EXTECH COMBINATION TACHOMETER +IR THERMOMETER RPM10

The RPM10 is a combination tachometer which provides both contact and non-contact RPM measurements, making this device useful in virtually all applications. The RPM10 also features a built-in IR thermometer with laser pointer for measuring surface temperature from -4 to 600 degrees F (-20 to 315 degrees C), making it ideal for checking the operating temperature of motors, bearings and machinery. Complete with wheels for linear surface speed (0.2 to 6560 ft. /minute; 0.05 to 1999.9 m/minute) or RPM measurements, 4 AA batteries, 23 in. (0.6 m) reflective tape, carrying case, and user manual.

Specifications:

• Display counts:: 99,999 count LCD
• Range (rpm):: Photo: 10 to 99,999 Contact: 0.5 to 20,000
• ft/Min:: 0.2 to 6560 (Contact)
• m/Min:: 0.05 to 1999.9 (Contact)
• Basic Accuracy:: ±(0.05%rdg+ 1 digit)
• Max rpm Resolution:: 0.1rpm
• Temperature (IR):: -4 to 600°F (-20 to 315°C)
• Dimension:: 8.5x2.6x1.5" (216x66x38mm)
• Weight:: 10.6oz (300g)
• Name: File Type
• Extech RPM10 Data Sheet: .pdf
• Extech RPM10 Manual: .pdf
