with USB connection See your data right away without leaving the site, using the USB and your laptop Extend your battery life by powering the digital thermometer from your laptop via the USB

Specifications:

• Infrared Temperature range: -40 °C to 800 °C (-40 °F to 1472 °F)
• Infrared accuracy: < 0 °C (32 °F): ± (1.0 °C (± 2.0 °F) + 0.1°/1 °C or °F);
• Display resolution: 0.1 °C / 0.1 °F
• Infrared spectral response: 8 µm to 14 µm
• Infrared response Time: < 500 msec
• Thermocouple Type-K input Temperature range: -270 °C to 1372 °C (-454 °F to 2501 °F)
• Thermocouple Type-K input accuracy: -270°C to -40°C:
• D:S (distance to measurement spot Size): 50:1
• Laser sighting: Single-point laser < 1 mw Output Class 2 (II) operation, 630 nm to 670 nm
• Minimumspot Size: 19 mm (0.75 in)
• Emissivity adjustment: By built-in table of common Materials or digitAlly adjustable from 0.10 to 1.00 by 0.01
• Data storage with Date/Time stamp: 99 points
• PC Interface and cable: USB 2.0 with FlukeView® Forms software
• Hi/Low alarms: Audible and two-Colour visual
• Min/Max/Avg/Dif: Yes
• Display: Dot matrix 98 x 96 pixels with function menus
• Backlight: Two levels, Normal and extra bright For darker environments
• Trigger lock: Yes
• Switchable Celsius and Fahrenheit: Yes
• Power: 2 AA/LR6 Batteries and USB when used with a PC
• Battery life: If used continuously:
• Operating Temperature: 0 °C to 50 °C (32 °F to 122 °F)
• Storage Temperature: -20 °C to 60 °C (-40 °F to 140 °F)
• Bead thermocouple Type-K range: -40 °C to 260 °C (-40 °F to 500 °F)
• Bead thermocouple Type-K accuracy: ± 1.1 °C (2.0 °F) from 0 °C to 260 °C (32 °F to 500 °F), typicAlly within 1.1 °C (2.0 °F) from -40 °C to 0 °C (-40 °F to 32 °F)
• Name: File Type
• Fluke 56x (561, 566, 568) Users Manual: .pdf
