FLUKE 381 REMOTE DISPLAY TRUE RMS AC/DC CLAMP METER WITH IFLEX

What once took two people, now takes one Now one technician can do jobs that would otherwise require two people. Clamp the Fluke 381 around a conductor, remove the display and walk across the room to operate controls or remove protective equipment, all while watching real-time readings. The iFlex® Flexible Current Probe (included) expands the measurement range to 2500 A AC while providing increased display flexibility. With a cord that runs 6 feet, you can finally measure those tight spaces, awkward sized conductors and disorganized wires.

Specifications:

• Range: 999.9 A
• Resolution: 0.1 A
• Accuracy: 2% ± 5 digits (10-100 Hz)
• Crest Factor (50/60 Hz): 3 @ 500 A
• Range: 999.9 A / 2500 A (45 Hz – 500 Hz)
• Resolution: 0.1 A / 1 A
• Accuracy: 3% ± 5 digits
• Crest Factor (50/60 Hz): 3.0 at 1100 A
• Flexible current probe: Distance from Optimum
• Accuracy: 2% ± 5 digits
• Range: 600 V /1000 V
• Resolution: 0.1 V / 1 V
• Accuracy: 1.5% ± 5 digits (20 – 500 Hz)
• Range: 600.0 V /1000 V
• Accuracy: 1% ± 5 digits
• Range: 5.0 – 500.0 Hz
• Resolution: 0.1 Hz
• Accuracy: 0.5% ± 5 digits
• Trigger Level: 5 – 10 Hz, ≥ 10 A
• Range: 5.0 to 500.0 Hz
• Trigger Level: 5 to 20 Hz, ≥ 25 A
• Range: 600 Ω/6 kΩ/60 kΩ
• Resolution: 0.1 Ω/1 Ω/10 Ω
• Size (L x W x H): 277 x 88 x 43 mm (55 mm for remote unit)
• Weight: 350 g
• Jaw Opening: 34 mm
• Flexible Current Probe Diameter: 7.5 mm
• Flexible Current Probe Cable Length: 1.8 m
• Operating Temperature: -10°C to +50°C
• Storage Temperature: -40°C to +60°C
• Operating Humidity: Non condensing (< 10°C)
• Operating Altitude: 2,000 meters
• Storage Altitude: 12,000 meters
• EMI, RFI, EMC, RF: EN 61326-1:2006, EN 61326-2-2:2006
• Temperature Coefficients: Add 0.1 x specified accuracy for each degree C above 28°C or below 18°C
• Wireless Frequency: 2.4 GHz ISM Band 10 meter range
• Safety Compliance: ANSI/ISA S82.02.01:2004
• Double Insulation Clearance: Per IEC 61010-2-032
• Double Insulation Creepage: Per IEC 61010-1
