ATLAS COPCO AIR COMPRESSOR ATB10-270 -10.0HP/270L(7.5KW) 400V/50HZ WITH MOM

The ATB 10 Cast Iron Piston Compressors are built to your needs to ensure you continue a compressor lifetime of performance and reliability. The IP55 motor and stainless-steel valves ensure that you receive a highly efficient compressor. The reliable ATB 10 Cast Iron Piston Compressor is made of super strong cast iron. * Price includes PE inspection and registration of unit with MOM * Workplace Number is a compulsory information, it consists of (UEN+ 4 digits) eg. 123456789A0001 * User guide to check for existing workplace number is available at the "Downloads" tab, please check with MOM if you are unsure of this information. * To speed up the MOM registration process, you may want to prefill the registration form located at the "Downloads" tab and email to our customer service quoting your online order. * Please note that the delivery date may be extended if the details provided is not complete or inaccurate ** Product warranty is 1 year ** Re-inspection is required every 2 years, and has to be arranged & paid additionally

Specifications:

• Power: 10hp/7.5kW (4000/1/50)
• Max pressure: 10 bar/145 psi
• Tank: 270L
• Pump displacement: 1470 l/m /51.9 cfm
• Free air delivery: 1020 l/m /36 cfm
• Current draw: 15.4 amp
• Noise: 77 dB (A)
• Cylinders/Stages: 3/1
• Motor speed: 810 RPM
• Weight: 290kg
• Dimension: L1560xW610xH1280mm
• Name: File Type
• MOM Registration Form - Atlas Copco Air Compressor: .pdf
• MOM - Search Existing Workplace Number Guide.pdf: .pdf
