BOSCH DIGITAL INCLINOMETER GIM60L

Integrated point laser for incline measurement up to 30 m length Strong magnets and two straps for securely fastening the instrument to workpieces Incline mechanism for fine adjustment on uneven surfaces Any value can be set as alternative 0° Angles can be adjusted manually to enable easy transfer Audio signal guides the user to the desired angle without having to look at the display Units of measure can be switched Display rotates automatically to make it easier to read

Brand: Bosch

Specifications:

• Length: 60 cm
• Measurement range: 0 – 360° (4 x 90°)
• Electronics measurement accuracy 0°/90°: .05°
• Electronics measuring accuracy at 1– 89°: .1°
• Working range (laser): 30 m
• Power supply, inclination measurement: 1 x 9 V 6LR61
• Power supply, laser mode: 2 x 1.5 V LR03
• Operating duration, inclination measurement, approx.: 300 h
• Operating duration, laser mode, approx.: 20 h
• Automatic deactivation, approx.: 30 Mins
• Weight, approx.: 0,9 kg
• Length: 618 mm
• Width: 27 mm
• Height: 59 mm
• Laser Type: 635 nm, < 1 mW
• Laser range: 30 m
• Laser class: 2
• Levelling accuracy of laser: .5 mm/m
• Units of measurement: °, %, mm/m
• Tripod thread: 1/4"
• Name: File Type
• Bosch GIM60 & GIM120 Manual: .pdf
