CLABER DUAL LOGIC 8485

Two-way automatic water timer, with watering on two independent lines. Powered by 2 x 1.5 V AA alkaline batteries, fitted in a rainproof socket. Easy programming with a single digital button. 19 preset programmes (+ off) for each line, listed on the front cover. Backlit LCD screen displaying the different functions (programming, time remaining, watering time, rain sensor). Start button allowing immediate or delayed (up to 23 hours) start, on both lines. On/off button for manual function (5-minute test). Reinforced structure. Bimaterial front panel. Transparent protective cover. Electronic components fully insulated, no wires exposed to view. 3/4 inch tap connector with pivoting ring nut. Washable filter. Operating pressure 0.2 – 12 bar. Can be connected to standard Rain Sensor (90915) or to wireless RF Rain Sensor (90831 – with optional interface). 100% checked and tested.

Specifications:

• Inlet thread: ¾"
• Outlet Quick connection: Quick-Click System
• Water fLow: 41 l/Min
• Pressure: 5 bar
• Outlets: 2
• Programmes: 19 per line
• Frequency of watering cycles: 3 per day o 1 per week
• Watering duration: da 00:02′ a 01:30′
• Rain sensor: Wired, Wireless
• Powered by: 2&Times;AA - 1.5V
