FISCHER KDH4 SPRING TOGGLE 4MM X 95MM X 2PPP 084342

For example, with the fischer spring fixing KDH lights can be fixed in gypsum plasterboard and gypsum fibreboard, chipboard, and hollow ceilings made of brick and concrete. The spring fixing is inserted into the drill hole in the pre-positioned installation and flips open independently when behind the board. This does not require a special installation tool and allows for a fast, convenient installation. • High load capacity due to good load distribution on the transition beams. • Simple assembly due to self-opening tension spring. • High flexibility due to a long thread. Use with various panel thicknesses and attachment thicknesses. • With hook. • Suitable for pre-positioned installation.

Specifications:

• Drill diameter (d0): 12 mm
• Max. panel thickness (dp): 51 mm
• Min. cavity depth (a): 27 mm
• Anchor length (l): 105 mm
• Thread (ø x length): M3 x 80 mm
• Contents: 2 x Spring toggle KDH 3
• Packaging: Blister card
• Amount: 2 pcs
• GTIN (EAN-Code): 8590369454757
