EXTECH COATING THICKNESS TESTER WITH BLUETOOTH CG304

The CG304 Coating Thickness Tester offers a non-destructive way of measuring the thickness of ferrous and non-ferrous substrates with automatic recognition of the material being measured. Memory stores 2500 readings. The unique Bluetooth interface feature wirelessly transmits data to your PC for further analysis and enables you to generate a documented report. Special LCD with backlight feature and contrast for easy viewing in various lighting conditions. Complete with two AAA batteries, software, hard case, Steel and Aluminum substrates and standard films for calibration.

Specifications:

• Specifications: Ferrous Probe
• Working Principle: Magnetic Induction
• Measuring Range: 0 to 2000µm; 0 to 78.7mils
• Accuracy: ±(2%+2µm); ±3.5% (1000 to 2000µm)
• Resolution: 0.1µm (0.01mils)
• MinimumCurvature Radius: 1.5mm (59.06mils)
• MinimumDiameter: 7mm (275.6mils)
• MinimumThickness: 0.5mm (19.69mils)
• Dimension /Weight: 4.7x2.4x1.25" (120x62x32mm)/6.17oz (175g)
• Name: File Type
• Extech CG304 Data Sheet: .pdf
• Extech CG304 Manual: .pdf
