FLUKE 365 DETACHABLE JAW TRUE RMS AC/DC CLAMP METER

The Fluke 365 is a rugged meter perfect for jobs where access to wires is difficult. The 365’s thin, small jaw is detachable with a flexible lead, which makes gaining access to wires and viewing the display easier than ever.

Specifications:

• Range: 200.0 A
• Resolution: 0.1 A
• Accuracy: 2 % ±5 digits (45 – 65 Hz)
• Crest Factor: 2.5 @ 125 A
• Accuracy: 2 % ±5 digits
• Range: 600.0 V
• Resolution: 0.1 V
• Accuracy: 1.5 % ±5 digits (45 – 400 Hz)
• Accuracy: 1 % ±5 digits
• Range: 600.0 Ω/6000 Ω
• Resolution: 0.1 Ω/1 Ω
• Size (L x W x H): 225 x 65 x 46 mm
• 225 x 65 x 46 mm: 275 g (including batteries)
• Jaw Opening: 18 mm
• Detachable Jaw Cable Length: 900 mm
• Operating Temperature: -10 °C to +50 °C
• Storage Temp: -40 °C to +60 °C
• Operating Humidity: Non condensing (<10 °C)
• Operating Altitude: 2000 meters
• Storage Altitude: 12,000 meters
• Temperature Coefficients: 0.1 x(specified accuracy)/ °C (<18 °C or > 28 °C)
• Safety Compliance: ANSI/ISA S82.02.01:2004
• Batteries: 2 AA, NEDA 15A, IEC LR6
