ACISION PTC7300 POCKET THERMAL CAMERA

The Acision PTC-7300 features a 49,152-pixel detector along with a customizable 2MP to 8MP optical lens. With 3-level/span modes (manual, auto, 1-tap), it elevates image contrast for swift fault identification and precise temperature measurements ranging from -20 °C to 400 °C. Its versatility makes it an outstanding choice for applications such as building inspections, HVAC, electrical, and mechanical maintenance. Key features • 256x192 thermal resolution (NETD < 40 mK) - ultra high resolution • Multiple image modes - Thermal, Fusion, PIP, Optical • Measurement presets - center spot, hot spot, cold spot, off • Portable design fits easily into pocket and tool bag • IP54 rating and 2-meter drop test protection suitable for industrial use • 3.5in color LCD Touch Screen display; 640x480 resolution; 1x to 4x digital zoom • Level and span modes (Auto, Manual, 1-tap touchscreen) • High-temperature alarm - audio/visual alerts to high temperatures • LED work light - work safely in dark environments • 7 Color palettes - white hot, black hot, rainbow, iron bow, red hot, fusion, rain • 25 Hz fast image frequency - smooth video, measurements if panning scenes, moving targets • 4hrs continuous running battery life • Field of View - 50° x 37.2° • Storage 16GB internal; 60K images, 10hrs video, radiometric JPEG with measurement data

Specifications:

• Detector Size: 256 x 192 Sensor
• Thermal Sensitivity: 40 mK (NETD)
• Temperature Range Max: 400 C
• Temperature Range Min: -20 C
• Image Frequency: 25 Hz
• Field of View: 50x37.5 Degrees
• Screen Size: 8.89 cm
• IR/Overlay Fusion Image: Yes
• Video Output: Yes
• Focus: Fixed
• Laser Spot: Yes
• Picture in Picture: Yes
• Video Recording: Yes
• Touch Screen Display: Yes
• Minimum Focus Distance: 0.3 M
• Accuracy: Max. (+/- 2C, +/-2%)
• Battery operating time Continuous: 4 HR
• Camera Light: Yes
• IR Digital Zoom: Yes
• Voice Annotation: Yes
• Warranty: 2 YEARS
• Safety Approval: RoHS
• IP Rating: IP54
• Product Weight: 218grams
• Product Height: 13.85cm
• Product Length: 8.51cm
• Product Width: 2.36cm
• HTS/Schedule B Number: 9027.50.4020
• ECCN Number: 6A003.b.4.b
• Power Supply Voltage: Battery Powered
• Name: File Type
• Acision PTC7300 Pocket Thermal Camera Product Datasheet: .pdf
