B&N PROFESSIONAL BENCH DRILL PRESS W/LASER, 550W, BND1601L
550W Motor Cast iron working table, Cast iron base Front emergency switch J2516-B16 Chuck + Chuck guard Cast iron belt Pulley Rack lifting system Equipped with Cross Laser Light
Availability:
In stock
SKU
WOW-5438
550W Motor Cast iron working table, Cast iron base Front emergency switch J2516-B16 Chuck + Chuck guard Cast iron belt Pulley Rack lifting system Equipped with Cross Laser Light
Specifications:
- A: Max Drilling Diameter (mm)
- Motor Power (W): 550
- Chuck Capacity (mm): 3-16
- B: Spindle Travel (mm)
- Class Of Speed: 16
- Speed 50Hz: 180-2770R.P.M.
- Speed 60Hz: 220-3320R.P.M.
- C: Spindle Taper
- D: Max. distance from spindle axis to surface of column (mm)
- E: Max. distance from spindle end to surface of table (mm)
- F: Max. distance from spindle end to surface of base (mm)
- Swing (mm): 325
- table Size (mm): Φ290
- Base Size (mm): 420X250
- G: Column Diameter (mm)
- H: Height (mm)
- Net Weight/Gross Weight (Kg): 42/45
- Packing Size (mm): 770X450X260
