ACISION HANDHELD THERMAL CAMERA HTC7630

Acision HTC7630 is a camera with both optical images and thermal images. The built-in high-sensitivity IR detector and high-performance sensor detects the temperature change and measure the real-time temperature. Key Features • Thermal resolution: 384 x 288 (110, 592 pixels) • NETD : < 35mK (@ 25 °C) • Temperature measurement range : -20 °C to 550°C • Accuracy: Max (±2 °C or ±2%) • Measurement Presets: Center spot, Hot spot, Cold spot, User Preset Point/Line/Area • Manual focus • 25 Hz image frequency • 3.5’’ LCD touch screen display

Specifications:

• Image Sensor: Vanadium Oxide Uncooled Focal Plane Arrays
• IR Resolution: 384 x 288 9110 592 pixels)
• Pixel Pitch: 17 μm
• NETD: < 35mK (@25°C)
• Focal Length: 10 mm
• FOV (Field of View): 37.5° x 28.5°
• Image Frequency: 25 Hz
• FOCUS: Manual
• IFOV (Spatial Resolution): 1.7mrad
• Aperture: F1.0
• Picture Resolution: Configurable: 2 MP, 5 MP, 8 MP
• Video Resolution: 640 x 480
• Focus: Fixed
• FOV: 37.5° x 28.5°
• Display: 640 x 480 Resolution, 3.5" LCD Touch Screen
• Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain
• Digital Zoom: 1x, 2x, 4x, 8x
• Image Modes: Thermal/Optical/Fusion/PIP
• PIP: Thermal Picture in Optical Picture
• Fushion: Thermal Pictire and Optical Picture Combined
• Object Temperture Range: -20°C to 550°C (-4 °F to 1022 °F)
• Accuracy: Max (±2°C , ±2%)
• Measurement Presets: Center Spot, Hot Spot, Cold Spot, Off
• Point: 10 user Presets
• Line: 1 User Preset
• Area: 3 Usr Presets
• High Temperature Alarm: Audible Warning
• Color Alarm (Isotherm): Above/Below/Interval/Insulation
• Storage Media: Removale Micro SD Card (64 GB)
• Image Storage Capacity: 120 000 images)
• Image File Format: JPEG with Measurement Data Included
• Video Storage Capacity: 56 Hours
• Video File Format: MP4
